STACKABLE CRESCENT CUBER
HOSHIZAKI
MODEL
KM-1200SAE
KM-1200SWE
KM-1200SRE
(FINAL) PARTS LIST
NO.
ISSUED:
DEC., 22, 1992
REVISED:
JUNE 19, 2000
71082

Advertisement

loading
Need help?

Need help?

Do you have a question about the KM-1200SAE and is the answer not in the manual?

Questions and answers

Related Manuals for Hoshizaki KM-1200SAE

Summary of Contents for Hoshizaki KM-1200SAE

  • Page 1 STACKABLE CRESCENT CUBER KM-1200SAE KM-1200SWE KM-1200SRE (FINAL) PARTS LIST HOSHIZAKI MODEL 71082 ISSUED: DEC., 22, 1992 REVISED: JUNE 19, 2000...

  • Page 5: Ice Cuber Assembly

    KM-1200SAE A. ICE CUBER ASSEMBLY...
  • Page 6 KM-1200SAE A. ICE CUBER ASSEMBLY...
  • Page 7 KM-1200SAE A. ICE CUBER ASSEMBLY C-1, D-0, E-0, E-1, F-0, F-1, G-0, G-1, H-0...
  • Page 8 JUNCTION BOX COVER BULB HOLDER (A) BULB HOLDER (B) BULB HOLDER SPACER BULB HOLDER (C) BUSHING SPACER BULB HOLDER (D) FRONT PANEL - BRACKET KM-1200SAE A. ICE CUBER ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER NUMBER B-1 C-0 C-1 D-0 105942A01...
  • Page 9 KM-1200SAE MODEL INDEX DESCRIPTION SPACER TOP INSULATION FRONT INSULATION THUMBSCREW SIDE PANEL (R) TOP PANEL (A) GASKET LOUVER (B) LOUVER (C) TAPPING SCREW - BLACK AIR FILTER (B) AIR FILTER (C) FRONT PANEL BARRIER A. ICE CUBER ASSEMBLY TITLE MATERIAL...
  • Page 10 KM-1200SWE A. ICE CUBER ASSEMBLY...
  • Page 11 KM-1200SWE A. ICE CUBER ASSEMBLY...
  • Page 12 KM-1200SWE A. ICE CUBER ASSEMBLY C-1, D-0, E-0, E-1, F-0...
  • Page 13 KM-1200SWE A. ICE CUBER ASSEMBLY F-1, G-0, G-1, H-0...
  • Page 14 MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONTROL BOX ASSEMBLY LABEL LOCATION EVAP. CASE CONTROL BOX COVER SQUARE WASHER SCREW - GROUNDING BUSHING JUNCTION BOX COVER BULB HOLDER (A) BULB HOLDER (B) BULB HOLDER SPACER BULB HOLDER (C) CAPILLARY RING SPACER BULB HOLDER (D) FRONT PANEL - BRACKET...
  • Page 15 KM-1200SWE MODEL INDEX DESCRIPTION SPACER TOP INSULATION FRONT INSULATION THUMBSCREW SIDE PANEL (R) TOP PANEL (A) GASKET LOUVER (B) LOUVER (C) TAPPING SCREW - BLACK FRONT PANEL BARRIER A. ICE CUBER ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER NUMBER B-1 C-0 C-1 324321-01 ABS, PE 324216G01...
  • Page 16 KM-1200SRE A. ICE CUBER ASSEMBLY...
  • Page 17 KM-1200SRE A. ICE CUBER ASSEMBLY...
  • Page 18 KM-1200SRE A. ICE CUBER ASSEMBLY C-1, D-0, E-0, E-1, F-0...
  • Page 19 KM-1200SRE A. ICE CUBER ASSEMBLY F-1, G-0, G-1, H-0...
  • Page 20 MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONTROL BOX ASSEMBLY LABEL LOCATION EVAP. CASE CONTROL BOX COVER SQUARE WASHER SCREW - GROUNDING BUSHING JUNCTION BOX COVER BULB HOLDER (A) BULB HOLDER (B) BULB HOLDER SPACER BULB HOLDER (C) BUSHING SPACER BULB HOLDER (D) FRONT PANEL - BRACKET KM-1200SRE...
  • Page 21 MODEL INDEX DESCRIPTION SPACER TOP INSULATION FRONT INSULATION THUMBSCREW SIDE PANEL (R) TOP PANEL (A) GASKET LOUVER (B) LOUVER (C) TAPPING SCREW - BLACK FRONT PANEL BARRIER BUSHING KM-1200SRE A. ICE CUBER ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER B-1 C-0 C-1 D-0 E-0 E-1 F-0 F-1 G-0 324321-01 ABS, PE 324216G01...

  • Page 22: Refrigeration Circuit

    KM-1200SAE B. REFRIGERATION CIRCUIT (1/2) B-1, C-0, C-1, D-0, E-0, F-0...
  • Page 23 KM-1200SAE B. REFRIGERATION CIRCUIT (1/2) F-1, G-0, G-1, H-0...
  • Page 24 KM-1200SAE B. REFRIGERATION CIRCUIT (2/2)
  • Page 25 KM-1200SAE B. REFRIGERATION CIRCUIT (2/2)
  • Page 26 KM-1200SAE B. REFRIGERATION CIRCUIT (2/2) C-1, D-0, E-0, E-1, F-0, F-1, G-0, G-1, H-0...
  • Page 27 KM-1200SAE MODEL INDEX DESCRIPTION EVAPORATOR REAR FRAME SIDE FRAME (A) SIDE FRAME (B) FRONT FRAME FRONT FRAME (A) CONDENSER SHROUD COMPRESSOR INSULATION - COMPRESSOR GROMMET SPACER BOLT FAN MOTOR BRACKET FAN MOTOR CAPACITOR FAN BLADE DRIER EXPANSION VALVE FRAME SEAL HOT GAS VALVE BRACKET B.
  • Page 28 KM-1200SAE MODEL INDEX DESCRIPTION LINE VALVE BRACKET PRESSURE SWITCH PRESSURE SWITCH BRCKT. GS COPPER TUBE - ACCESS VALVE ACCESS VALVE COPPER TUBE (A) - HIGH SIDE STRAINER CHECK VALVE COPPER TUBE - LINE VALVE COPPER HEAT EXCHANGER COPPER TUBE (R) - LOW SIDE...
  • Page 29 KM-1200SAE MODEL INDEX DESCRIPTION CABLE TIE "C" CLAMP VALVE BODY COIL - VALVE BOLT CLAMP SELF-LOCKING NUT DRIER BRACKET COPPER TUBE (D) - HIGH SIDE INSULATION TUBE EVACUATION TUBE B. REFRIGERATION CIRCUIT TITLE MATERIAL PART OR MODEL NUMBER B-1 C-0 C-1 D-0...
  • Page 30 KM-1200SWE B. REFRIGERATION CIRCUIT (1/2) B-1, C-0...
  • Page 31 KM-1200SWE B. REFRIGERATION CIRCUIT (1/2)
  • Page 32 KM-1200SWE B. REFRIGERATION CIRCUIT (1/2) D-0, E-0, E-1, F-0...
  • Page 33 KM-1200SWE B. REFRIGERATION CIRCUIT (1/2) F-1, G-0, G-1, H-0, H-1...
  • Page 34 KM-1200SWE B. REFRIGERATION CIRCUIT (2/2) B-1, C-0...
  • Page 35 KM-1200SWE B. REFRIGERATION CIRCUIT (2/2) C-1, D-0, E-0, E-1, F-0, F-1, G-0, G-1, H-0, H-1...
  • Page 36 KM-1200SWE MODEL INDEX DESCRIPTION EVAPORATOR REAR FRAME SIDE FRAME (A) SIDE FRAME (B) FRONT FRAME FRONT FRAME (A) REAR PANEL (A) CONDENSER - WATER- COOLED COMPRESSOR INSULATION - COMPRESSOR GROMMET SPACER BOLT DRIER EXPANSION VALVE FRAME SEAL HOT GAS VALVE BRACKET LINE VALVE BRACKET B.
  • Page 37 KM-1200SWE MODEL INDEX DESCRIPTION PRESSURE SWITCH PRESSURE SWITCH BRACKET COPPER TUBE - ACCESS VALVE ACCESS VALVE WATER REGULATOR BRCKT. WATER REGULATOR FITTING COPPER TUBE (A) - HIGH SIDE STRAINER CHECK VALVE COPPER TUBE (B) - HIGH SIDE COPPER TUBE LINE - HIGH SIDE HEAT EXCHANGER COPPER TUBE (R) - LOW SIDE...
  • Page 38 KM-1200SWE MODEL INDEX DESCRIPTION CLAMP EXP. VALVE COVER (A) EXP. VALVE COVER (B) THERMISTOR HOLDER - THERMISTOR INSULATION - THERMISTOR HOLDER / EXP. VALVE - 3/8 INSULATED RUBBER TUBE INSULATION CLAMP WIRE SADDLE CABLE TIE "C" CLAMP VALVE BODY COIL - VALVE BOLT DRIER BRACKET INSULATION TUBE...
  • Page 39 KM-1200SRE B. REFRIGERATION CIRCUIT (1/2) B-1, C-0, C-1, D-0 E-0, E-1, F-0...
  • Page 40 KM-1200SRE B. REFRIGERATION CIRCUIT (1/2) F-1, G-0, G-1, H-0...
  • Page 41 KM-1200SRE B. REFRIGERATION CIRCUIT (2/2) B-1, C-0...
  • Page 42 KM-1200SRE B. REFRIGERATION CIRCUIT (2/2) C-1, D-0, E-0, E-1, F-0, F-1, G-0, G-1,...
  • Page 43 KM-1200SRE MODEL INDEX DESCRIPTION EVAPORATOR REAR FRAME SIDE FRAME (A) SIDE FRAME (B) FRONT FRAME REAR PANEL COMPRESSOR INSULATION - COMPRESSOR GROMMET SPACER BOLT RECEIVER TANK DRIER EXPANSION VALVE FRAME SEAL HOT GAS VALVE BRACKET LINE VALVE BRACKET PRESSURE SWITCH PRESSURE SWITCH BRACKET COPPER TUBE-ACCESS VALVE ACCESS VALVE...
  • Page 44 KM-1200SRE MODEL INDEX DESCRIPTION STRAINER CHECK VALVE COUPLING TUBE HOLDER (L) COUPLING TUBE HOLDER (S) COPPER TUBE (A) - HIGH SIDE COPPER TUBE (B) - HIGH SIDE COPPER TUBE (C) - HIGH SIDE CLAMP HEAT EXCHANGER COPPER TUBE (R) - LOW SIDE COPPER TUBE (L) - LOW SIDE COPPER TUBE - HOT GAS COPPER TUBE CAPILLARY...
  • Page 45 KM-1200SRE MODEL INDEX DESCRIPTION VALVE BODY COIL - VALVE BOLT HOLDER / EXP. VALVE - 3/8 DRIER BRACKET INSULATION TUBE EVACUATION TUBE B. REFRIGERATION CIRCUIT TITLE MATERIAL PART OR MODEL NUMBER B-1 C-0 C-1 D-0 E-0 E-1 440352-01 440353-01 ABS-25-1-HD-2 440353F01 3A0107-01 4A0807-01...

  • Page 46: Water Circuit

    KM-1200SAE, SWE, SRE C. WATER CIRCUIT...
  • Page 47 KM-1200SAE, SWE, SRE C. WATER CIRCUIT...
  • Page 48 KM-1200SAE, SWE, SRE C. WATER CIRCUIT C-1, D-0, E-0...
  • Page 49 KM-1200SAE, SWE, SRE C. WATER CIRCUIT E-1, F-0, F-1, G-0, G-1, H-0, H-1...
  • Page 50 KM-1200SAE, SWE, SRE MODEL INDEX DESCRIPTION PUMP MOTOR ASSEMBLY FITTING - INLET FITTING HOLDER - INLET WATER SUPPLY PIPE RUBBER GASKET WATER VALVE BRACKET WATER VALVE DISTRIBUTOR HOSE (A) JOINT PIPE DISTRIBUTOR HOSE (B) CABLE TIE HOSE CLAMP SPRAY TUBE...
  • Page 51 KM-1200SAE, SWE, SRE MODEL INDEX DESCRIPTION HOSE (B) VALVE HOUSING - DRAIN SPRING VALVE SHEET OVERFLOW CAP JOINT - OVERFLOW BUSHING CONDUIT BUSHING BUSHING FLOAT SWITCH BRACKET CONNECTOR - FLOAT SWITCH FLOAT SWITCH CLAMP CLAMP BARRIER "O" RING "O" RING...
  • Page 52 KM-1200SAE, SWE, SRE MODEL INDEX DESCRIPTION JOINT HOSE DISTRIBUTOR (B) FLANGE BY-PASS HOSE MALE ADAPTOR "O" RING BALL VALVE VALVE HOLDER MICRO SWITCH TAPPING SCREW JOINT HOSE HANDLE CORNER INSULATION (A) CORNER INSULATION (B) HANDLE BRACKET FLOAT SWITCH STOP VINYL HOSE...
  • Page 53 KM-1200SAE, SWE, SRE MODEL INDEX DESCRIPTION VINYL HOSE SILICONE HOSE VINYL HOSE SILICONE HOSE WIRE SADDLE TITLE MATERIAL PART OR MODEL NUMBER B-1 C-0 C-1 D-0 E-0 E-1 F-0 L=140 7716-0913 7730 I 3812 L=140 L=390 7716-0913 7730 I 3812...

  • Page 54: Control Box Assembly

    KM-1200SAE D. CONTROL BOX ASSEMBLY...
  • Page 55 KM-1200SAE D. CONTROL BOX ASSEMBLY...
  • Page 56 KM-1200SAE D. CONTROL BOX ASSEMBLY C-1, D-0, E-0, E-1, F-0, F-1, G-0, G-1, H-0...
  • Page 57 KM-1200SAE MODEL INDEX DESCRIPTION CONTROL BOX CAPACITOR - STARTING CAPACITOR STRAP STARTER MAGNETIC CONTACTOR BRACKET CAPACITOR BUSHING BUSHING TRANSFORMER CLAMP CONTROLLER BOARD BOARD SUPPORT CONTROL LABEL THERMOSTAT TOGGLE SWITCH 3P PLUG HOUSING 2P PLUG HOUSING 3P RECEPTACLE HOUSING D. CONTROL BOX ASSEMBLY...
  • Page 58 KM-1200SAE MODEL INDEX DESCRIPTION 2P RECEPTACLE HOUSING BUSHING 2P PLUG HOUSING 2P RECEPTACLE HOUSING RELAY TAPPING SCREW BUSHING D. CONTROL BOX ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER B-1 C-0 C-1 D-0 E-0 E-1 F-0 3191-02R1 412831-07 OCB-500 428394-02 3190-02P...
  • Page 59 KM-1200SWE D. CONTROL BOX ASSEMBLY...
  • Page 60 KM-1200SWE D. CONTROL BOX ASSEMBLY...
  • Page 61 KM-1200SWE D. CONTROL BOX ASSEMBLY C-1, D-0, E-0, E-1, F-0, F-1, G-0, G-1, H-0, H-1...
  • Page 62 KM-1200SWE MODEL INDEX DESCRIPTION CONTROL BOX CAPACITOR - STARTING CAPACITOR STRAP STARTER MAGNETIC CONTACTOR BRACKET CAPACITOR BUSHING BUSHING TRANSFORMER CLAMP CONTROLLER BOARD BOARD SUPPORT CONTROL LABEL THERMOSTAT TOGGLE SWITCH 3P PLUG HOUSING 2P PLUG HOUSING 3P RECEPTACLE HOUSING D. CONTROL BOX ASSEMBLY TITLE MATERIAL PART...
  • Page 63 KM-1200SWE MODEL INDEX DESCRIPTION 2P RECEPTACLE HOUSING BUSHING BUSHING D. CONTROL BOX ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER B-1 C-0 C-1 D-0 E-0 E-1 F-0 3191-02R1 412831-07 OCB-500 428394-02 OCB-750 428394-01 OCB-875 428394-04 REQUIRED NUMBER H-0 H-1...
  • Page 64 KM-1200SRE D. CONTROL BOX ASSEMBLY...
  • Page 65 KM-1200SRE D. CONTROL BOX ASSEMBLY...
  • Page 66 KM-1200SRE D. CONTROL BOX ASSEMBLY C-1, D-0, E-0, E-1, F-0, F-1, G-0, G-1, H-0...
  • Page 67 KM-1200SRE MODEL INDEX DESCRIPTION CONTROL BOX CAPACITOR - STARTING CAPACITOR STRAP STARTER MAGNETIC CONTACTOR BRACKET CAPACITOR BUSHING BUSHING TRANSFORMER CLAMP CONTROLLER BOARD BOARD SUPPORT CONTROL LABEL THERMOSTAT TOGGLE SWITCH 3P PLUG HOUSING 2P PLUG HOUSING 3P RECEPTACLE HOUSING D. CONTROL BOX ASSEMBLY TITLE MATERIAL PART...
  • Page 68 KM-1200SRE MODEL INDEX DESCRIPTION 2P RECEPTACLE HOUSING BUSHING 2P PLUG HOUSING 2P RECEPTACLE HOUSING BUSHING D. CONTROL BOX ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER B-1 C-0 C-1 D-0 E-0 E-1 F-0 3191-02R1 412831-07 OCB-500 428394-02 3190-02P 412832-09 (RED) 3191-02RI 412831-09 (RED) OCB-750...

  • Page 69: Label Location

    KM-1200SAE E. LABEL LOCATION B-1, C-0, C-1, D-0, E-0, E-1, F-0, F-1, G-0, G-1...
  • Page 70 KM-1200SAE E. LABEL LOCATION...
  • Page 71 MODEL INDEX DESCRIPTION EMBLEM (L) - HOSHIZAKI EMBLEM MODEL NUMBER LABEL LABEL - PENGUIN (R) LABEL - AIR FILTER MAINTENANCE LABEL WARNING LABEL CAUTION LABEL (K) LABEL - R22 NAMEPLATE WIRING LABEL MANUAL LABEL MANUAL LABEL - BIN CONTROL OPERATION LABEL - VALVE PVC FILM...
  • Page 72 KM-1200SWE E. LABEL LOCATION B-1, C-0, C-1, D-0, E-0, E-1, F-0, F-1...
  • Page 73 KM-1200SWE E. LABEL LOCATION F-1, G-0, G-1, H-0...
  • Page 74 KM-1200SWE E. LABEL LOCATION...
  • Page 75 MODEL INDEX DESCRIPTION EMBLEM (L) - HOSHIZAKI EMBLEM MODEL NUMBER LABEL LABEL - PENGUIN (R) MAINTENANCE LABEL WARNING LABEL - DANGER PVC FILM CAUTION LABEL (K) LABEL - R22 NAMEPLATE WIRING LABEL MANUAL LABEL MANUAL LABEL - BIN CONTROL OPERATION LABEL - VALVE PVC FILM...
  • Page 76 KM-1200SRE E. LABEL LOCATION B-1, C-0, C-1...
  • Page 77 KM-1200SRE E. LABEL LOCATION D-0, E-0, E-1, F-0...
  • Page 78 KM-1200SRE E. LABEL LOCATION F-1, G-0, G-1...
  • Page 79 KM-1200SRE E. LABEL LOCATION...
  • Page 80 MODEL INDEX DESCRIPTION EMBLEM (L) - HOSHIZAKI EMBLEM MODEL NUMBER LABEL LABEL - PENGUIN (R) MAINTENANCE LABEL WARNING LABEL - DANGER PVC FILM CAUTION LABEL (K) LABEL - R22 LABEL - CHARGE NAMEPLATE WIRING LABEL MANUAL LABEL MANUAL LABEL - BIN...
  • Page 81 KM-1200SAE, SWE, SRE F. EVAPORATOR...
  • Page 82 KM-1200SAE, SWE, SRE F. EVAPORATOR C-0, C-1, D-0, E-0, E-1, F-0, F-1, G-0, G-1, H-0, H-1...
  • Page 83 KM-1200SAE, SWE, SRE MODEL INDEX DESCRIPTION EVAPORATOR EVAP. BRACKET (A) EVAP. BRACKET (B) END PLATE (A) END PLATE (B) HOOK EVAP. BRACKET COPPER TUBE TITLE MATERIAL PART OR MODEL NUMBER B-1 C-0 C-1 D-0 E-0 E-1 F-0 (S-0533) 103444G02 323690-01...

  • Page 84: Pump Motor Assembly

    KM-1200SAE, SWE, SRE G. PUMP MOTOR ASSEMBLY B-1, C-0, C-1, D-0, E-0, E-1, F-0, F-1, G-0, G-1, H-0, H-1,...
  • Page 85 KM-1200SAE, SWE, SRE MODEL INDEX DESCRIPTION PUMP MOTOR PUMP FLANGE PUMP MOTOR BRACKET MECHANICAL SEAL PACKING IMPELLER PUMP HOUSING F. PUMP MOTOR ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER B-1 C-0 C-1 D-0 E-0 E-1 F-0 2U0106-01 M91A60SP201 215662-01 323904-01...
  • Page 86 KM-1200SAE, SWE, SRE H. ACCESSORIES...
  • Page 87 KM-1200SAE, SWE, SRE H. ACCESSORIES...
  • Page 88 KM-1200SAE, SWE, SRE H. ACCESSORIES C-1, D-0, E-0, E-1...
  • Page 89 KM-1200SAE, MWE, MRE H. ACCESSORIES F-0, F-1, G-0, G-1, H-0, H-1...
  • Page 90 KM-1200SAE, SWE, SRE MODEL INDEX DESCRIPTION INSTRUCTION MANUAL REDUCER BUSHING BRACE UNIVERSAL BRACE CHECK VALVE ELBOW NIPPLE THUMBSCREW THERMOSTAT EXTENSION BRACKET TITLE MATERIAL PART OR MODEL NUMBER B-1 C-0 C-1 D-0 E-0 PAPER 91U1JN10A PAPER 91U1JN10B PAPER 91U1JN10C 4A0169-01 4A0138-01...
