Washing Manual
with refurbishment information
for Netti manual wheelchairs
SM0034 UK 2022-05
My-Netti.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Netti 4U CED XL and is the answer not in the manual?

Questions and answers

Related Manuals for Alu Rehab Netti 4U CED XL

Summary of Contents for Alu Rehab Netti 4U CED XL

  • Page 1 Washing Manual with refurbishment information for Netti manual wheelchairs SM0034 UK 2022-05 My-Netti.com...
  • Page 2 New parts /spare parts, paint, new cushions and upholstery and new wheels can be purchased at Wheelchair in hospitals - Alu Rehab so that even a worn wheelchair can be frequent change of user - risk for infections. reused after proper refurbishment.

  • Page 3: Table Of Contents

    INDEX This Manual is divided into four grades of washing methods of the Wheelchair depending on cleaning needs. GRADE 1 CLEANING PROCEDURE - ONE USER - PRIVATE SURROUNDINGS Wheelchair .......... page 4 Seating system ........page 4 GRADE 2 CLEANING PROCEDURE - ONE USER - CARE INSTITUTIONS Wheelchair ..........

  • Page 4: Wheelchair

    Machine wash 60ºC Machine wash 60ºC Drying Tumble Dry max 85ºC Tumble Dry max 85ºC CORE All Alu Rehab Back Rest Cushions are processed in the same way. Wash No wash Disinfection Virkon S Autoclave 105ºC Drying Shake (clench), Air Dry vertical.

  • Page 5: Wheelchair

    GRADE 2 CLEANING PROCEDURE FOR WHEELCHAIR ONE USER - CARE INSTITUTIONS FREQUENCY: 2 TIMES A MONTH OR MORE DEPENDING ON USE AND NEED Remove back and seat cushion before washing. Please note the position of the cushions. They must be installed at same position and height after cleaning when the same user receives the chair back.

  • Page 6: Wheelchair

    GRADE 3 CLEANING PROCEDURE FOR WHEELCHAIRS FREQUENT CHANGE OF USERS - INSTITUTIONS FREQUENCY: FOR EVERY NEW USER OR MINIMUM 2 TIMES A MONTH Remove back cushion, seat cushion, high adjustable push handles, seat plate and arm support before washing. The removed parts are to be cleansed by sponge and mild detergent. Clean the wheelchair by sponge and mild detergent.

  • Page 7: Wheelchair - Hand Wash

    GRADE 4 A CLEANING PROCEDURE FOR WHEELCHAIRS FREQUENT CHANGE OF USERS - HOSPITALS FREQUENCY: FOR EVERY NEW USER OR MINIMUM 2 TIMES A MONTH HAND WASH PROCEDURE: Remove back cushion, seat cushion, high adjustable push handles, seat plate and arm support before washing.

  • Page 8: Wheelchair - Machine Wash

    GRADE 4 B CLEANING PROCEDURE FOR WHEELCHAIRS FREQUENT CHANGE OF USERS - HOSPITALS FREQUENCY: FOR EVERY NEW USER OR MINIMUM 2 TIMES A MONTH MACHINE WASH PROCEDURE: Remove back cushion, seat cushion, high adjustable push handles, seat plate and arm support before washing.

  • Page 9: Refurbishment Procedure

    REFURBISHMENT PROCEDURE Before working on the wheelchair it is advisable to place the wheelchair on a raised table or bench giv- ing an ergonomically correct position, avoiding any unnecessary lift. Use recommended, high quality tools and refer to the User Manual that can be downloaded from our home page www.My-Netti.com. Clean the Wheelchair - see Cleaning Procedure Page 4, difficult stains remaining after the cleaning process can be removed with methylated spirit.

  • Page 10: Arm Rest

    • ARM SUPPORTS - NETTI III: Arm support pad Check that the lock track is cleaned. Ensure that the position screw is mounted and in the correct posi- tion. Check that the arm support pads are mounted with two screws on each side, check that the screws are tight.

  • Page 11: Seating Unit

    (see User Manual for correct adjustment). Profile tube Lock • GENERAL INFORMATION: Use Alu Rehab AS original parts only. Use light Lock bicycle oil on moveable parts and bearings. Spring Use HHS Lube (Wurth) on Gas Springs. Spring Lock...

  • Page 12: Function Check

    FUNCTION CHECK BEFORE DELIVERY TO USER/CUSTOMER Check that the wheelchair is adjusted according to order. Visual check: – All pins, plugs and screws are correctly fitted. – Check the sewing in the Velcro back, no loose threads shall be seen. –...
  • Page 13 Function Model Test/check Done/OK Bearing All models except Ensure the bearing housing is adjusted in posi- housing Netti 4U FAMILY tion vertical to the horizontal ground. Front All wheelchair models The front castors quick release should operate castors freely on and off and lock them in the secure position.
  • Page 14 RECEIPT FORM FOR EXECUTED WASHING AND REFURBISHMENT PROCEDURE • Frame number/serial number: • PROCEDURE EXECUTED OK: • Cleaning procedure • Refurbishment procedure • Function control All the points above have been executed and the wheelchair is ready for delivery Company name: Technician: ................
  • Page 15 • PROCEDURE EXECUTED OK: • Cleaning procedure • Refurbishment procedure • Function control All the points above have been executed and the wheelchair is ready for delivery Place and date: Technician: ................................ • PROCEDURE EXECUTED OK: • Cleaning procedure •...
  • Page 16 Manufacturer: Alu Rehab AS Bedriftsvegen 23 N-4353 Klepp Stasjon Norway post@My-Netti.com T: +47 51 78 62 20 my-netti.no Distributor Distributor Distributor Alu Rehab ApS Meyra GmbH MDH Sp. zo.o. Kløftehøj 8 Meyra-Ring 2 ul. W. Tymienieckiego 22/24 DK-8680 Ry D-32689 Kalletal 90-349 tódz...
