Black Floating Speaker Floor Stand
Instruction Manual
SKU: STAND-TEN02B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-ten02b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-TEN02B
Summary of Contents for Vivo STAND-TEN02B
- Page 1 Black Floating Speaker Floor Stand Instruction Manual SKU: STAND-TEN02B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-ten02b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 ASSEMBLY STEPS STEP 1 Mount Base Support Bar (C) to Base (B) using M6x25mm Screws (S-B) and tighten using 5mm Allen Wrench (T-A). STEP 2 Mount Shelf Support Bar (D) to Shelf (A) using M5x30mm Screws (S-C) and tighten using Phillips end of the 5mm Allen Wrench (T-A).
- Page 4 STEP 3 Insert the Binding Barrels (S-A) into the top of Shelf (A) and attach the short threads of Outer Cables (F) to Binding Barrels (S-A). Attach the long threads of Outer Cables (F) to the top of Base (B).
- Page 5 STEP 4 Attach Inner Cable (E) into the bottom of Base Support Bar (C). Tighten Inner Cable (E) using M8 Wrench (T-B).
- Page 6 STEP 5 Attach Inner Cable (E) into the top of Shelf Support Bar (D). Tighten Inner Cable (E) using M8 Wrench (T-B). If Cable does not easily reach, partially loosen from Base Support Bar (C) until Cable threads into Shelf Support Bar (D), then retighten.
- Page 7 STEP 6 Apply Soft Pads (G) to the underside of Base (B).
