User Manual
Smart Touch Lamp Speaker
BT FM
SD
SPK-V01
Packing list
Speaker User Manual
3.5mm Audio Cable USB Cable
Introduction
Smart touch lamp speaker is a product which integrates a touch sensitive lamp and
Bluetooth speaker. The touchable lamp can be easily switched on/off and adjusted to
different brightness levels by a hand touch at the top-center of the product. The Bluetooth
speaker is a smart device which combines audio player (Bluetooth mode, SD mode, Line In
mode), FM player, and clock functions. Please check the detailed operations of each
function in the Specifications. For operation, please refer to the Operating Instructions.
Specifications
Product Name: Smart touch lamp speaker
Model No.: SPK-V01
Power Input: Micro USB,DC5V 1000mA
Battery Capacity: 3.7V/2000mA
Charging Time: 2.5-4hours
Speaker Specification: 2.5Inch,4ohm/5W
Frequency Response: 70Hz-20KHz
Distortion: ≤0.5%
Signal to Noise Ratio: ≥65db
Material: ABS/Silica-gel
Music Playing Time: 15 hours at volume level 15.
Lighting Time: 15 hours at the lowest brightness.
Button Functions
1
2
6
3
5
4
7
8
9
Note: LED display will be off after 5min
12
17
16
13
14
15
Button/Indicator List
1 Power Switch: Used to cut off power supply for safety purposes in delivery.
The product will not get power when this switch is off.
2 Alarm Set: Enter alarm set mode.
3 Sleep Indicator: It will light when sleep mode is turned on.
4
Sleep: Turn on/off automatic sleep mode.
5
Alarm On: Turn on/off the alarm.
6 Clock Set: Enter clock set mode.
7
Charging Port: Micro USB port for power input.
8
Charging Indicator: To show if battery's charging
9 TF Port: Port to insert TF card.
10 Line In: 3.5mm port to connect line in signal.
11
Micro Phone: Micro phone for hand free call in bluetooth mode.
12
LED Display
13 Mode: Switch speaker to different modes (bluetooth, TF, line in, FM tuner).
14 : Play back/volume down/number down.
15
: Play forward/volume up/number up.
16 : Play/pause/answer phone
1 1
17 ON/OFF: Switch to active/sleep mode.
10
Song Length
TF Card Mode
if no touch to the product.
