1 Description
The TD433 Series Transmitters are ideal for the opening of automatic doors. The Transmitter is available in hand-held or pushplate style
and transmits a unique rolling code each time the switch is closed to provide a secure door-opening signal. The transmitter is powered by
either a 3-volt or a standard 9-volt battery and a red indicator light when the transmitter is activated.
10TD433HH - ONE BUTTON
10TD433PB3V - ONE BUTTON, 3 VOLT w / WIRE LEADS
2 Specifi cations
DESCRIPTION
FREQUENCY
EMMITTED RADIO POWER
POWER CONSUMPTION
OPERATING TEMPERATURE
DIMENSIONS
CERTIFICATIONS
3 Battery Replacement
1. Remove screw from back of transmitter.
2. Separate housing and install a fresh 3-Volt (Type CR2032)
battery making sure to observe properly polarity.
3. Reassemble housing and replace screw.
75.0057.09 20070827
10TD433HH2 - TWO BUTTON
SPECIFICATION
433 FHz
250mA
14ºF TO 131ºF (-10ºC TO 55ºC)
2. 3/4" X 1 3/8" X 9/16" (70mm x 35mm x 14mm)
, FCC, IC
433 MHz TRANSMITTERS
HAND HELD DIGITAL TRANSMITTER
10TD433HH3 - THREE BUTTON
10TD433PB9V - ONE BUTTON, 9 VOLT w / WIRE LEADS
USER'S GUIDE
10TD433HH4 - FOUR BUTTON
Page 1 of 2
Advertisement
Table of Contents
Related Manuals for BEA TD433 Series
Summary of Contents for BEA TD433 Series
- Page 1 1 Description The TD433 Series Transmitters are ideal for the opening of automatic doors. The Transmitter is available in hand-held or pushplate style and transmits a unique rolling code each time the switch is closed to provide a secure door-opening signal. The transmitter is powered by either a 3-volt or a standard 9-volt battery and a red indicator light when the transmitter is activated.
- Page 2 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. • Changes or modifi cations not expressly approved by BEA, Inc. for compliance could void the user’s authority to operate the equipment. 5 Precautions Shut off all power going to header before attempting any wiring procedures.
