900 MHZ RECEIVER & INDUSTRIAL TRANSMITTERS
DESCRIPTION
1
6
1. receiver (10RD900)
2. antenna wire
3. blue activation LED
4. red learn LED
5. tri-color signal strength LED
NEMA 4 HAND HELD TRANSMITTERS
1 BUTTON
(10TD900INDHH1)
This product is NOT intended for use directly with Magnetic Locks or Electric Strikes.
Contact BEA Technical Support for further information.
75.5858.02 900 MHZ INDUSTRIAL 20160419
75.5858.02 900 MHZ INDUSTRIAL 20160419
3
4
5
8
9
7
2 BUTTON
(10TD900INDHH2)
IMPORTANT:
Digital receiver and industrial transmitter
with frequency hopping, sequencing and
extended hold functionality
(US version)
2
7. no-delay learn button
8. delay learn button
9. delay learn potentiometer
10. NEMA 4 1-button transmitter
11. belt clip (10BELTCLIP)
3 BUTTON
(10TD900INDHH3)
10
11
4 BUTTON
(10TD900INDHH4)
Page 1 of 4
Page 1 of 4
Advertisement
Table of Contents
Related Manuals for BEA 10TD900INDHH1
Summary of Contents for BEA 10TD900INDHH1
- Page 1 (10TD900INDHH3) (10TD900INDHH4) IMPORTANT: This product is NOT intended for use directly with Magnetic Locks or Electric Strikes. Contact BEA Technical Support for further information. 75.5858.02 900 MHZ INDUSTRIAL 20160419 75.5858.02 900 MHZ INDUSTRIAL 20160419 Page 1 of 4 Page 1 of 4...
- Page 2 Ensure compliance with all applicable safety standards (i.e. ANSI A156.10) upon completion of installation. DO NOT attempt any internal repair of the components. All repairs and/or component replacements must be performed by BEA, Inc. Unauthorized disassembly or repair: 1. May jeopardize personal safety and may expose one to the risk of electrical shock.
- Page 3 Removing Transmitters Single Transmitter All Transmitters Press BOTH learn buttons until Press transmiter TWICE within Press BOTH learn buttons until red LED flashes once (~2 s). 10 seconds. blue LED illuminates (~10 s). Battery Replacement Handheld (TD900INDHHx) Remove back three (3) screws Replace two (2) 3V (CR2032) batteries and disassemble.
- Page 4 If you are not an AAADM certifi ed inspector, BEA strongly recommends you have an AAADM certifi ed inspector perform an AAADM inspection and place a valid inspection sticker below the safety information label prior to putting the equipment into operation.
