MODULAR FLAKER
F-1001MAH(-C) (-22C)
F-1001MWH(-C)
F-1001MRH(-C)
F-1001MLH(-C)
HOSHIZAKI
MODEL
PARTS LIST
NO.
71196
ISSUED:
OCT. 29, 2001
NOV. 21, 2000
REVISED:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F-1001MAH and is the answer not in the manual?

Questions and answers

Related Manuals for Hoshizaki F-1001MAH

Summary of Contents for Hoshizaki F-1001MAH

  • Page 1 HOSHIZAKI MODULAR FLAKER F-1001MAH(-C) (-22C) F-1001MWH(-C) F-1001MRH(-C) F-1001MLH(-C) PARTS LIST MODEL 71196 ISSUED: OCT. 29, 2001 NOV. 21, 2000 REVISED:...
  • Page 2 F-1001MAH March, 2001 F-1001MAH-C April, 2001 F-1001MAH-22C March, 2001 F-1001MWH March, 2001 F-1001MWH-C June, 2001 F-1001MRH May, 2001 F-1001MRH-C July, 2001 F-1001MLH July, 2001 F-1001MLH-C...
  • Page 3 ALUMINUM Aluminum COPPER Copper PLASTIC Acrylonitritrile -butadiene - styrene Polyacetal Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PTFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride RUBBER Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene SI.R...
  • Page 4 F-1001MAH(-C) A. ICE FLAKER ASSEMBLY...
  • Page 5 F-1001MAH MODEL INDEX DESCRIPTION ICE MAKING UNIT SOCKET HEAD HEX BOLT SPLIT LOCK WASHER REFRIGERATION UNIT WATER CIRCUIT CONTROL BOX ASSEMBLY TRUSS HEAD SCREW CHUTE ASSEMBLY LABEL LOCATION A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER...
  • Page 6 F-1001MAH-C MODEL INDEX DESCRIPTION ICE MAKING UNIT SOCKET HEAD HEX BOLT SPLIT LOCK WASHER REFRIGERATION UNIT WATER CIRCUIT CONTROL BOX ASSEMBLY TRUSS HEAD SCREW CHUTE ASSEMBLY LABEL LOCATION A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER...
  • Page 7 F-1001MAH(-C) MODEL INDEX DESCRIPTION CHASSIS REAR PANEL T2 SCREW JUNCTION BOX COVER T2 SCREW SIDE FRAME (R) TRUSS HEAD SCREW FRONT FRAME TRUSS HEAD SCREW RESERVOIR BRACKET T2 SCREW DRAIN PAN STRAP T3 SCREW PUSH RETAINER CLAMP BUSHING RING “O” RING...
  • Page 8 F-1001MAH(-C) MODEL INDEX DESCRIPTION SCREW-GROUNDING SIDE PANEL (RIGHT) TRUSS HEAD SCREW SIDE PANEL (LEFT) TRUSS HEAD SCREW TOP PANEL FRONT PANEL LOUVER (B) AIR FILTER (B) CABLE TIE SQUARE WASHER TRUSS HEAD SCREW BRACKET-CHUTE A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR...
  • Page 9 F-1001MAH-22C A. ICE FLAKER ASSEMBLY...
  • Page 10 F-1001MAH-22C MODEL INDEX DESCRIPTION ICE MAKING UNIT SOCKET HEAD HEX BOLT SPLIT LOCK WASHER REFRIGERATION UNIT WATER CIRCUIT CONTROL BOX ASSEMBLY TRUSS HEAD SCREW CHUTE ASSEMBLY LABEL LOCATION A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR PART MODEL NUMBER NUMBER 3A1600A02...
  • Page 11 F-1001MAH-22C MODEL INDEX DESCRIPTION CHASSIS REAR PANEL T2 SCREW JUNCTION BOX COVER T2 SCREW SIDE FRAME (R) TRUSS HEAD SCREW FRONT FRAME TRUSS HEAD SCREW RESERVOIR BRACKET T2 SCREW DRAIN PAN STRAP T3 SCREW PUSH RETAINER CLAMP BUSHING RING “O”RING...
  • Page 12 F-1001MAH-22C MODEL INDEX DESCRIPTION SCREW-GROUNDING SIDE PANEL (RIGHT) TRUSS HEAD SCREW SIDE PANEL (LEFT) TRUSS HEAD SCREW TOP PANEL FRONT PANEL LOUVER (B) AIR FILTER (B) CABLE TIE SQUARE WASHER TRUSS HEAD SCREW BRACKET-CHUTE A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR...
  • Page 13 F-1001MWH(-C) A. ICE FLAKER ASSEMBLY...
  • Page 14 F-1001MWH MODEL INDEX DESCRIPTION ICE MAKING UNIT SOCKET HEAD HEX BOLT SPLIT LOCK WASHER REFRIGERATION UNIT WATER CIRCUIT CONTROL BOX ASSEMBLY TRUSS HEAD SCREW CHUTE ASSEMBLY LABEL LOCATION A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER 3A1600A01 8X110, SS...
  • Page 15 F-1001MWH-C MODEL INDEX DESCRIPTION ICE MAKING UNIT SOCKET HEAD HEX BOLT SPLIT LOCK WASHER REFRIGERATION UNIT WATER CIRCUIT CONTROL BOX ASSEMBLY TRUSS HEAD SCREW CHUTE ASSEMBLY LABEL LOCATION A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER 3A1600A02 8X110, SS...
  • Page 16 F-1001MWH(-C) MODEL INDEX DESCRIPTION CHASSIS REAR PANEL T2 SCREW JUNCTION BOX COVER T2 SCREW SIDE FRAME (R) TRUSS HEAD SCREW FRONT FRAME TRUSS HEAD SCREW RESERVOIR BRACKET T2 SCREW DRAIN PAN STRAP T3 SCREW CLAMP LOUVER (A) RING “O” RING PACKING-SPOUT SPOUT THUMBSCREW...
  • Page 17 F-1001MWH(-C) MODEL INDEX DESCRIPTION SQUARE WASHER TRUSS HEAD SCREW SCREW-GROUNDING SIDE PANEL (RIGHT) TRUSS HEAD SCREW SIDE PANEL (LEFT) TRUSS HEAD SCREW TOP PANEL FRONT PANEL WIRE SADDLE BRACKET-CHUTE AIR FILTER (A) A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER...
  • Page 18 F-1001MRH(-C) A. ICE FLAKER ASSEMBLY...
  • Page 19 F-1001MRH MODEL INDEX DESCRIPTION ICE MAKING UNIT SOCKET HEAD HEX BOLT SPLIT LOCK WASHER REFRIGERATION UNIT WATER CIRCUIT CONTROL BOX ASSEMBLY TRUSS HEAD SCREW CHUTE ASSEMBLY LABEL LOCATION A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER 3A1600A01 8X110, SS...
  • Page 20 F-1001MRH-C MODEL INDEX DESCRIPTION ICE MAKING UNIT SOCKET HEAD HEX BOLT SPLIT LOCK WASHER REFRIGERATION UNIT WATER CIRCUIT CONTROL BOX ASSEMBLY TRUSS HEAD SCREW CHUTE ASSEMBLY LABEL LOCATION A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER 3A1600A02 8X110, SS...
  • Page 21 F-1001MRH(-C) MODEL INDEX DESCRIPTION CHASSIS REAR PANEL T2 SCREW JUNCTION BOX COVER T2 SCREW SIDE FRAME (R) TRUSS HEAD SCREW FRONT FRAME TRUSS HEAD SCREW RESERVOIR BRACKET T2 SCREW DRAIN PAN STRAP T3 SCREW CLAMP LOUVER (A) RING "O" RING PACKING-SPOUT SPOUT THUMBSCREW...
  • Page 22 F-1001MRF(-C) MODEL INDEX DESCRIPTION SCREW-GROUNDING SIDE PANEL (RIGHT) TRUSS HEAD SCREW SIDE PANEL (LEFT) TRUSS HEAD SCREW TOP PANEL FRONT PANEL WIRE SADDLE BRACKET-CHUTE A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR PART MODEL NUMBER NUMBER BRASS 433304-02 2A1845G01 4X8, SS 7C32-0408 2A1846G01 4X8, SS...
  • Page 23 F-1001MLH(-C) A. ICE FLAKER ASSEMBLY...
  • Page 24 F-1001MLH MODEL INDEX DESCRIPTION ICE MAKING UNIT SOCKET HEAD HEX BOLT SPLIT LOCK WASHER REFRIGERATION UNIT WATER CIRCUIT CONTROL BOX ASSEMBLY TRUSS HEAD SCREW CHUTE ASSEMBLY LABEL LOCATION A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER 3A1600A01 8X110, SS...
  • Page 25 F-1001MLH-C MODEL INDEX DESCRIPTION ICE MAKING UNIT SOCKET HEAD HEX BOLT SPLIT LOCK WASHER REFRIGERATION UNIT WATER CIRCUIT CONTROL BOX ASSEMBLY TRUSS HEAD SCREW CHUTE ASSEMBLY LABEL LOCATION A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER 3A1600A02 8X110, SS...
  • Page 26 F-1001MLH(-C) MODEL INDEX DESCRIPTION CHASSIS REAR PANEL T2 SCREW JUNCTION BOX COVER T2 SCREW SIDE FRAME (R) TRUSS HEAD SCREW FRONT FRAME TRUSS HEAD SCREW RESERVOIR BRACKET T2 SCREW DRAIN PAN STRAP T3 SCREW CLAMP LOUVER (A) RING “O” RING PACKING-SPOUT SPOUT THUMBSCREW...
  • Page 27 F-1001MLH(-C) MODEL INDEX DESCRIPTION SCREW-GROUNDING SIDE PANEL (RIGHT) TRUSS HEAD SCREW SIDE PANEL (LEFT) TRUSS HEAD SCREW TOP PANEL FRONT PANEL WIRE SADDLE BRACKET-CHUTE FILTER (A) A. ICE FLAKER ASSEMBLY TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER BRASS 433304-02 2A2073G01 4X8, SS...
  • Page 28 F-1001MAH, MWH, MRH, MLH B. ICE MAKING UNIT...
  • Page 29 F-1001MAH, MWH, MRH, MLH MODEL INDEX DESCRIPTION GEAR MOTOR BARRIER - GEAR MOTOR TRUSS HEAD SCREW COUPLING - SPLINE HOUSING “O” RING MECHANICAL SEAL AUGER EVAPORATOR SOCKET HEAD CAP SCREW SPLIT LOCK WASHER EXTRUDING HEAD / 70F SOCKET HEAD CAP SCREW...
  • Page 30 F-1001MAH-C, MWH-C, MRH-C, MLH-C B. ICE MAKING UNIT F-1001MAH-22C...
  • Page 31 F-1001MAH-C, MWH-C, MRH-C, MLH-C, F-1001MAH-22C MODEL INDEX DESCRIPTION GEAR MOTOR BARRIER - GEAR MOTOR TRUSS HEAD SCREW COUPLING - SPLINE HOUSING “O” RING MECHANICAL SEAL AUGER EVAPORATOR SOCKET HEAD CAP SCREW SPLIT LOCK WASHER EXTRUDING HEAD / 70F SOCKET HEAD CAP SCREW...
  • Page 32 F-1001MAH(-C) C. REFRIGERATION UNIT...
  • Page 33 F-1001MAH(-C) MODEL INDEX DESCRIPTION COMPRESSOR BOLT CONDENSER-AIR COOLED FT SCREW SHROUD T2 SCREW FAN MOTOR BRACKET HEX HEAD BOLT W/WASHER FAN MOTOR FAN BLADE DRIER COPPER TUBE (A) - HIGH SIDE COPPER TUBE (B) -HIGH SIDE COPPER TUBE-PROCESS CLAMP COPPER TUBE - HEAT EXCHANGER EXPANSION VALVE EXP.
  • Page 34 F-1001MAH(-C) MODEL INDEX DESCRIPTION DRIER BRACKET FT SCREW TERMINAL COVER SPRING CLIP C. REFRIGERATION UNIT TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER 445847-01 7F31-0408 111-2 436000-01 4A1322F01 4A1322F02...
  • Page 35 F-1001MAH-22C C. REFRIGERATION UNIT...
  • Page 36 F-1001MAH-22C MODEL INDEX DESCRIPTION COMPRESSOR BOLT CONDENSER-AIR COOLED FT SCREW SHROUD T2 SCREW FAN MOTOR BRACKET HEX HEAD BOLT W/WASHER FAN MOTOR FAN BLADE DRIER COPPER TUBE(A)-HIGH SIDE COPPER TUBE(B)-HIGH SIDE CLAMP COPPER TUBE-LOW SIDE EXPANSION VALVE EXP. VALVE COVER(A)
  • Page 37 F-1001MAH-22C MODEL INDEX DESCRIPTION DRIER BRACKET FT SCREW EXP. VALVE COVER(B) SOCKET C. REFRIGERATION UNIT TITLE MATERIAL OR PART MODEL NUMBER NUMBER 445847-01 7F31-0408 PE FOAM 3A0555-02 COPPER 436578-01 REQUIRED NUMBER...
  • Page 38 F-1001MWH(-C) C. REFRIGERATION UNIT...
  • Page 39 F-1001MWH(-C) MODEL INDEX DESCRIPTION COMPRESSOR CONDENSER-WATER COOLED HEX BOLT W/WASHER (LF) WATER REGULATOR TRUSS HEAD SCREW TERMINAL COVER DRIER COPPER TUBE (A) - HIGH SIDE COPPER TUBE (B) - HIGH SIDE COPPER TUBE - ACCESS VALVE CLAMP COPPER TUBE - HEAT EXCHANGER EXPANSION VALVE DRIER BRACKET FT SCREW...
  • Page 40 F-1001MWH(-C) MODEL INDEX DESCRIPTION HOLDER/EXP. VALVE-1/2 WASHER MALE CONNECTOR SPRING CLIP C. REFRIGERATION UNIT TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER 3A0112-01 4A0655-03 111-2 436000-01 48F-8-6 4A1087-01 4A1322F02...
  • Page 41 F-1001MRH(-C) C. REFRIGERATION UNIT...
  • Page 42 F-1001MRH(-C) MODEL INDEX DESCRIPTION COMPRESSOR CLAMP CRANKCASE HEATER RECEIVER TANK FT SCREW DRIER COPPER TUBE(A)- HIGH SIDE COPPER TUBE (B) - HIGH SIDE COPPER TUBE(C)- HIGH SIDE COPPER TUBE(D)- HIGH SIDE COUPLING CABLE TIE TUBE HOLDER - S T2 SCREW COPPER TUBE - HEAT EXCHANGER EXPANSION VALVE EXP.
  • Page 43 F-1001MRH(-C) MODEL INDEX DESCRIPTION DRIER BRACKET FT SCREW HOLDER/EXP.VALVE-1/2 TERMINAL COVER SPRING CLIP INSULATION TUBE C. REFRIGERATION UNIT TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER 4A1348-01 4X8, SS 7F32-0408 3A0112-01 4A1322F01 4A1322F02 L=400 7762-0717...
  • Page 44 F-1001MLH(-C) C. REFRIGERATION UNIT...
  • Page 45 F-1001MLH(-C) MODEL INDEX DESCRIPTION EPR VALVE EPR VALVE COVER COPPER TUBE - (OUT) COPPER TUBE - (IN) COPPER TUBE-HEAT EXCHANGER SOLENOID VALVE TRUSS HEAD HEAT EXCHANGER EXPANSION VALVE EXPANSION VALVE COVER HOT GAS VALVE BRACKET VALVE BODY COIL - VALVE BOLT COUPLING-(MALE) COUPLING...
  • Page 46 F-1001MLH(-C) MODEL INDEX DESCRIPTION COPPER TUBE - EXP. VALVE COPPER TUBE - EPR TRUSS HEAD SCREW INSULATION TUBE INSULATION TUBE INSULATION TUBE INSULATION TUBE INSULATION TUBE INSULATION TUBE INSULATION TUBE INSULATION TUBE INSULATION TUBE C. REFRIGERATION UNIT TITLE MATERIAL OR PART REQUIRED NUMBER MODEL...
  • Page 47 F-1001MAH(-C), MWH(-C), MRH(-C), MLH(-C) D. WATER CIRCUIT F-1001MAH-22C...
  • Page 48 F-1001MAH(-C), MWH(-C), MRH(-C), MLH(-C), F-1001MAH-22C MODEL INDEX DESCRIPTION WATER SUPPLY PIPE T2 SCREW WASHER WATER VALVE T2 SCREW RESERVOIR SEPARATOR-RESERVOIR FLOAT SWITCH RESERVOIR COVER INLET- RESERVOIR WATER VALVE T2 SCREW VINYL HOSE CLAMP CLAMP CABLE TIE CLAMP FITTING T2 SCREW...
  • Page 49 F-1001MAH(-C), MWH(-C), MRH(-C), MLH(-C), F-1001MAH-22C MODEL INDEX DESCRIPTION HOSE CLAMP HOSE CLAMP HOSE CLAMP D. WATER CIRCUIT TITLE MATERIAL OR PART MODEL NUMBER NUMBER 4A2017-06 4A2017-01 4A2017-02 REQUIRED NUMBER...
  • Page 50 F-1001MAH(-C), F-1001MAH-22C E. CONTROL BOX ASSEMBLY...
  • Page 51 F-1001MAH(-C), F-1001MAH-22C MODEL INDEX DESCRIPTION CONTROL BOX COVER-CONTROL BOX TRUSS HEAD SCREW RELAY RELAY TAPPING SCREW TRANSFORMER T2 SCREW STRAP T2 SCREW TIMER BOARD BOARD SUPPORT TOGGLE SWITCH FUSE HOLDER FUSE 12P PLUG HOUSING 6P PLUG HOUSING 4P PLUG HOUSING...
  • Page 52 F-1001MAH(-C), F-1001MAH-22C MODEL INDEX DESCRIPTION RELAY ROCKER SWITCH CAPACITOR - STARTING CAPACITOR SCREW E. CONTROL BOX ASSEMBLY TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER LY1F-HSD, 418271-05 AC220/240V 62111929-0-0-N 4A0558-01 3A0076-02 3535B5A0108A250B8 X386S(HG02) 439943-02 32 x 3/8 4A0898-01...
  • Page 53 F-1001MWH(-C), MRH(-C) E. CONTROL BOX ASSEMBLY...
  • Page 54 F-1001MWH(-C), MRH(-C) MODEL INDEX DESCRIPTION CONTROL BOX COVER-CONTROL BOX TRUSS HEAD SCREW RELAY RELAY TAPPING SCREW TRANSFORMER T2 SCREW STRAP T2 SCREW TIMER BOARD BOARD SUPPORT TOGGLE SWITCH FUSE HOLDER FUSE 12P PLUG HOUSING 6P PLUG HOUSING 4P PLUG HOUSING 3P PLUG HOUSING STARTER T2 SCREW...
  • Page 55 F-1001MWH(-C), MRH(-C) MODEL INDEX DESCRIPTION ROCKER SWITCH CAPACITOR - STARTING CAPACITOR SCREW E. CONTROL BOX ASSEMBLY TITLE MATERIAL OR PART REQUIRED NUMBER MODEL NUMBER NUMBER 62111929-0-0-N 4A0558-01 3A0076-02 3535B5A0108A250B8 X386S(HG02) 439943-02 32 x 3/8 4A0898-01...
  • Page 56 F-1001MLH(-C) E. CONTROL BOX ASSEMBLY...
  • Page 57 F-1001MLH(-C) MODEL INDEX DESCRIPTION CONTROL BOX COVER-CONTROL BOX TRUSS HEAD SCREW RELAY RELAY TAPPING SCREW TRANSFORMER T2 SCREW TIMER BOARD BOARD SUPPORT TOGGLE SWITCH FUSE HOLDER FUSE 12P PLUG HOUSING 3P PLUG HOUSING TIMER CAPACITOR (GM) T2 SCREW FUSE FUSE HOLDER RELAY ROCKER SWITCH SCREW...
  • Page 58 F-1001MAH(-C), MWH(-C), MRH(-C), MLH(-C) F. CHUTE ASSEMBLY F-1001MAH-22C...
  • Page 59 F-1001MAH(-C), MWH(-C), MRH(-C), MLH(-C), F-1001MAH-22C MODEL INDEX DESCRIPTION CHUTE INSULATION-CHUTE BAFFLE-CHUTE (A) WING NUT BAFFLE-CHUTE (B) BIN CONTROL ACTUATOR SHAFT SNAP PIN PROXIMITY SWITCH PACKING THUMBSCREW PLATE THUMBSCREW TRUSS HEAD SCREW F. CHUTE ASSEMBLY TITLE MATERIAL OR PART MODEL NUMBER...
  • Page 60 F-1001MAH(-C) G. LABEL LOCATION...
  • Page 61 F-1001MAH MODEL INDEX DESCRIPTION INSTRUCTION SHEET EMBLEM MODEL NUMBER LABEL LABEL-PENGUIN-HA-R RATING LABEL LABEL-AIR FILTER INSTRUCTION LABEL LABEL-CLEANING NAMEPLATE TAG-WARNING:ELECTRICAL CONNECTION CONTROL LABEL LABEL-R404A CAUTION LABEL (E) WIRING LABEL INSTRUCTION SHEET CAUTION LABEL (H) LABEL (GM) - FUSE G. LABEL LOCATION...
  • Page 62 F-1001MAH-C MODEL INDEX DESCRIPTION INSTRUCTION SHEET EMBLEM MODEL NUMBER LABEL LABEL-PENGUIN-HA-R RATING LABEL LABEL-AIR FILTER INSTRUCTION LABEL LABEL-CLEANING NAMEPLATE TAG-WARNING:ELECTRICAL CONNECTION CONTROL LABEL LABEL-R404A CAUTION LABEL (E) WIRING LABEL INSTRUCTION SHEET CAUTION LABEL (H) LABEL (GM) - FUSE G. LABEL LOCATION...
  • Page 63 F-1001MAH-22C G. LABEL LOCATION...
  • Page 64 F-1001MAH-22C MODEL INDEX DESCRIPTION INSTRUCTION SHEET EMBLEM MODEL NUMBER LABEL LABEL-PENGUIN-HA-R RATING LABEL LABEL-AIR FILTER INSTRUCTION LABEL LABEL-CLEANING NAMEPLATE TAG-WARNING: ELECTRICAL CONNECTION CONTROL LABEL LABEL-R22 CAUTION LABEL(E) WIRING LABEL INSTRUCTION SHEET CAUTION LABEL(H) LABEL(GM)-FUSE G. LABEL LOCATION TITLE MATERIAL OR...
  • Page 65 F-1001MWH(-C) G. LABEL LOCATION...
  • Page 66 F-1001MWH MODEL INDEX DESCRIPTION INSTRUCTION SHEET EMBLEM MODEL NUMBER LABEL LABEL-PENGUIN-HA-R RATING LABEL INSTRUCTION SHEET INSTRUCTION LABEL LABEL-CLEANING NAMEPLATE TAG-WARNING:ELECTRICAL CONNECTION CONTROL LABEL LABEL-R404A CAUTION LABEL (E) WIRING LABEL CAUTION LABEL (H) LABEL (GM) - FUSE G. LABEL LOCATION TITLE MATERIAL OR PART REQUIRED NUMBER...
  • Page 67 F-1001MWH-C MODEL INDEX DESCRIPTION INSTRUCTION SHEET EMBLEM MODEL NUMBER LABEL LABEL-PENGUIN-HA-R RATING LABEL INSTRUCTION SHEET INSTRUCTION LABEL LABEL-CLEANING NAMEPLATE TAG-WARNING:ELECTRICAL CONNECTION CONTROL LABEL LABEL-R404A CAUTION LABEL (E) WIRING LABEL CAUTION LABEL (H) LABEL (GM) - FUSE G. LABEL LOCATION TITLE MATERIAL OR PART REQUIRED NUMBER...
  • Page 68 F-1001MRH(-C) G. LABEL LOCATION...
  • Page 69 F-1001MRH MODEL INDEX DESCRIPTION INSTRUCTION SHEET EMBLEM MODEL NUMBER LABEL LABEL-PENGUIN-HA-R RATING LABEL LABEL-CHARGE INSTRUCTION LABEL LABEL-CLEANING NAMEPLATE TAG-WARNING: ELECTRICAL CONNECTION CONTROL LABEL LABEL-R404A WIRING LABEL CAUTION LABEL(E) CAUTION LABEL(H) INSTRUCTION SHEET TAG-FAN MOTOR LEADS CAUTION - REMOTE LABEL CAUTION TAPE - 404A LABEL (GM) - FUSE G.
  • Page 70 F-1001MRH-C MODEL INDEX DESCRIPTION INSTRUCTION SHEET EMBLEM MODEL NUMBER LABEL LABEL-PENGUIN-HA-R RATING LABEL LABEL-CHARGE INSTRUCTION LABEL LABEL-CLEANING NAMEPLATE TAG-WARNING: ELECTRICAL CONNECTION CONTROL LABEL LABEL-R404A WIRING LABEL CAUTION LABEL(E) CAUTION LABEL(H) INSTRUCTION SHEET TAG-FAN MOTOR LEADS CAUTION - REMOTE LABEL CAUTION TAPE - 404A LABEL (GM) - FUSE G.
  • Page 71 F-1001MLH(-C) G. LABEL LOCATION...
  • Page 72 F-1001MLH MODEL INDEX DESCRIPTION INSTRUCTION SHEET EMBLEM MODEL NUMBER LABEL LABEL-PENGUIN-HA-R RATING LABEL INSTRUCTION LABEL LABEL-CLEANING NAMEPLATE TAG-WARNING: ELECTRICAL CONNECTION CONTROL LABEL LABEL-R404A WIRING LABEL CAUTION LABEL(E) CAUTION LABEL(H) INSTRUCTION SHEET LABEL (GM) - FUSE G. LABEL LOCATION TITLE MATERIAL OR PART REQUIRED NUMBER MODEL...
  • Page 73 F-1001MLH-C MODEL INDEX DESCRIPTION INSTRUCTION SHEET EMBLEM MODEL NUMBER LABEL LABEL-PENGUIN-HA-R RATING LABEL INSTRUCTION LABEL LABEL-CLEANING NAMEPLATE TAG-WARNING: ELECTRICAL CONNECTION CONTROL LABEL LABEL-R404A WIRING LABEL CAUTION LABEL(E) CAUTION LABEL(H) INSTRUCTION SHEET LABEL (GM) - FUSE G. LABEL LOCATION TITLE MATERIAL OR PART REQUIRED NUMBER MODEL...
  • Page 74 F-1001MAH(-C), MWH(-C), MRH(-C), MLH(-C) H. ACCESSORIES F-1001MAH-22C...
  • Page 75 F-1001MAH(-C), MWH(-C), MRH(-C), MLH(-C), F-1001MAH-22C MODEL INDEX DESCRIPTION INSTRUCTION MANUAL UNIVERSAL BRACE HEX HEAD BOLT LABEL-FASTENER TRUSS HEAD SCREW H. ACCESSORIES TITLE MATERIAL OR PART MODEL NUMBER NUMBER PAPER 91A2LA10A 4A0363-01 SS, 5 x 12 7B02-0512 PAPER 427122-01 4X8, SS...
