CUBELET ICE DISPENSER
DCM-750BAF
DCM-750BWF
HOSHIZAKI
MODEL
PARTS LIST
NO.
June 9, 1999
ISSUED:
REVISED:
December 1, 2004
71137

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCM-750BAF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hoshizaki DCM-750BAF

Summary of Contents for Hoshizaki DCM-750BAF

  • Page 1 HOSHIZAKI CUBELET ICE DISPENSER DCM-750BAF DCM-750BWF PARTS LIST MODEL 71137 June 9, 1999 ISSUED: REVISED: December 1, 2004...

  • Page 2: Table Of Contents

    Auxiliary Codes ... 3 Material Abbreviations ... 5 A. Ice Dispenser Assembly ... 5 DCM-750BAF (1/2) ... 5 DCM-750BWF (1/2) ... 6 DCM-750BAF, DCM-750BWF (2/2) ... 7 B. Frame Assembly ... 12 DCM-750BAF ... 12 DCM-750BWF ... 14 C. Evaporator Assembly ... 16 DCM-750BAF, DCM-750BWF ...

  • Page 3: Auxiliary Codes

    Auxiliary Codes DCM-750BAF DCM-750BWF October 1998 December 1998 August 1999 November 1999 December 1999 August 2000 January 2001 November 2001 February 2002 January 2003 October 1998 December 1998 March 2000 August 2000 February 2002 February 2002 January 2003...

  • Page 4: Material Abbreviations

    Material Abbreviations Aluminum Aluminum Copper Copper Plastic Acrylonitrile -butadiene - styrene Polyacetal Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PTFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride Rubber Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene...

  • Page 5: Ice Dispenser Assembly

    A. Ice Dispenser Assembly DCM-750BAF (1/2) H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, N-0...

  • Page 6: Dcm-750Bwf (1/2)

    A. Ice Dispenser Assembly DCM-750BWF (1/2) H-0, J-0, K-0, K-1, M-0, M-1, N-0...

  • Page 7: Dcm-750Baf, Dcm-750Bwf (2/2)

    A. Ice Dispenser Assembly DCM-750BAF, DCM-750BWF (2/2) H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, M-1, N-0...
  • Page 8 Title: A. Ice Dispenser Assembly Model: DCM-750BAF Index Description FRAME ASSEMBLY EVAPORATOR ASSEMBLY SOCKET HEAD CAP SCREW SS, 8 X 110 SPLIT LOCK WASHER REFRIGERATION CIRCUIT WATER CIRCUIT MIDDLE FRONT PANEL ASSEMBLY TRUSS HEAD SCREW BIN ASSEMBLY TRUSS HEAD SCREW...
  • Page 9 Title: A. Ice Dispenser Assembly Model: DCM-750BAF Index Description BUSHING GUIDE - CUP PANEL (LOWER) TRUSS HEAD TRAY - DRIP DRIP TRAY TRUSS HEAD REAR PANEL TRUSS HEAD SIDE PANEL (LEFT) TRUSS HEAD SIDE PANEL (RIGHT) TRUSS HEAD STRIKE LATCH...
  • Page 10 Title: A. Ice Dispenser Assembly Model: DCM-750BWF Index Description FRAME ASSEMBLY EVAPORATOR ASSEMBLY SOCKET HEAD HEX BOLT SPLIT LOCK WASHER REFRIGERATION CIRCUIT WATER CIRCUIT MIDDLE FRONT PANEL ASSEMBLY TRUSS HEAD SCREW BIN ASSEMBLY TRUSS HEAD SCREW TRUSS HEAD SCREW GEAR MOTOR ASSEMBLY GEAR MOTOR ASSEMBLY (L) - GEAR MOTOR ASSEMBLY (R) SHUTTER ASSEMBLY...
  • Page 11 Title: A. Ice Dispenser Assembly Model: DCM-750BWF Index Description BUSHING GUIDE - CUP PANEL (LOWER) TRUSS HEAD SCREW TRAY - DRIP DRIP TRAY TRUSS HEAD SCREW REAR PANEL TRUSS HEAD SCREW SIDE PANEL (LEFT) TRUSS HEAD SCREW SIDE PANEL (RIGHT) TRUSS HEAD SCREW STRIKE LATCH...

  • Page 12: Frame Assembly

    B. Frame Assembly DCM-750BAF H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, N-0...
  • Page 13 Title: B. Frame Assembly Model: DCM-750BAF Index Description BASE FRONT FRAME TRUSS HEAD SCREW REAR FRAME TRUSS HEAD SCREW SEPARATOR TRUSS HEAD SCREW SIDE FRAME (R) TRUSS HEAD BRACKET – GEAR MOTOR TRUSS HEAD SCREW SIDE FRAME (UPPER) TRUSS HEAD SCREW...

  • Page 14: Dcm-750Bwf

    B. Frame Assembly DCM-750BWF H-0, J-0, K-0, K-1, M-0, M-1, N-0...
  • Page 15 Title: B. Frame Assembly Model: DCM-750BWF Index Description BASE FRONT FRAME TRUSS HEAD SCREW REAR FRAME TRUSS HEAD SCREW SEPARATOR TRUSS HEAD SCREW SIDE FRAME (R) TRUSS HEAD BRACKET – GEAR MOTOR TRUSS HEAD SCREW SIDE FRAME (UPPER) TRUSS HEAD SCREW CENTER PANEL TRUSS HEAD SCREW BRACKET...

  • Page 16: Evaporator Assembly

    C. Evaporator Assembly DCM-750BAF, DCM-750BWF H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, M-1, N-0...
  • Page 17 Title: C. Evaporator Assembly Model: DCM-750BAF, DCM-750BWF Index Description GEAR MOTOR HOUSING “O” RING EXTRUDING HEAD – 95C WASHER CUTTER AUGER AUGER ASSEMBLY (AUGER) (BUSHING) (COUNTERSUNK SCREW) EVAPORATOR SILICON CORD HEATER SOCKET HEAD CAP SCREW SS, M10 X 15 429121-02...

  • Page 18: Refrigeration Circuit

    D. Refrigeration Circuit DCM-750BAF H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, N-0 7C31-0408 7P31-0408 7P31-0408 7C31-0408 7P31-0408 38 39 40 7B02-0512 7L22-0500 7W22- 0500...
  • Page 19 Title: D. Refrigeration Circuit Model: DCM-750BAF Index Description COMPRESSOR GROMMET SPACER BOLT CONDENSER TRUSS HEAD SCREW SHROUD T2 SCREW COPPER TUBE (A) HIGH SIDE COPPER COPPER TUBE (B) HIGH SIDE COPPER COPPER TUBE (C) HIGH SIDE FAN MOTOR BRACKET HEX HEAD BOLT W/WASHER...
  • Page 20 Title: D. Refrigeration Circuit Model: DCM-750BAF Index Description INSULATION TUBE TERMINAL COVER SPRING CLIP PROTECTOR PROTECTOR HOLDER INSULATION TUBE BUSHING Material or Part Number Model Number L=130 7762-2943 4A1387F01 4A1843F01 4A1387F02 4A1843F02 4A1387F03 4A1843F03 4A1387F04 4A1843F04 L=500 7762-0717 420470-09 Required Number...

  • Page 21: Dcm-750Bwf

    D. Refrigeration Circuit DCM-750BWF H-0, J-0, K-0, K-1, M-0...
  • Page 22 D. Refrigeration Circuit DCM-750BWF M-1, N-0 23 24 7P31-0408 1 32 33 34 35 7C31-0406 7B0230512 7C31-0408 7C31-0406...
  • Page 23 Title: D. Refrigeration Circuit Model: DCM-750BWF Index Description COMPRESSOR GROMMET SPACER BOLT CONDENSER - WATER COOLED HEX HEAD BOLT W/WASHER (LF) COPPER TUBE (A) HIGH SIDE COPPER COPPER TUBE (B) HIGH SIDE COPPER COPPER TUBE (C) HIGH SIDE DRIER DRIER BRACKET TRUSS HEAD SCREW EXPANSION VALVE EXP.
  • Page 24 Title: D. Refrigeration Circuit Model: DCM-750BWF Index Description TERMINAL COVER SPRING CLIP PROTECTOR PROTECTOR HOLDER WASHER INSULATION TUBE VINYL HOSE Material or Part Number Model Number 4A1387F01 4A1843F01 4A1387F02 4A1843F02 4A1387F03 4A1843F03 4A1387F04 4A1843F04 4A0655-03 L=500 7762-0717 L=500 7711-0406 Required Number K-1 M-0 M-1 N-0...

  • Page 25: Water Circuit

    E. Water Circuit DCM-750BAF, DCM-750BWF H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, M-1, N-0...
  • Page 26 Title: E. Water Circuit Model: DCM-750BAF, DCM-750BWF Index Description WATER SUPPLY PIPE T2 SCREW WASHER WATER VALVE WATER VALVE T2 SCREW WATER VALVE BRACKET (A) WATER VALVE BRACKET (B) WATER VALVE BRACKET (C) T2 SCREW TRUSS HEAD SCREW INLET - RESERVOIR...
  • Page 27 Title: E. Water Circuit Model: DCM-750BAF, DCM-750BWF Index Description VINYL HOSE PIPE - DRAIN BRACKET THUMBSCREW HOSE CLAMP HOSE CLAMP HOSE CLAMP HOSE CLAMP CLAMP HOSE CLAMP Material or Part Number Model Number L=630 7725-1923 320836-01 432496-01 415949G04 435934-07 4A2017-01...

  • Page 28: Middle Front Panel Assembly

    F. Middle Front Panel Assembly DCM-750BAF, DCM-750BWF H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, M-1, N-0...
  • Page 29 Title: F. Middle Front Panel Assembly Model: DCM-750BAF, DCM-750BWF Index Description MIDDLE FRONT PANEL PUSH SWITCH SWITCH BRACKET TRUSS HEAD SCREW SWITCH COVER TRUSS HEAD SCREW ROCKER SWITCH - DISPENSE ROCKER SWITCH - ICE/FLUSH LAMP Material or Part Number Model...

  • Page 30: Bin Assembly

    G. Bin Assembly DCM-750BAF, DCM-750BWF H-0, J-0, J-1, J-2, K-0...
  • Page 31 G. Bin Assembly DCM-750BAF, DCM-750BWF K-1, L-0, L-1, M-0, M-1, N-0...
  • Page 32 Title: G. Bin Assembly Model: DCM-750BAF, DCM-750BWF Index Description BIN TOP ASSEMBLY TRUSS HEAD SCREW BIN - FORMED BARRIER TRUSS HEAD SCREW BRACKET - SLIDING TRUSS HEAD SCREW "O" RING SHAFT HOLDER (C) BARRIER – MOTOR Material or Part Number...

  • Page 33: Gear Motor Assembly

    H. Gear Motor Assembly DCM-750BAF, DCM-750BWF H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, M-1, N-0 Title: H. Gear Motor Assembly Model: DCM-750BAF, DCM-750BWF Index Description GEAR MOTOR JOINT BRACKET (C3) - GEAR MOTOR FLAT HEAD SCREW PLASTIC SLEEVE (A)

  • Page 34: Gear Motor Assembly (L)

    I. Gear Motor Assembly (L) DCM-750BAF, DCM-750BWF H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, M-1, N-0 Title: I. Gear Motor Assembly (L) Model: DCM-750BAF, DCM-750BWF Index Description GEAR MOTOR BRACKET (L1) - GEAR MOTOR FLAT HEAD SCREW PLASTIC SLEEVE (A)

  • Page 35: Gear Motor Assembly (R)

    J. Gear Motor Assembly (R) DCM-750BAF, DCM-750BWF H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, M-1, N-0 Title: J. Gear Motor Assembly (R) Model: DCM-750BAF, DCM-750BWF Index Description GEAR MOTOR BRACKET (R1) - GEAR MOTOR FLAT HEAD SCREW PLASTIC SLEEVE (A)

  • Page 36: Shutter Assembly

    K. Shutter Assembly DCM-750BAF, DCM-750BWF H-0, J-0, J-1, J-2, K-0...
  • Page 37 K. Shutter Assembly DCM-750BAF, DCM-750BWF K-1, L-0, L-1, M-0, M-1, N-0...
  • Page 38 Title: K. Shutter Assembly Model: DCM-750BAF, DCM-750BWF Index Description SOLENOID SOLENOID NUT LEVER SPRING SOLENOID PACKING R-C CAPACITOR (NOISE SUPPRESSOR) TRUSS HEAD SCREW SELF-LOCKING NUT TOOTH WASHER BASE - SHUTTER LINK COLLAR (D) TRUSS HEAD SCREW U NUT BASE (B) - SHUTTER...

  • Page 39: Control Box Assembly

    L. Control Box Assembly DCM-750BAF, DCM-750BWF H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, M-1, N-0 DCM-750baf ONLY...
  • Page 40 Title: L. Control Box Assembly Model: DCM-750BAF Index Description CONTROL BOX COVER - CONTROL BOX TRUSS HEAD SCREW STARTER T2 SCREW RUN CAPACITOR CAPACITOR - STARTING STRAP T2 SCREW TRANSFORMER T2 SCREW TIMER BOARD BOARD SUPPORT RELAY - HEATER CONTROL...
  • Page 41 Title: L. Control Box Assembly Model: DCM-750BAF Index Description 3P PLUG HOUSING 6P PLUG HOUSING 9P PLUG HOUSING 2P PLUG HOUSING R-C CAPACITOR (NOISE SUPPRESSOR) CAPACITOR T2 SCREW RELAY - GEAR MOTOR PROTECT Material or Part Number Model Number 3191-03P...
  • Page 42 Title: L. Control Box Assembly Model: DCM-750BWF Index Description CONTROL BOX COVER - CONTROL BOX TRUSS HEAD SCREW STARTER T2 SCREW RUN CAPACITOR CAPACITOR - STARTING STRAP T2 SCREW TRANSFORMER T2 SCREW TIMER BOARD BOARD SUPPORT RELAY - HEATER CONTROL RELAY - POWER PROTECT RELAY - WATER CONTROL TAPPING SCREW...
  • Page 43 Title: L. Control Box Assembly Model: DCM-750BWF Index Description 4P PLUG HOUSING 3P PLUG HOUSING 6P PLUG HOUSING 9P PLUG HOUSING 2P PLUG HOUSING R-C CAPACITOR (NOISE SUPPRESSOR) RELAY - GEAR MOTOR PROTECT Material or Part Number Model Number 3191-04P 412832-05 3191-03P 412832-06...

  • Page 44: Label Location

    M. Label Location DCM-750BAF, DCM-750BWF H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, M-1, N-0 OUT AT N-0...
  • Page 45 Title: M. Label Location Model: DCM-750BAF Index Description INSTRUCTION SHEET EMBLEM MODEL NUMBER LABEL LABEL - PENGUIN - HA - L NAMEPLATE LABEL - AIR FILTER INSTRUCTION LABEL LABEL - CLEANING WIRING LABEL LABEL - SWITCH, FUSE RATING LABEL CAUTION LABEL (J)
  • Page 46 Title: M. Label Location Model: DCM-750BWF Index Description INSTRUCTION SHEET EMBLEM MODEL NUMBER LABEL LABEL - PENGUIN - HA - L NAMEPLATE INSTRUCTION LABEL LABEL - CLEANING WIRING LABEL LABEL - SWITCH, FUSE RATING LABEL CAUTION LABEL (J) LABEL-CAUTION: TOP PANEL INSTRUCTION SHEET - BIN COVER TAG - WARNING:...

  • Page 47: Bin Top Assembly

    N. Bin Top Assembly DCM-750BAF, DCM-750BWF H-0, J-0, J-1, J-2, K-0...
  • Page 48 N. Bin Top Assembly DCM-750BAF, DCM-750BWF K-1, L-0, L-1, M-0, M-1, N-0...
  • Page 49 Title: N. Bin Top Assembly Model: DCM-750BAF, DCM-750BWF Index Description COVER - BIN TOP PROXIMITY - SWITCH BRACKET - SWITCH TRUSS HEAD SCREW BUSHING HINGE THUMBSCREW ACTUATOR SHAFT SNAP PIN Material or Part Number Model Number 211182G01 2A1713G01 427223-01 4A2033-01...

  • Page 50: Accessories

    P. Accessories DCM-750BAF, DCM-750BWF H-0, J-0, J-1, J-2, K-0, K-1, L-0, L-1, M-0, M-1, N-0 Title: P. Accessories Model: DCM-750BAF, DCM-750BWF Index Description INSTRUCTION MANUAL PACKAGING (ONLY AVAILABLE FOR MODELS CURRENTLY IN PRODUCTION) CARTON CORNER POST CORNER POST PALLET SIDE PROTECTOR WOOD BLOCK –...
