Manual Maredo® GT 424-03
VibeSpike- SeederC
Serial no.:
IMPORTANT:
The required (hydraulic) power depends on the working depth, soil
conditions, working speed etc. The condition of the triplex greensmower
and the ambient temperature determine the available capacity. Everybody
should check the greensmower during work if it isn't overloaded by
checking the heat built up and take the correct measurements.
MAREDO DOES NOT TAKE ANY LIABILITY FOR GREENSMOWER DAMAGES
For a safe operation it is essential, that the operator reads and
understands the manual of the Maredo machine.
MAREDO BV, Rijksstraatweg 16, 3956 CR Leersum, The Netherlands
WWW.MAREDO-BV.COM
EN 20.13
1
Advertisement
Table of Contents
Related Manuals for MAREDO GT 424-03 VibeSpike- SeederC
Summary of Contents for MAREDO GT 424-03 VibeSpike- SeederC
- Page 1 MAREDO DOES NOT TAKE ANY LIABILITY FOR GREENSMOWER DAMAGES For a safe operation it is essential, that the operator reads and understands the manual of the Maredo machine.
- Page 2 10. Use only original MAREDO spare parts, in order to ensure the safe operation of the machine. 11. Never use the MAREDO in the dark, in heavy rains, on frozen grounds, stony conditions and/ or on slopes steeper than 30 degrees.
- Page 3 FOREWORD Congratulations on the purchase of your MAREDO®. To ensure the safe and long- lasting operation of the MAREDO machine, you and anyone using the machine, should read and understand this user’s manual. Also ensure that you understand and practice the safety rules, as described in this manual.
- Page 4 FIRST SETUP: Unpack the GT424 carefully from steel side panels. If the drive side needs to be changed to the other side, do NOT remove the main spike shaft. You can easily exchange the side weights with the complete gearbox, because the main spike shaft has a tap for the belt pulley at each side.
- Page 5 GENERAL TIPS/ REMARKS 1. Do not use the seeder unit in wet conditions. The funnels may clog. 2. You can check the dosing rates yourself. 10.3 revs of the front roller equals 1m² (or 9.4 revs matches 10 sq ft). Measure the seed amount and you know the dosing per m²...
- Page 6 USER NOTES AND DEFINITIONS. Side weights Safety decal Trolley Protection strip Weight Motor mount plate Belt drive box Depth adjustment via the front roller Seed dosing gearbox Top cover seedbox. Click-on thoroughly Dosing decal for Bluegrass and Fescues Spare gear wheels Belt drive.
- Page 7 MAINTENANCE. 1) Check nut, bolts and other parts of the machine on a regular base. Check for damages or loose parts and fix and tighten the eventual errors prior to use. 2) Never use a high pressure water washer to clean the GT424. Using a high pressure washer will relieve damage the machine and its bearings.
