MAREDO MT210 Manual

Tractor mounted vibespike-aerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual of MAREDO MT210
tractor mounted VibeSpike-Aerator
Serial #:
IMPORTANT NOTE:
This machine cannot run by its own. It needs a (compact) tractor to drive it. An
experienced driver is required, alongside a well-equipped, safe tractor.
MAREDO DOES NOT TAKE ANY LIABILITY FOR TRACTOR OR DRIVER
.
DAMAGES WHO ARE TO BE BLAMED BY MIS-USE OR MIS-CHOICE
MAX. PTO REV.
: 540 RPM
MAX GROUND SPEED : 10 KM/H 6 MPH
.
Note:
For a safe operation it is essential, that the operator reads and under-
stands the manual of this Maredo MT210 and the tractor.
MAREDO BV, RIJKSSTRAATWEG 16, 3956 CR LEERSUM, NETHERLANDS.
WWW.MAREDO-BV.COM.
EN 1829
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT210 and is the answer not in the manual?

Questions and answers

Related Manuals for MAREDO MT210

Summary of Contents for MAREDO MT210

  • Page 1 MAX GROUND SPEED : 10 KM/H 6 MPH Note: For a safe operation it is essential, that the operator reads and under- stands the manual of this Maredo MT210 and the tractor. MAREDO BV, RIJKSSTRAATWEG 16, 3956 CR LEERSUM, NETHERLANDS. WWW.MAREDO-BV.COM.

  • Page 2: Safety Instructions

    11. Use only original Maredo MT210 spare parts, in order to ensure the safe operation of the machine. 12. Never use the Maredo MT210 in the dark, in heavy rain, on frozen grounds, stony conditions and/ or on slopes steeper than 30 degrees.

  • Page 3: Technical Specifications

    2.0 FOREWORD Congratulations with the purchase of your Maredo MT210 ® machine. To ensure the safe and long lasting operation of this Maredo MT210 machine, you and anyone else using this machine, should read and understand this user’s manual. Also ensure that you understand and practice the safety rules, as described in this manual and shown on the decal.
  • Page 4 4.0 UNPACKING AND FIRST SET-UP: Maredo MT210 machine is delivered on a specially prepared steel pallet, at which the heads and the MFrame are firmly packed. Assemble the machine as follows: 5.1. Remove all items from the pallet. Unscrew the rear draw bar from the MFrame.
  • Page 5 5.9. It is important that the tractor PTO length is correctly determined. Not only when the machine is new, but every time another tractor is used for this MAREDO machine. The way to calculate the correct length for the PTO goes as follows:...
  • Page 6 6.0 (FIRST) JOB PREPARATION + IMPORTANT NOTES. 6.1 TOPLINK & 3-POINT LINKAGE SETTINGS. At the top of the Aframe we have 3 holes for the top link. If a higher hole is chosen, Maredo MT200 machine will be tilted more forwards when raised. Which means more clearance for the rear head.
  • Page 7 6.4.5 You can make curves, as long as they aren’t tighter than a radius=2.00 mtr./ 6’. 6.4.6 Important: Make sure the PTO is always switched off before lifting the MT210. Running the PTO with a lifted MT210 may cause serious damage to the machine.
  • Page 8 6.5 SECURE THE HEADS. Standard the heads can individually follow the undulations via the front roller and the rear roller. This is possible because the heads are flexibly mounted with rubber blocks to the Mframe. The heads can be secured for two reasons: 6.5.1 LOCK THE HEADS IN WORK POSITION.

  • Page 9: Maintenance

    Disconnect the tractor and the machine is stored. NOTE: Disconnect the machine only on a levelled, hard surface. 7.0 MAINTENANCE. Maredo MT210 This machine is a low maintenance machine. Most bearings are sealed and do not need re-greasing. The following maintenance is needed: 7.1.
  • Page 10 Maredo There are two gearboxes mounted on this MT210 machine. Both use the same gearbox oil SAE 80/90W. The first time the oil needs to be replaced is after 100 hours of use. After that the oil will have to be replaced every 300 hours or once a year.

  • Page 11: Repair And Replacement

    - Lower the machine on it’s stands and disconnect the tractor. Make sure to place the MT210 on a clean and even surface - Remove the rear cover of each MT210 head as shown in the picture below. - Each spike section is bolted with three bolts to the main shaft. Remove these three bolts per section to take off the spikes.

  • Page 12: Spare Parts

    9.0 SPARE PARTS. For a complete overview of all parts for this MAREDO® machine, please look at our web site under support (www.maredo-bv.com/support/). Key part: #1835232 Spike section (24 pcs. per head / 72 pcs. for three heads) 10.0 OPTIONS.
