Lennox Hearth Products BV4000C Manual

Wood
ITEM NO

Door Parts

27M67 Clip Set, Glass
G6000 Door, Black Cast, H0533 (handle included)
14M72 Door, Gold, G3000 (handle included)
86-128 Gasket Kit, 3/4" Door Rope (includes adhesive)
27M81 Gasket Kit, Glass (10' of 10580)
G2000-7 Glass, Arched 9 3/8 x 15 3/4" (gasket not included)
10300 Handle Assembly, LB-102214 (does not fit brass doors. handles for brass doors are no longer
available)
11529 Hinge Pin, 10 L 18, Original (requires welding)
11531 Hinge Pin, Retrofit (requires drill #3 [.213"] & tap 1/4"-28 UNF. order 2 if set is needed)
10362 Torque Plate (latch)

Catalytic Combustor Parts

11000 Clip, Combustor
CLIP-2 Clip, Combustor (old style - stairstep spring) Looped end may need to be bent for fit this model
ESCC Combustor Assembly 2" (*SN<4645) - Includes ceramics, gasket & housing
14000 Combustor Assembly 3" (*SN>4645) - Includes ceramics, gasket & housing
11481H Gasket, Interam Combustor, 11481 (1/16 x 3 x 36")
C-200-51 Hook, Damper (Coil handle with hook for opening / closing damper bypass)
11485 Housing, Combustor
BV100 Probe, Combustor Temperature

Room Air Blower Parts

4020 Blower Assembly ⌧
11565 Disc, Low Limit (for blower, F110°-20F)
LB-101495 Wire Harness, Blower
10050087 Knob, Rheostat (02107)
LB-101496 Motor, Blower, 1 ea. (includes metal propeller)
26M22 Power Cord (02071)
42M1401 Propeller, Blower Motor, metal
528 Rheostat, Blower Speed Control, 02082 (knob, p/n 10050087, not included)
410-270 Switch, On/Off (Bypass)
410-260 Terminal Block, Large
11597 Wire Harness, Blower

Surround Parts

2046 Bracket, Surround Trim, 02046 ("L" bracket / corner key. order 2 if set is needed)
00010H Dart, Plastic, 00010 (1 each. for brass air intake trim)
26M71 Insulation Set, Surround (11842 & 11843)
HO471 Surround, 32 x 42" (standard), BV4032
11817 Trim, Air Intake Housing Gold
18748 Trim, Gold Tone, Surround 28 x 36"
2047 Trim, Gold Tone, Surround 32 x 42"
430XL Trim, Gold Tone, Surround 32 x 48"
14M71 Surround w/ Trim, X-Large, BV4832, 32 x 48"
BV4000C / BV4000C-2
LENNOX HEARTH PRODUCTS
Service Replacement Parts List
BV4000C / BV4000C-2
MODEL YEARS: 1986 - present
DESCRIPTION
W27
Earth Stove
