Marantz SR7010 Service Manual page 29

2-1.6. Confirmation items for the video system
See the block diagram fig.XXth.
Paths to be confirmed
Analog Video through (signal) Path
L1
V 0 1 V I D E O
fig.16
1 L2
* * * . * d B
Video Convert
L1
V 0 2 C O N V
(Analog or HDMI ⇒ HDMI)
fig.17a
L2
* * * . * d B
fig.17b
2
HDMI through (signal) Path
L1
V 0 3 H D M I
(MAIN ZONE) fig.18
3 L2
* * * . * d B
CEC
L1
V 0 4 C E O
fig.19
L2
* * * . * d B
4
(Control Monitor：HDMI Monitor1)
HDMI Audio
L1
V 0 5 H - A V R
fig.20a
(Audio :AVR)
L2
* * * . * d B
fig.20b
5
fig.20c
HDMI Audio
L1
V 0 6 H - T V
(Audio :TV)
fig.21a
6 L2
* * * . * d B
fig.21b
OSD
L1
V 0 7 M E N U
fig.22
L2
* * * . * d B
7
HDMI (signal) Path
L1
V 0 8 Z 2 H D
(ZONE2) fig.23
L2
* * * . * d B
8
Display
Input Source : CBL/SAT
Video Convert (IP Scaler) : OFF, All sources
MAIN ZONE : ON
ZONE2 : ON
Input Source : CBL/SAT
Video Convert (IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "Auto", All sources
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
Input Source : CBL/SAT
Video Convert (IP Scaler): OFF MAIN ZONE : ON, All sources
ZONE2 : OFF
ZONE3 : OFF
Input Source : CBL/SAT
HDMI Control : ON
Control Monitor : Monitor1 (HDMI Monitor Out1)
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
Input Source : CBL/SAT
HDMI Control : OFF
HDMI Audio : AVR (if checking the audio output from AVR)
HDMI Audio : TV (if checking the audio output from TV)
Input Source : CBL/SAT
Video Convert (IP Scaler) : ON, All sources
IP Scaler : "Analog & HDMI", All sources
Resolution : "AUTO", All sources
Setup Menu : ON
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
Input Source : CBL/SAT
ZONE2 Source : Source
MAIN ZONE : ON
ZONE2 : ON
ZONE3 : OFF
Settings
・Component input ⇒ Component output
・ CVBS input ⇒ CVBS output (MAIN/ZONE2)
(b The input source can be switched to any source except CBL/SAT.)
・CVBS input ⇒ IP Scaler ⇒ HDMI output.
・Component input ⇒ IP Scaler ⇒ HDMI output.
・HDMI input ⇒ IP Scaler ⇒ HDMI output.
・ETHERNET input ⇒ IP Scaler ⇒ HDMI output.
(b The input source can be switched to any source except CBL/SAT.)
・HDMI input ⇒ HDMI output(MAIN)
(b The input source can be switched to any source except CBL/SAT.)
・ When the power supply of a TV is put in the standby mode, make sure that the power supply of this unit is also put in the
standby mode.
・The ARC path can also be checked (check this using the TV input source).
(b The input source can be switched to any source except CBL/SAT.)
・HDMI input (PCM, DolbyDigital, DTS) ⇒ Speaker output.
・HDMI input(HD audio) ⇒ Speaker output.
(b The input source can be switched to any source except CBL/SAT.)
・HDMI input(PCM, DolbyDigital, DTS) ⇒ HDMI output (audio output from connected TV)
(b The input source can be switched to any source except CBL/SAT.)
・OSD display ⇒ HDMI output.
(b The input source can be switched to any source except CBL/SAT.)
・HDMI input (ZONE 2Function) ⇒ HDMI output (ZONE2)
(b The input source can be switched to any source except CBL/SAT.)
29
What to confirm
