Marantz SR7010 Service Manual page 28

Paths to be confirmed
Front Amp-Front Wide (signal) Path
L1
A 2 1 F W 2
fig.14a
L2
* * * . * d B
fig.14b
14
Wide/Height Amp-Surround Back (signal)
L1
A 2 3 S B
Path
L2
* * * . * d B
fig.15a
fig.15b
15
Display
Input Source : CBL/SAT
Input Mode:Auto
SURROUND mode: Multi ch STEREO
Amp assign:11.1ch
Floor Layout : 5ch&SB&FW
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Pre-out Channel : Front
Speaker Select : Front
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
Input Mode:Auto
Sound mode: Multi ch Stereo
Amp assign:7.1ch + ZONE2
Speakers for ZONE2: Front Wide/Height 2
Floor Layout : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Speaker Select : Floor
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
Settings
・Analog input ⇒ Speaker output : Front Wide L/R ( Front Wide signal )
(b The input source can be switched to any source except CBL/SAT.)
(b Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
・Analog input ⇒ Preout output (Surround Back L/R)
(b The input source can be switched to any source except CBL/SAT.)
(b Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
28
What to confirm
