Marantz SR7010 Service Manual page 27

Paths to be confirmed
Analog Amp Assign (signal) Path
L1
A 0 9 Z 2 / 3 A
(Amp Assign：ZONE2 / ZONE3 - MONO)
L2
* * * . * d B
fig.09
9
Amp Assign (signal ) Path
L1
A 1 1 B i A M P
(Amp Assign : Bi-AMP)
fig.10a
L2
* * * . * d B
fig.10b
10
Front Height (signal) Path
L1
A 1 4 F H
fig.11a
L2
* * * . * d B
fig.11b
11
Front Wide (signal) Path
L1
A 1 5 F W
fig.12a
L2
* * * . * d B
fig.12b
12
7.1ch INPUT (signal) Path
L1
A 1 9 7 . 1 I N
fig.13
L2
* * * . * d B
13
Display
Input Source : CBL/SAT
Input Mode : Auto
Sound mode： STEREO
Z2 Source : Source
Z3 Source : Source
Amp assign : 7.1ch + ZONE2/3-MONO
Speaker for ZONE2/3：Height1
Floor Layout : 5ch&SB&FW
MAIN ZONE ON
ZONE2 ON
ZONE3 ON
Input Source : CBL/SAT
Input Mode : Auto
Sound mode： MULTI CH STEREO
Amp assign : 7.1ch + Bi-Amp
Speaker for Bi-Amp:S.Back
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
Input Source : CBL/SAT
Input Mode : Auto
Sound mode： MULTI CH STEREO
Amp assign ： 11.1ch
Floor Layout : 5ch&SB
Height Sp : 4ch
Dolby Sp : None
Height Layout : Top Front & Top Rear
Pre-out Channel = Top Rear
Speaker Select=Floor & Height
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
Input Source : CBL/SAT
Input Mode : Auto
Sound mode： Multi Ch Stereo
Vol.：60.0（-20.0dB）
Amp assign ： 11.1ch
Floor Layout : 5ch&FW
Height Sp : 4ch
Dolby Sp : None
Height Layout : Front Height & Top Middle
Pre-out channel : Top Middle
Speaker Select = Floor & Height
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
Input Source : CBL/SAT
Input Mode : 7.1Ch In
Amp Assign : 9.1ch
Floor Layout : 5ch&SB
Height Sp. : None
Dolby Sp : None
Speaker Config All Speaker=Small/SW=2ch
Settings
・Analog input ⇒ Speaker output
・Analog input ⇒ Pre OUT output
(b The input source can be switched to any source except CBL/SAT.)
(b Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
・Analog input ⇒ Speaker output (Surround Back L/R → Front L/R)
Pre OUT, do not need.
(b The input source can be switched to any source except CBL/SAT.)
(b Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
・Analog input ⇒ Speaker output
・Analog input ⇒ Preout output ( Top Front output Height2 L / R output )
(b The input source can be switched to any source except CBL/SAT.)
・PREOUT output
(b Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
・Analog input ⇒ Speaker output (Front Wide L/R)
・Analog input ⇒ Preout output (Front Wide L/R, Height 2 L/R (Top Middle))
(b The input source can be switched to any source except CBL/SAT.)
・PREOUT output
(b Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
・7.1ch input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・7.1ch input ⇒ Pre output (Front L/R, Center, Surround L/R, Surround Back L/R, Subwoofer 1/2)
27
What to confirm
Height1 L ( ZONE2 MONO )
Height1 R ( ZONE3 MONO )
ZONE2 L/R MONO
ZONE3 L/R MONO
Height1 L / R ( Top Front output )
Height1 L / R ( Top Front output )
Height2 L / R ( Top Rear output )
