Marantz SR7010 Service Manual page 26

Paths to be confirmed
Digital (signal) Path
L1
A 0 4 Z 3 D I G
(ZONE3)
fig.04a
L2
* * * . * d B
fig.04b
4
HDMI (signal) Path
L1
A 0 5 H D M I
fig.05a
L2
* * * . * d B
fig.05b
fig.05c
5
Analog AD (signal) Path
L1
A 0 6 A D
(MAIN ZONE)
fig.06a
L2
* * * . * d B
fig.06b
6
Analog Amp Assign (signal) Path
L1
A 0 7 Z 2 A S S
(Amp Assign：ZONE2)
fig.07
L2
* * * . * d B
7
Analog Amp Assign (signal) Path
L1
A 0 8 Z 3 A S S
(Amp Assign：ZONE3) fig.08
L2
* * * . * d B
8
Display
Input Source : Online Music
Input Mode : Auto
Sound mode： STEREO
Amp assign : 7.1ch + ZONE3
Speaker for ZONE3 : Front Wide/Height2
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE ON
ZONE2 OFF
ZONE3 ON
Input Source : CBL/SAT
Input Mode : HDMI (fixed)
Sound mode： STEREO
Amp assign : 9.1ch
Floor Layout : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
Input Source : CBL/SAT
Input Mode : Analog (fixed)
Sound mode： MULTI CH STEREO
Amp assign : 9.1ch
Floor Layout : 5ch&SB&FW
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Speaker Select : Floor
Speaker Config All Speaker=Small/SW=Yes(2ch)
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
Input Source : CBL/SAT
Input Mode : Auto
Sound mode： STEREO
Z2 Source : Source
Amp assign : 7.1ch + ZONE2
Speaker for ZONE2 : S.Back
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE ON
ZONE2 ON
ZONE3 OFF
Input Source : CBL/SAT
Input Mode : Auto
Sound mode： STEREO
Z3 Source : Source
Amp assign : 7.1ch + ZONE3
Speaker for ZONE3 : Front Wide/Height2
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE ON
ZONE2 OFF
ZONE3 ON
Settings
・Digital(PCM) input ⇒ Amp Assign Speaker output ( Front Wide ( ZONE3 ) L / R )
・Digital ( PCM ) input ⇒ Preout output ( ZONE3 L / R )
( b As the input source, you can switch from Online Music to other ones.)
・HDMI input ⇒ Speaker output (Front L/R)
・HDMI input ⇒ Preout output (Front L/R)
(b The input source can be switched to any source except CBL/SAT.)
・Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R, Front Wide L/R)
・Analog input ⇒ Preout output, SW(20Hz) (Front L/R, Center, Surround L/R, Surround Back L/R, Front Wide L/R, SUbwoofer)
(b The input source can be switched to any source except CBL/SAT.)
(b Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
・Analog input ⇒ Speaker input (Surround Back (ZONE2) L/R)
・Analog input ⇒ Preout input (ZONE2 L/R)
(b The input source can be switched to any source except CBL/SAT.)
(b Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
・Analog input ⇒ Speaker output (Front Wide (ZONE3) L/R)
・Analog input ⇒ Preout input (ZONE3 L/R)
(b The input source can be switched to any source except CBL/SAT.)
(b Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
