Version Display Mode - Marantz SR7010 Service Manual

1. Version Display Mode

1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
While holding down buttons "DIMMER" and "STATUS" simultaneously, press the power button to turn on the power.
then press the "STATUS" button to display the information in section 1.3 on the display.
The version list is also displayed on GUI while the version is displayed on the display.
b
1.3. Display Order
Error information("See "1.4. Error display") → q Model destination information, Serial Number
→ w Firmware Package Version → e Main µ-com, Main 1st Boot Loader Version → r DSP1/2/3/4 ROM
→ t Audio, Video PLD → y GUI SFLASH → u Ethernet 1st Boot Loader, Hardware ID
→ i Ethernet 2nd Boot Loader, Rhapsody Flag → o Ethernet IMAGE → Q0 Ethernet MAC ADDRESS information
→ Q1 BT MAC ADDRESS information → Q2 MultEQ Pro APP (Displayed when Audyssey Pro is complete)
→ Q3 MultEQ Pro ICL (Displayed when Audyssey Pro is complete) → Q4 HD Radio (For U Region)
q Model destination information, Serial Number：
FLD L1
S R 7 0 1 0
FLD L1
S R 7 0 1 0
FLD L1
S R 7 0 1 0
FLD L1
S R 7 0 1 0
FLD L2
S / N .
w Firmware Package Version：
L1
F i r m .
FLD
L2
e Main µ-com, Main 1st Boot Loader Version:
L1
M a i n
FLD
L2
M a i n
r DSP1/2/3/4 ROM :
L1
D S P 1
FLD
L2
D S P 2
L1
D S P 3
FLD
L2
D S P 4
t Audio, Video PLD :
L1
A u d i o
FLD
L2
V i d e o
U
N
F
K
* * * * * * * * * *
P a c k a g e
V e r . : * * * *
: * * * * * * * *
F B L : * * . * * *
: * * . * *
: * * . * *
: * * . * *
: * * . * *
P L D : * * . * *
P L D : * * . * *
