Switching on and off

4.1

Switching on the instrument

1 Ensure that all components are connected to the power supply.
2 Switch on the external laser module. The key switch is located on the laser module, refer to manufacturer
documentation.
3 Switch on the UltraMicroscope Blaze™ Imaging System. The power switch is located on the rear side of the
instrument (Figure 2.2).
4 Switch on the workstation PC and log on to Windows system with your user credentials.
5 Start the ImSpector software by double clicking on the program icon. The switched on devices are
registered and checked.
4.2

Switching off the instrument

1 Close the ImSpector software.
2 Shut down Windows system.
3 Switch off the UltraMicroscope Blaze™ Imaging System. The power switch is located on the rear side of the
instrument (Figure 2.2).
4 Switch off the external laser module. The key switch is located on the laser module, refer to manufacturer
documentation.
5 Disconnect the camera from the power supply.
4.3

Graphical user interface

Name
Start measurement
Stop measurement
Save settings
Start measurement
Start batch measurement
Start live preview
Function
Starts the defined measurement
Stops the defined measurement
Saves all settings
Starts the defined measurement
Starts the defined batch
measurement
Starts a preview in the live window
Location
Toolbar
Toolbar
Toolbar
Measurement Wizard
Measurement Wizard
Measurement Wizard
