Uplift Desk TG001-REV1 Quick Start Manual

E7 LED Desk Lamp
SKU: LTG001-REV1

Package Contents

Lamp
• Maximum desktop thickness: 2.25"
© UPLIFT Desk • 800-349-3839 • info@upliftdesk.com • upliftdesk.com
O-ring Gaskets
Step 1
A. Loosen the handle under the Clamp and slide onto
your desk.
B. Tighten the handle until the Clamp is securely fas-
tened to the edge of your desk.
• C lamp will fit worksurfaces up to 2.25'' thick
Step 2
A. Install the Lamp to the Clamp base by sliding
the bottom peg of the Lamp into the hole on the
Clamp.
B. If it's difficult to install the Lamp into the hole, twist
the Lamp. The pre-installed O-ring can be a bit
tight and would not respond to a push, but if you
twist and push, it will go in.
• T here are additional O-ring Gaskets provided,
Step 3
A. Tighten the set screw in the Clamp so the Lamp is
secure and won't come unattached.
B. If you purchased the Desk Base (LTG002), it will
have a similar hole and set screw for its assembly.
Desk Base
Step 4
A. Plug the end of the Lamp's cord into the Power Adapt-
er, and plug the Power Adapter into a wall outlet.
B. The switch on the power cord should come shipped
in the "off" position. Flip the switch to "on."
C. Tap the button on the top of the Lamp's head to
turn it on. Continue tapping the button, cycling
through the color temperatures, to turn the Lamp
off, or turn the lamp off using the switch on the
power cord.
Clamp Power Adapter
should the pre-installed O-ring Gasket break or
need replacing.
Allen Wrenches
