GM-82 GPS Receiver
Features
SiRF Star II/LP (low power) chipset with embedded ARM7TDMI CPU available for
customized applications in firmware。
12 parallel satellite-tracking channels for fast acquisition and reacquisition。
High speed signal acquisition using 1920 time/frequency search channels。
Built-in WAAS/EGNOS Demodulator。
Low power consumption with Advanced Trickle-Power and Push-To-Fix mode。。
Optional Rechargeable battery for memory and RTC backup and for fast Time to
First Fix(TTFF)。
Support NMEA0183 v2.2 data protocol and SiRF binary code。
Enhanced algorithms -SnapLock and SnapStart provide superior navigation
performance in urban, canyon and foliage environments。
For Car Navigation , Marine Navigation ,Fleet Management ,AVL and
Location-Based Services , Auto Pilot ,Personal Navigation or touring devices,
Tracking devices/systems and Mapping devices application。

Advertisement

loading
Need help?

Need help?

Do you have a question about the GM-82 and is the answer not in the manual?

Questions and answers

Summary of Contents for Holux GM-82

  • Page 1 GM-82 GPS Receiver Features SiRF Star II/LP (low power) chipset with embedded ARM7TDMI CPU available for customized applications in firmware。 12 parallel satellite-tracking channels for fast acquisition and reacquisition。 High speed signal acquisition using 1920 time/frequency search channels。 Built-in WAAS/EGNOS Demodulator。...
  • Page 2: Specifications

    Specifications Snap Start Hot Start Warm Start Cold Start Satellite Reacquisition Time Accuracy Channels Position Accuracy Receiver Protocol Maximum Altitude Maximum Velocity Max. Update Rate RF Connector Dimension Weight Firmware Upgrade Time Mark Operating Temperature Storage Temperature Operating Humidity Electrical specifications: Less than 80mA (without antenna )。...
  • Page 3 Electrical Output specification: Interface 1、 RS-232。 2、 CMOS TTL Level。 3、 5 GPIO NMEA output protocol: Baud rate: 4800 bps Data bit: 8 Parity: Stop bit: 1 Output format: GGA, GSA, GSV, MC.(VTG , GLL, RMS option) Output terminal and definition 20 Pin header (2.0mm Pitch).
  • Page 4: Products List

    General purpose I/O pin General purpose I/O pin GPIO2 General purpose I/O pin GPIO3 GPIO4 General purpose I/O pin Ground Products List Output Level Model No. TTL or RS-232 GM-82-A0X-5 RS-232 GM-82-A0X-3 RS-232 GM-82-A0A-5 RS-232 GM-82-A0A-3 RS-232 GM-82-A1X-5 RS-232 GM-82-A1X-3 RS-232 GM-82-A1A-5...
