CF GPS receiver GM-270-Ultra

Features:

12 parallel satellite-tracking channels for fast acquisition and reacquisition.

High speed signal acquisition using 1920 time/frequency search channels.

Low power consumption with Star II / LP chipset.

Built-in rechargeable battery for memory and RTC backup and for fast Time to

First Fix(TTFF).

Support NMEA0183 v2.2 data protocol .

Enhanced algorithms -SnapLock and SnapStart provide superior navigation

performance in urban, canyon and foliage environments.

Support CF card type I connector suitable PDA, Hand Held PC or PC device.

Need help?

Do you have a question about the GM-270 Ultra CF and is the answer not in the manual?

Page 1 CF GPS receiver GM-270-Ultra Features: 12 parallel satellite-tracking channels for fast acquisition and reacquisition. High speed signal acquisition using 1920 time/frequency search channels. Low power consumption with Star II / LP chipset. Built-in rechargeable battery for memory and RTC backup and for fast Time to First Fix(TTFF).
Page 2: Technical Specification
45 sec., averaged Position accuracy: Non DGPS (Differential GPS) Position 5-25 m CEP without SA Velocity 0.1 m/sec, without SA Time 1 usec sync GPS Time Dynamic Conditions: Altitude 18,000 meters (60,000 feet )max Velocity 515 meters / second (700 knots) max...
Page 3 * The specifications are subject to be changed without notice. * The measurement functions of this GPS CF card are not intended for use in tracking measurements that requires professional or industrial precision. Values produced by this GPS CF card should be...
