1. PACKAGE CONTENT

7" Wireless screen
Up to 4 screens
VICAM-AMS-M7-MULTI
Monitor stand
Monitor stand
+ screws
IMPORTANT NOTICE
- Storage:
The storage temperature for this product is -30 to +80°C and the operating temperature is -20 to +70°C. The humidity level
is RH 90%. Be sure not to overlook these safety precautions. Never use this product near water, or in dusty or humid areas.
Use:
- The product can be powered by 10V–32V
- Be careful when setting up the cables.
Warning:
- The monitor has high voltage.
- Some dark patches or spots may appear on the LCD display.
This is a highly common phenomenon in active-matrix display technology and does not necessarily indicate a fault.
Never attempt to repair this device yourself. If there is a problem, please turn off the display immediately and notify us.
The monitor is a complex device. Disassembling or modifying it in any way may result in damage and void the warranty.
2
AMS Diffusion - Rue des Galeries - ZA du Chevalement - 59286 Roost Warendin - FRANCE - Tél. +33 (0)3.27.94.44.44 - Fax. +33 (0)3 27 94 44 45
Email : contact@ams-diffusion.fr - www.ams-diffusion.com RCS DOUAI A 451 360 382 - CODE APE 4531Z - SIRET 451 360 382 00035 - TVA FR 55 451 360 382
Wireless cameral
VICAM-AMS-CAM-MULTI
Remote control
Power-supply cable
2. USE
CAMERA
The pairing button can be found
on the back of the camera
MONITOR
POWER
- ON/OFF
<
- Volume -
- Navigation towards the left
>
- Volume +
- Navigation towards the right
MENU :
Image & volume
settings
- Brightness
- Contrast
- Colors
- Volume
PICTURE MIR-FLIP
Recording
- REWRITE: New recordings
overwrite previous ones
when the card is full
- FORMAT: SD card
RECORD formatting PLAY
AMS Diffusion - Rue des Galeries - ZA du Chevalement - 59286 Roost Warendin - FRANCE - Tél. +33 (0)3.27.94.44.44 - Fax. +33 (0)3 27 94 44 45
Email : contact@ams-diffusion.fr - www.ams-diffusion.com RCS DOUAI A 451 360 382 - CODE APE 4531Z - SIRET 451 360 382 00035 - TVA FR 55 451 360 382
The memory card is located on the back of
the screen
OK
- Confirm / Enter
- Start/Stop recording
- 3 seconds: activates pairing
mode
MENU
- Access menu
Display
Mirror effect
settings
- Standard
- Clock
- Mirror
- Automatic brightness
- Flip
adjustment
- Mirror flip
- Park assist lines
SYSTEM
Reading
Pairing of
- Management of
recorded files
cameras
- Date settings
PAIRING
3
