- Page 1 SMART CHECKER™ Visual Fault Locator User Manual VFL Part Number: AFT-G-FC 1.25mm Adapter Part Number: AFT-G-CAC SENKO ADVANCED COMPONENTS sales@senko.com https://www.senko.com/product/smart-checker-visual-fault-locator-vfl/ Issue: AFTGFC202208BT01 Page 0...
-
Page 2: Table Of Contents
TABLE OF CONTENTS: SECTION 1.0 DESCRIPTION PAGE 1 SECTION 2.0 FEATURES PAGE 1 SECTION 3.0 SPECIFICATIONS PAGE 1 AND 2 SECTION 4.0 OPERATION INSTRUCTIONS PAGE 3 SECTION 5.0 MAINTENANCE INSTRUCTIONS PAGE 4 SECTION 6.0 PRODUCT WARRANTY PAGE 4 SECTION 7.0 SERVICE CONTACTS PAGE 4 Issue: AFTGFC202208BT01... -
Page 3: Description
1.0 DESCRIPTION: The SMART CHECKER™ visual fault locator is a very useful tool designed for checking the defects of a fiber cable. It emits a visible 650 nm wavelength red laser light through fiber optic assemblies. The light can be seen where the are fiber breaks or defects like micro and marco bends in the fiber. The light will refract out creating a bright glow around the faulty area. -
Page 4: Operation Instructions
3.0 SPECIFCATIONS (CONT.): Laser Class: Class 2M Wavelength: 650nm ± 10nm @ +25°C Spectral Width: < 10nm Output Power: > -3dBm @ +25°C into 9μm fiber Continuous Wave (CW) Operational Modes: Pulse Mode Power Source: 2X 1.5V AAA alkaline batteries Green for Power On LED Indicator Modes: Red for Low Remaining Battery Life... -
Page 5: Maintenance Instructions
Exposed to extreme temperature. Near energized power cables The internal fiber stub will require periodic cleaning with a 1.25mm optical grade cleaning stick. Senko recommend the 2.5mm NEOCLEAN sticks (Part Number CSK-02). Cleaning the ferrule end face on the 1.25mm adapter before it is inserted prevent accidental cross contaminating the ferrule stub end face in the VFL port.
