ASSEMBLY INSTRUCTION
BAJA Gaming Chair
ITEM CODE 73856
Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please phone
Amart Furniture, Customer Service Free call 1800 351 084
1
73856
Advertisement
Table of Contents
Related Manuals for Amart Furniture BAJA 73856
Summary of Contents for Amart Furniture BAJA 73856
- Page 1 ASSEMBLY INSTRUCTION BAJA Gaming Chair ITEM CODE 73856 Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please phone Amart Furniture, Customer Service Free call 1800 351 084 Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
- Page 2 PRE-ASSEMBLY PREPARATION Before you start: Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product Take care when lifting. Product should be assembled as near as possible to the point of use Ensure that you have all required contents for complete assembly Always read the assembly instructions carefully before beginning assembly.
- Page 3 PARTS LIST Headrest Back Backrest Armrest Regulator Seat Mechanism Three cups Gas lift Base Castor Screw Screw cover Gasket 16pcs 4pcs 6pcs φ 17Xφ 8.5X1mm M8X20mm M5X8mm Cover 1 Cover 2 Screwdriver 73856...
- Page 4 STEP 1: Insert castor 11 into base 10 Insert gas lift 9 into base 10, then place three cups 8 on gas lift 9. STEP 2: Connect mechanism 7 to seat 6, twist screw A and tighten with screwdriver F. 73856...
- Page 5 STEP 3: Connect armrest 4 to seat 6. Twist in screw A and fasten with screwdriver F. STEP 4: Connect regulator 5 to back 2. Twist in screw A and gasket B and tighten with screwdriver F. 73856...
- Page 6 STEP 5: Insert the cover D and E, twist the screw and cover C, tighten with screwdriver F. STEP 6: Place mechanism 7 on gas lift 9. 73856...
- Page 7 STEP 7: Installation method for the top pillows and lower pillows. Top pillows installed Lower pillows installed Adjustment strap Adjustment strap Figure 1 Figure 1 1.Pass both ends of the adjustment 1.Move the adjustment strap strap through the seat back hole. across the back of the chair where it is attached to the seat.
- Page 8 GENERAL PRODUCT CARE CARE AND MAINTENANCE OFFICE CHAIR DO NOT REMOVE THIS LABEL ● DO NOT STAND ON THIS CHAIR-DO NOT USE THIS CHAIR AS STEP LADDER. ● USE THIS PRODUCT ONLY FOR SEATING ONE PERSON AT A TIME. ● DO NOT USE THIS CHAIR UNLESS ALL BOLTS, SCREWS AND KNOBS ARE FIRMLY SECURED.
