P/N 126754-01 Rev. B 03/2014
P126754-01
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or mobile
home, where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other gases, unless a certified kit is used.
WARNING AVERTISSEMENT AVISO
f i r e - p a r t s . c o m
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
WARNING: If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property damage,
personal injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
Installation and Operation Instructions
Astria
Electronic Ignition System
PFS
Models
®
Mission36TEN
C
US
Installateur : Laissez cette notice avec l'appareil.
Consommateur : Conservez cette notice pour consultation ultérieure.
UNE SURFACE VITRÉE CHAUDE PEUT
CAUSER DES BRÛLURES.
LAISSER REFROIDIR LA SURFACE VITRÉE
AVANT D'Y TOUCHER.
NE PERMETTEZ JAMAIS À UN ENFANT DE
TOUCHER LA SURFACE VITRÉE.
AVERTISSEMENT : Assurez-vous de bien suivre les
instructions données dans cette notice pour réduire au
minimum le risque d'incindie ou d'explosion ou pour éviter
tout dommage matériel, toute blessure ou la mort.
— Ne pas entreposer ni utilizer d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
— QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ :
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucan interrupteur. Ne pas vous
• Appelez immédiatement votre fournisseur de
• Si vous ne pouvez rejoindre le fournisseur de gaz,
— L'installation et l'entretien doivent être assurés par un
installateur ou un service d'entretien qualifié ou par le
fournisseur de gaz.
B-Vent Decorative Gas Fireplace
TM
Mission42TEN
servir des téléphones se trouvant dans le bâtiment
où vous trouvez.
gaz depuis un voisin. Suivez les instructions du
fournisseur.
appelez le service des incindies.
EL VIDRIO CALIENTE
CAUSARÁ QUEMADURAS.
USTED DEBE NUNCA TOCAR
EL VIDRIO CALIENTE.
LOS NIÑOS DEBEN NUNCA
TOCAR EL VIDRIO.
Advertisement
Table of Contents
Related Manuals for Astria Fireplaces Mission36TEN
Summary of Contents for Astria Fireplaces Mission36TEN
- Page 1 Astria B-Vent Decorative Gas Fireplace Electronic Ignition System P/N 126754-01 Rev. B 03/2014 Models ® Mission36TEN Mission42TEN P126754-01 INSTALLER: Leave this manual with the appliance. Installateur : Laissez cette notice avec l’appareil. CONSUMER: Retain this manual for future reference. Consommateur : Conservez cette notice pour consultation ultérieure.
-
Page 2: Table Of Contents
WARNING: Improper installation, adjustment, al- teration, service or maintenance can cause injury or property damage. Refer to this manual for correct in- stallation and operational procedures. For assistance or additional information consult a qualified installer, service agency or the gas supplier. NOT FOR USE WITH SOLID FUEL CHECK LOCAL CODES PRIOR TO INSTALLATION SAVE THIS BOOK... -
Page 3: Safety
SAFETY 1. This appliance is only for use with the type WARNING: This product con- of gas indicated on the rating plate. This tains and/or generates chemicals appliance is not convertible for use with other gases unless a certified kit is used. known to the State of California 2. -
Page 4: Unpacking
Safely retain these items for later installation. pan and ember materials INTRODUCTION BEFORE YOU BEGIN Models MISSION36TEN and MISSION42TEN are vented gas fireplaces that use an electronic Before beginning the installation of your control valve and electronic ignition system. appliance, read these instructions through A 6"... -
Page 5: Selecting Location
INTRODUCTION Continued D) The burning of anything other than the type of CAUTION: Do not connect gas approved for use in this gas appliance. The installation must conform with local appliance before pressure test- codes or, in the absence of local codes, with ing gas piping. -
Page 6: Product Specifications
PRODUCT SPECIFICATIONS GAS RATING - NATURAL MISSION36TEN MISSION42TEN Max. Input Rating: 40,000 Btu/Hr 45,000 Btu/Hr Manifold Pressure: 3.5" WC (.87 kPa) 3.5" WC (.87 kPa) Minimum Supply Pressure: 4.5" WC (1.12 kPa) 4.5" WC (1.12 kPa) Maximum Supply Pressure: 10.5" WC (2.66 kPa) 10.5"... -
Page 7: Pre-Installation Preparation
3" (7.6 cm) 2 x 4 Stud " Nailing (3.8 cm) Max. Flange f i r e - p a r t s . c o m Left Side Back Surround MISSION36TEN MISSION42TEN 0 cm/po F0858 F0864 Clearance F0860 F0866 F0862 F0868 14"... - Page 8 Required at Nailing Flanges point or alternate access hole in the bottom of appliance (see Figure 19, page 14). MISSION36TEN (F0858, MISSION42TEN (F0864, 4. Repack insulation around gas line to cover F0860 and F0862) F0866 and F0868) any remaining openings in conduit sleeve.
-
Page 9: Requirements For The Commonwealth Of Massachusetts
REQUIREMENTS FOR THE COMMONWEALTH OF MASSACHUSETTS INSPECTION For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or The state or local gas inspector of the side structure used in whole or in part for residential wall horizontally vented gas fueled equipment purposes, including those owned or operated by shall not approve the installation unless, upon... -
Page 10: Venting Installation
VENTING INSTALLATION A B-type venting system must be connected at 60° or greater. The total vertical height in to appliance for venting to the outside of this example represents the minimum height building. of 8 feet and therefore the allowable lateral is 6 feet when the 75% rule applies. - Page 11 VENTING INSTALLATION Continued Listed Vent Cap Listed Listed Vent Cap Vent Cap Maintain Maintain Listed Listed Clearance Clearance Maintain Listed Maintain Support Each Clearance Listed Lateral At Clearance Least Every 45° 60° 6 Feet 12' Min. 45° Position Position Firestop Firestop Position 12' Min.
-
Page 12: Installation
VENTING INSTALLATION Continued CHECKING FOR PROPER VENTING NOTICE: This appliance is After completing and checking electrical, equipped with a vent safety gas and vent connections, follow the lighting shutoff switch which will shut instructions and allow the main burner to run down the appliance in the case of for approximately 5 minutes. - Page 13 OFF. 7" 7" A manual shutoff valve has been included in Alternate Gas Supply Through Sub-Floor the appliance’s gas supply system. You may MISSION36TEN MISSION42TEN consider installing an extra gas shutoff valve F0858 F0864 outside appliance’s enclosure (check with F0860...
- Page 14 INSTALLATION Continued Complete your gas installation by connect- CAUTION: Compounds used ing incoming gas line with flexible gas line. on threaded joints of gas piping Secure tightly with wrench but DO NOT OVERTIGHTEN. shall be resistant to the action of Liquefied Petroleum (LP or EMBER AND PAN MATERIAL propane) and should be applied PLACEMENT...
- Page 15 Burner Pan Log 4 Figure 22 - Pan and Ember Material Clearances Log 3 LOG PLACEMENT FOR MISSION36TEN Log 2 (F0858, F0860, F0862) Notches 1. Place small front right log (log 1) on right front of grate as shown in Figure 23.
- Page 16 INSTALLATION Continued LOG PLACEMENT FOR MISSION42TEN 5. Place upper end of log 5 into notch on top inner right of log 1 (see Figure 29). Rest (F0864, F0866 AND F0868) lower end of log 5 on middle grate finger 1. Place large back log (log 1) onto grate as shown in Figure 30.
- Page 17 INSTALLATION Continued COMBUSTION AIR KIT MODEL AK4 INSTALLING OPTIONAL GLASS (OPTIONAL) DOOR ACCESSORY The outside air kit may be installed on the left CAUTION: Use only glass side of fireplace only. The vent can be installed doors certified for use with this through any outside wall a minimum of three feet below fireplace termination cap.
- Page 18 INSTALLATION Continued 6. Repeat process for opposite door as- Spring Hold-Down Clip sembly. Screw 7. To adjust doors, slide them partially open. Side Using a screwdriver, loosen hold-down Front screws in the spring clip (see Figure 34) Face and pivot plate. 8.
-
Page 19: Operation
OPERATION FOR YOUR SAFETY 1. STOP! Read the safety information, col- umn 1. READ BEFORE LIGHTING 2. Turn wall switch (if installed) to the OFF WARNING: If you do not fol- position. low these instructions exactly, 3. Turn off all electric power to appliance. a fire or explosion may result 4. -
Page 20: Inspecting Burners
OPERATION Continued TO TURN OFF GAS 1. Turn equipment shutoff valve to ON posi- tion. You can now turn burner on and off TO APPLIANCE with the hand-held remote control unit. 1. Turn off wall switch. IMPORTANT: Be sure to press ON/OFF 2. -
Page 21: Cleaning And Maintenance
CLEANING AND MAINTENANCE WARNING: Failure to keep WARNING: Installation and the primary air opening(s) of repair should be done by a quali- the burner(s) clean may result in fied service person. The appli- sooting and property damage. ance should be inspected before each use and at least annually PILOT AND BURNER by a qualified service person. -
Page 22: Wiring Diagram
WIRING DIAGRAM Pilot Burner INCOMING WALL SWITCH MAIN GAS (NOT SUPPLIED) SUPPLY Pilot Gas Line BLACK INCOMING 120V AC WHITE (FUSE BOX GREEN VENT SAFETY OR BREAKER) SHUTOFF SWITCH MANUAL DAMPER SWITCH ELECTRICAL RATING: 120v, 60Hz, 0.7A 24V AC STEP DOWN TRANSFORMER 120V AC OPTIONAL... -
Page 23: Troubleshooting
TROUBLESHOOTING Note: Before troubleshooting the system, make sure the gas shutoff valve is ON. The two most common causes of a malfunctioning gas appliance are: 1. Loose wiring connections 2. Construction debris clogging the pilot and/or gas control valve filter OBSERVED PROBLEM POSSIBLE CAUSE REMEDY... - Page 24 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions.
-
Page 25: Accessories
FD42 - 42" Black Finish FD42B - 42" Brushed Brass Finish FD42P - 42" Platinum Finish BRICK LINER KIT (RED) (For Mission36TEN and Mission42TEN) BL36 - 36" Refractory Standard Brick BL42 - 42" Refractory Standard Brick BL36H - 36" Refractory Herringbone Brick BL42H - 42"... -
Page 26: Parts
PARTS MODELS MISSION36TEN (CATALOG NUMBERS F0858, F0860 AND F0862), MISSION42TEN (CATALOG NUMBERS F0864, F0866 AND F0868) 35 34 f i r e - p a r t s . c o m www.Astria.US.com 126754-01B... - Page 27 PARTS This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 21 of this manual. F0858, F0860 F0864, F0866 and F0862 and F0868 DESCRIPTION 14153 14153 Micro Switch 109098-01 109098-01 Wire Harness 108863-01...
- Page 28 PARTS This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 21 of this manual. Catalog numbers are referenced for clarity. f i r e - p a r t s . c o m 36"...
- Page 29 PARTS LOGSETS FOR MODELS MISSION36TEN (CATALOG NUMBERS F0858, F0860 AND F0862) f i r e - p a r t s . c o m NO. PART NO. DESCRIPTION QTY. 107999-01 Log Set 108724-01 Right Front 9" Split Log 901098-01 Rear Log 108720-01 Top Right Log - 11 "...
- Page 30 PARTS LOGSETS FOR MODELS MISSION42TEN (CATALOG NUMBERS F0864, F0866 AND F0868) f i r e - p a r t s . c o m NO. PART NO. DESCRIPTION QTY. 107999-02 Log Set 901098-02 Rear Log 108723-01 Left Front Log - 11" 108839-01 Right Front Log - 15 "...
-
Page 31: Warranty
Innovative Hearth Products Astria™ Brand Gas Fireplace Limited Lifetime Warranty THE WARRANTY Innovative Hearth Products ("IHP") Limited Lifetime Warranty warrants your Astria™ brand gas fireplace ("Product") to be free from defects in materials and workmanship at the time of manufacture. The Product body and firebox carry the Limited Lifetime Warranty. Ceramic glass carries the Limited Lifetime Warranty against thermal breakage only. - Page 32 KEEP THIS WARRANTY Model (located on product or identification tag) ______________________ Serial No. (located on product or identification tag) ___________________ Date Purchased ______________________ Keep receipt for warranty verification. f i r e - p a r t s . c o m Innovative Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
