Summary of Contents for HighGear AltiTech 2
- Page 1 summit/altitech...
-
Page 2: Table Of Contents
Managing the Chronograph Data Log Reviewing Runs Clearing Laps and Runs 15-16 DAILY ALARM 17-18 Turning Alarm On/Off Setting the Daily Alarm 17-18 RESETTING THE INSTRUMENT SPECIFICATIONS AND RANGES 19-22 TROUBLE SHOOTING 23-25 23-24 26-27 28-29 28-29 30-31 32-33 summit/altitech 2... - Page 3 We use only the finest Swiss sensors to create the most accurate and dependable products possible. The Summit/Altitech 2 features an altimeter/barometer/weather station along with a full selection of advanced watch and chronograph functions.
- Page 4 Clean your instrument using a moist cloth. Care should be taken when cleaning the lens not to rub dirt into the surface as it can become scratched and hard to read. CHANGING WATCH BATTERY The Summit/Altitech 2 uses a common CR2032 3V Lithium battery. Normal battery life is approximately 1yr. NOTE: Heavy use of the Altimeter, Compass or Backlight system may significantly reduce battery life.
-
Page 5: The Display Icons
Current Altitude measured in feet FEET Current Altitude measured in meters METERS BAROMETER ICONS symbol description what it means Barometric pressure units MILLIBAR Fahrenheit temperature units DEGREES F Centigrade temperature units DEGREES C summit/altitech 2... -
Page 6: Key Actions
TABLE OF CONTENTS KEYS AND THEIR FUNCTIONS The Summit/Altitech 2 is equipped with 4 individual keys. Each key has several functions listed below. S1 KEY - Changes View in Time, Barometer, Altimeter, Altimeter Log and Chronograph Log modes - Start/Stop information storage in Altimeter mode... -
Page 7: Modes Of Operation
1.5 seconds before advancing automat- ically to the modes primary screen. QUICK TIME BAROMETER QUICK PRESS of the key. Upon entering a mode, the COMPASS ALTIMETER summit/altitech 2... -
Page 8: Time Functions
TABLE OF CONTENTS TIME FUNCTIONS VIEW TIME 1 / TIME 2 The Summit/Altitech 2 is equipped with a full feature watch package including Time of Day, Day/Date/Day of Week, Two Time Zones and Two Daily Alarms. The Time Zone being displayed is indicated by a small T1/T2 in the upper left corner of the display. -
Page 9: Secondary Time Screens
For accurate temperature readings, remove the instrument from your body and place in a shaded area for 10-15 minutes. (continued) SCREEN 3 Top Line: GRAPH OF BAROMETRIC PRESSURE FOR THE PAST 24HOURS Center Line: TIME OF DAY Bottom Line: TEMPERATURE summit/altitech 2... -
Page 10: Compass
REACTIVATING COMPASS To save power, the compass feature of the Summit/Altitech 2 only remains active for a period of 10 seconds. To reactivate the compass display, (continued) center line and END in the upper line and automatically advance to the compass display. -
Page 11: Barometer
BAROMETER TABLE OF CONTENTS The Summit/Altitech 2 are equipped with a highly sensitive barometer/weather station. The barometer measures the local Barometric Pressure and calculates the Barometric Pressure corrected to Mean Sea Level (MSL). Barometric pressure is displayed in Millibar/HectoPascals (mbar/hpa). -
Page 12: Barometric Pressure Graph
PRESS & HOLD key. Continue to hold the key until the temperature units icon stops flashing. NOTE: The TEMPERATURE units chosen while in the BAROMETER mode will be the units displayed in the TIME OF DAY mode. of the summit/altitech 2... -
Page 13: Altimeter
TABLE OF CONTENTS ALTIMETER Because the ALTIMETER system in the Summit/Altitech 2 relies on barometric pressure for its measurements, it is critical that you regularly calibrate the unit to a known altitude. For maximum accuracy, daily calibration is a must. If you are using the unit during times of changeable weather, the unit may need to be calibrated more often. -
Page 14: Max/Acc Scrolling Message
TABLE OF CONTENTS ALTIMETER DATA LOG MEMORY The Summit/Altitech 2 is equipped with an Altitude Data Point memory system. This system allows you to capture to memory the altitude of a particular location along with the date and time of the capture. -
Page 15: Chronograph
ALTIWARE SERIES TABLE OF CONTENTS CHRONOGRAPH The Summit/Altitech 2 features a sophisticated digital CHRONOGRAPH timing system capable of storing multiple timed workouts. The chronograph has a resolution of 0.01 seconds and displays both key. The display will lap time and split time on screen simultaneously. -
Page 16: Chronograph Data Log Memory
4. The bottom line will show the number of the LAP/SPLIT. After reviewing all LAP/SPLIT information the display will show the BEST TIME OF ALL LAPS. The final display will show the AVERAGE TIME OF ALL LAPS which were timed. key it summit/altitech 2... -
Page 17: Daily Alarm
ALTIWARE SERIES TABLE OF CONTENTS DAILY ALARM The Summit/Altitech 2 is equipped with two individual daily alarms which can be set to the hour and minute for either Time Zone 1 or Time Zone 2. TURNING AN ALARM ON/OFF 1. Starting in ALARM mode. -
Page 18: Specifications And Ranges
BAROMETER Range 300 to 1100mbar Resolution 1mbar CHRONOGRAPH Range 24 hours Resolution 0.01 second for first hour; 1.0 second for hours 2-23 CHRONOGRAPH LOG 100 Laps/Splits 30 Runs/Workouts showing Lap/split times, Best Lap/Split, Average Lap/Splits summit/altitech 2... -
Page 19: Trouble Shooting
The Summit/Altitech 2 is equipped with a display which allows it to be used in a wide variety of environments. However, if the unit is used in extreme cold (<32 F or 1c) the function of the display may be slower than normal. - Page 20 2 HIGHGEAR USA/TECHTRAIL INC. web: www.highgear.com www.techtrail.com email: contacts@highgear.com contacts@techtrail.com © 2006 Highgear USA/TechTrail Inc. All Rights Reserved.
