XOCECO LC-27K16 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LCD TELEVISION
LC-27K16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC-27K16 and is the answer not in the manual?

Questions and answers

Related Manuals for XOCECO LC-27K16

Summary of Contents for XOCECO LC-27K16

  • Page 1 LCD TELEVISION LC-27K16...

  • Page 2: Table Of Contents

    CONTENTS Safety instructions………………………………………………………………………..… Adjustment instructions …………………………….…….…………………………….… Trouble shooting ……………………………………………………….…………………… LC-27K16 working principle analysis……………………………….………….…………. LC-27K16 block diagram…………………………………..……………………….………… IC block diagram………………………………………………………………………..…… Main assembly……………………………………………………………………………..… Identification criteria for the bright spot and dark spot of the LCD screen………..…. Wiring diagram ……………………………………………………………..……………... Troubleshooting charts………………………………………………………………..…… Schematic diagram …………………………………………………………………….…..

  • Page 3: Safety Instructions

    This service manual is only for service personnel to take reference with. Before Attention: servicing please read the following points carefully. Safety instructions 1. Instructions Be sure to switch off the power supply before replacing or welding any components inserting/plugging in connection wire Anti static measures to be taken (throughout the entire production process!): a) Do not touch here and there by hand at will;...
  • Page 4 would be unable to work and no way to get it repaired. 2.11 Special care must be taken in transporting or handling it. Exquisite shock vibration may lead to breakage of screen glass or damage to driving circuit. Therefore it must be packed in a strong case before the transportation or handling.

  • Page 5: Adjustment Instructions

    Alignment instruction 1 Alignment equipment PM5518 (video signal generator) K-7253 (VGA signal generator) CA210 (white balancer) 2 Alignment flow-chart The alignment flow-chart is shown as fig-1 Check DDC, HDCP KEY and FLASH To produce CPU board and analog board Check the CPU board and analog board All testing Connect with central signal source, then check each function of TV such as analog control etc., check the output of headphone and speaker...
  • Page 6 3.1 EEPROM initialization Enter the first page of factory menu, select “clear eeprom” and then press “enter”, shut down the unit after “ok” appears. 3.2 VGA/DVI channel adjustment 3.2.1 Preset VGA channel mode Input VGA signal (PATTERN 5: Final Test) of K-7253, select TIME301(640*350/70Hz), press “AUTO”...

  • Page 7: Trouble Shooting

    offset_R, offset_G,offset_B, gain_R and gain_G, repeatedly using the same method until the value of the two levels gray-scale be the specified value. 3.4 white balance adjustment YPbPr channel input YpbPr signal of K-7253 to YPbPr-1 terminal, input TIME380(480i) PATTERN471 8 level gray-scale signal, set the value of S-bright to 120 and S-contrast to 140.Enter adjustment menu of white balance, adjust the third level using white balancer.
  • Page 8 Fringe in picture Check if the antenna is correctly oriented. Maybe there is electric wave reflected from hilltop or building. Picture is interfered by stripe Possibly due to interference from automobile, train, high shaped bright spots voltage transmission line, neon lamp etc. Maybe there is interference between antenna and power supply line.

  • Page 9: Lc-27K16 Working Principle Analysis

    LC-27K16 working principle analysis Please refer to LC-27K16 BLOCK DIAGRAM in order to know the working principle of LC-27K16 brief introduction to its signal flow is shown as follows: RF signal produces composite color television signal through TUNER201, the signal together with AV1/SVHS (SVHS priority), AV2 etc.
  • Page 10 decode. After decoded by U32, the signal will be sent back to U29 in the form of R G B and FB, then it will be added to the decoded picture and then it will be sent to U13 FL12310 in the form of ITU-R656 signal format of 8BIT to do line-by-line process.

  • Page 11: Lc-27K16 Block Diagram

    LC-27K16 BLOCK DIAGRAM U15 DVI DRIVER 24bit LVDS TFP501 DRIVER 24bit TUNER SCALER DS90C385A JAG-ASM 24bit DEINTER ITU-R656 LACER AV1-V/S-Y 8bit FLI2310 SVHS-C AV2 -V SDRAM SDRAM SDRAM AV-V OUT I IC BUS U32 CCD V-CHIP FLASH Z86229 MEMORY MICRO-...

  • Page 12: Ic Block Diagram

    IC block diagram 1.MSP3420 Pins description: 47: DVI/YPRPB1/YPRPB2-L input 48: DVI/YPRPB1/YPRPB2-R input 50: VGA-L input 51: VGA-R input 53: AV2-L input 54: AV2-R input 56: AV1-L input 57: AV1-R input 67: SIF input...
  • Page 13 25: earphone-L input 24: earphone-R input 27: R output 28: L output 36: AV-R output 37: AV-L 2: SCL 3: SDA 11,12,13; 39; 65,66: +5V—MSP 2.VPC3230 Pins description: 70: AV-V output...
  • Page 14 71: C output 72: Y/AV1-V output 74: AV2-V output 75: TV-V output 31-34,37-40: ITU-R656 format signal output 27: CLK output 13: SCL 14: SDA 10,29,45; 52: 3.3V_VPC 59,69,76: 5V 3.AD9883 Pins description: 54,48,43: YPRPB input...
  • Page 15 9-2: Y output 19-12: U output 77-70: V output 56: SCL 57: SDA 66: H-SYNC output 64: V-SYNC output 65: DE output 67: CLK output 11,26,34: 3.3V 4.FLI2310-Simplified Internal Block Diagram...
  • Page 16 Pins description: 196,199-205: ITU-R656 format signal input 11-15,18-20: U input 21-28: V input 29,32-35,38-40: Y input 1: YPRPB H-SYNC input 2: YPRPB V-SYNC input 4: YPRPB-CLK input 5: YPRPB-DE input 195: AV/TV-CLK input 114: SDRAM-CLK input 136,137,140-145: R output 148-155: G output 126,127,130-135: B output 125: CLK output 111: SDRAM-CLK output...
  • Page 17 5.JAG-ASM Pins description: A12, A13: VGA-R input A16, A17: VGA-G input...
  • Page 18 A20, A21: VGA-B input P1, P2, N2, N3, M1-M4: DVI-B input L1-L4, K2-K4, J1: DVI-R input J2-J4, H1-H3, G1, G2: DVI-G input AA2, AA3, Y1-Y3, N1-N3: AV/TV/YPRPB-B input N4, V1-V4, U1-U3: AV/TV/YPRPB-G input U4, T1-T4, R1-R3: AV/TV/YPRPB-R input AB3: DVI H-SYNC input AB1: DVI V-SYNC input G4: DVI-CLK input F1: DVI-DE input...
  • Page 19 6.TFP403 Pins description: 80,8183,84,86,87,89,90: DVI input 92: DDC-SCL 93: DDC-SDA 95: PROM-SCL 96: PROM-SDA 2: POWER DOWN input 9: OUTPUT DRIVE POWER DOWN input 8: sync detection output 10-17: B output 20-27: G output 30-37: R output 44: CLK output 46: data enable output 47: H-SYNC output 48: V-SYNC output...
  • Page 20 7.DS90C383 51,52,54-56,3,50,2: R input 4,6,7,11,12,14,8,10: G input 15,19,20,22-24,16,18: B input 27: H-SYNC input 28: V-SYNC input 30: data enable input 31: CLK input 32: power supply enable input 37,38,41,42,45,46,47,48: 4 pair differential signal output 39, 40: 1pair clock signal output 1, 9, 26, 34, 44: 3.3V...
  • Page 21 8.Z86229 Pins description: 7 PIN: VDIEO INPUT 2 PIN: G OUTPUT 3 PIN: B OUTPUT 18 PIN: R OUTPUT 17 PIN: FB OUTPUT...

  • Page 22: Main Assembly

    Main assembly NAME MAIN COMPONENT AND it’S NO. Sound conversion board 667-L27K6-15 N201 MSP3420G-Q (353-34200-10) N203 M62494FP (353-62494-20) N213 N214 MPS7720 (353-77200-10) CPU board 667-L23K6-56 AT49F002NT (352-49002-70) TSC80251G2D (353-80251-10) Z8622912SS (353-86229-10) DS90C385 (353-03850-20) MST9883B (353-98830-10) VPC3230D (353-32300-80) TFP501 (353-05010-00) FLI2310 (353-23100-00) JAG-ASM (353-0JAG0-00) IR board...

  • Page 23: Identification Criteria For The Bright Spot And Dark Spot Of The Lcd Screen

    Identification criteria for the bright spot and dark spot of the LCD screen Q’ty allowed Distance between two spots Category criteria 15" 20" 22" 30" 40" 15" 20" 22" 30" 40" One single ≤5 ≤2 ≤5 ≤2 ≤3 spot Bright 2 neighboring ≥15mm ≤2...

  • Page 24: Wiring Diagram

    Wiring diagram...

  • Page 25: Troubleshooting Charts

    Troubleshooting guide 1. No raster Turn-on power supply, check if the red indicator is light in the STANDBY? blue Check PIN6-8(24V output) of Check the indicator in the power supply board X903 turn-on condition Check if the indicator is flicker Non-change color in the sensor control normal condition?
  • Page 26 2. raster, but no picture Check if the unit Check can operation? channels have signal? Which is no VGA/DVI Replacing CPU Enter factory-menu, signal board operation CLEAR channels EEPROM, then turn YPRPB Replacing off , turn on again , it if CPU board display picture.
  • Page 27 3.no sound Check if PIN1 is level 1/2VCC(12V) of N213 Check PIN5 Replacing N213 and N214 PIN8 output of N203 and N214 Check power supply Check PIN27 PIN28 output wave of Replacing N203 N201 Check PIN67 wave of N201 Replacing N201 Replacing TUNER202...
  • Page 49 Exploded views LC-27K16...
  • Page 50 PART LIST OF EXPLODED VIEW DESCRIPTION PART NO. REAR CABINET COVER(LEFT) 808-10687-AF0A REAR CABINET COVER(RIGHT) 808-10689-AF0A BUTTON 877-60621-00B REAR CABINET 780-T06WHJAF9C LED COLUMN 700-60247-100 FRONT NAMEPLATE 880-10661-B1 FRONT CABINET 780-X16W0J1A0 SPEAKER 384-31904-B0 SPEAKER BRACKET 870-20954-00A RUBBER WASHER 868-20453-00 LCD PANEL 335-27001-00 VIDEO PROCESSING BOARD 667-L27K6-40...

  • Page 51: Part List

    PART LIST PART# DESCRIPTION LOCA.NO. 203-L27K160-10 LC-27K16, LC-27K16 BRAND PRIMA 100-L27K160-01 LC-27K16 21 SOFTWARE 　 NA PRIMA SL27K60-10A10 335-27001-00 DISPLAY SCREEN V270W1-L04 485-10144-00 POWER CORD LAP-31+LAS-13 615-10481-00 LCD SCREEN HOLDER ASS'Y 615-10482-00A WALL MOUNT BRACKET ASS'Y 655-B1201-46 (12-PINS) LEAD WITH HOUSING...
  • Page 52 FRONT CABINET ABS V0 SILVERY WHITE 03/ BLACK 880-10661-B1 FRONT LOGO ( NEWPRIMA SILVERY BLACK BOTTOM27") 881-62809-00 CUL LABEL 881-62875-102 BACK PLATE LABEL (LC-27K16,PRIMA) 881-63016-00A POWER SYMBOL LABEL ( T2751) 881-63896-00 BAR CODE LABEL (69020727160) 881-80667-00 REGISTER CARD ( PRIMA )
  • Page 53 881-80674-00 SERVICE CARD ( LCD27-32 ) 886-31492-52 CARTON BOX (LC-27K16,PRIMA) 887-20047-01 ACCESSORY PALSTIC BAG 887-20047-01A ACCESSORY PALSTIC BAG ( ) 301-UL27K6-38RA RC-U38R-0AREMOTE CONTROL UNIT (PRIMA NEW ) 353-34282-30 SMD ICM34282M1-D48GP (M) 535-L27M6-03 WALL MOUNT ASS'Y 615-1A288-00A WALL MOUNT ASS'Y 852-34008-81 SCREW B(+) M4X8-D.Zn...
  • Page 54 870-20954-00A SPEAKER BRACKET 667-L27K16-09 IR RECEIVE ASS'Y 340-10113-20 LED HFT503MPBR-1 LED1 352-51170-00 IC HRM538BB5117 (D) 364-351BQ-00 5-PINS CONNECTORS 1.25T-1-5AW 454-04622-MA SMD ELECTROLYTIC CAPACITOR CDPS-16V-22uF-M 455-12110-H0 SMD RESISTOR FTR0603101JR 455-12110-H0 SMD RESISTOR FTR0603101JR 455-12147-H0 SMD RESISTOR FTR0603471JR 455-12310-H0 SMD RESISTOR FTR0603103JR 456-1410K-B1 SMD CAPACITOR C1608X7R1C104KT 655-54301-13...
  • Page 55 462-B0447-H02 POLYESTER CAPACITOR CL21X-50V-0.47uF-J C378 464-DF810-M1 ELECTROLYTIC CAPACITOR CD110H-35V-1000uF-M C379 464-DF810-M1 ELECTROLYTIC CAPACITOR CD110H-35V-1000uF-M C380 464-DF810-M1 ELECTROLYTIC CAPACITOR CD110H-35V-1000uF-M C296 464-DF810-M1 ELECTROLYTIC CAPACITOR CD110H-35V-1000uF-M C385 464-6C722-M02 ELECTROLYTIC CAPACITOR CD110-10V-220uF-M C214 464-6C722-M02 ELECTROLYTIC CAPACITOR CD110-10V-220uF-M C217 464-6C722-M02 ELECTROLYTIC CAPACITOR CD110-10V-220uF-M C241 464-6D522-M02 ELECTROLYTIC CAPACITOR CD110-16V-2.2uF-M C245...
  • Page 56 340-00362-00 SMD DIODE MBRST130LT3 D207 340-00362-00 SMD DIODE MBRST130LT3 D208 340-00362-00 SMD DIODE MBRST130LT3 D209 340-00362-00 SMD DIODE MBRST130LT3 D210 340-50625-00 SMD ZENER DIODE BZV55-C6V2 D203 340-50625-00 SMD ZENER DIODE BZV55-C6V2 D204 342-08470-90 SMD TRANSISTOR BC847AW V206 342-08470-90 SMD TRANSISTOR BC847AW V208 342-08570-90 SMD TRANSISTOR BC857 AW...
  • Page 57 455-12310-H0 SMD RESISTOR FTR0603103JR R272 455-12310-H0 SMD RESISTOR FTR0603103JR R352 455-12310-H0 SMD RESISTOR FTR0603103JR R353 455-12310-H0 SMD RESISTOR FTR0603103JR R338 455-12310-H0 SMD RESISTOR FTR0603103JR R339 455-12310-H0 SMD RESISTOR FTR0603103JR R354 455-12310-H0 SMD RESISTOR FTR0603103JR R355 455-12310-H0 SMD RESISTOR FTR0603103JR R356 455-12310-H0 SMD RESISTOR FTR0603103JR R357...
  • Page 58 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C316 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C267 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C335 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C334 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C340 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C216 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C250 456-2422M-C1 SMD CAPACITOR 06032E224M250BA C258 456-2447R-C1 SMD CAPACITOR 06032E474Z250BA C218...
  • Page 59 666-13208-00 SMD FERRITE BEAD STBH3216-301PT L204 666-13208-00 SMD FERRITE BEAD STBH3216-301PT L208 782-L27K6-150F SOUND SWITCH BOARD PCB 667-L27K6-40 VIDEO PROCESSING CIRCUIT BOARD ASS'Y 352-21420-00 IC TLE2142 CP N212 364-11212-00 EARPHONE JACK ST-112 X210 364-41207-00 ANTENNA SOCKET HR-F 364-91202-00 S-VIDEO TERMINAL CKX5-2K-2 X206 364-93219-00 AV JACK AV3-14WKD...
  • Page 60 455-12000-H0 SMD RESISTOR FTR0603000XR R304 455-12000-H0 SMD RESISTOR FTR0603000XR R305 455-12068-H0 SMD RESISTOR FTR0603680JR R316 455-12310-H0 SMD RESISTOR FTR0603103JR R310 455-12310-H0 SMD RESISTOR FTR0603103JR R311 455-12310-H0 SMD RESISTOR FTR0603103JR R312 455-12310-H0 SMD RESISTOR FTR0603103JR R313 455-12347-H0 SMD RESISTOR FTR0603473JR R222 455-12347-H0 SMD RESISTOR FTR0603473JR R223...
  • Page 61 340-00287-00 DIODE 1N5822 340-00287-00 DIODE 1N5822 352-49002-70 IC AT49F002NT-70PC 352-49002-70 IC AT49F002NT-70PC 364-03205-00 IC SOCKET 32T6 364-11212-00 EARPHONE JACK ST-112 364-11212-00 EARPHONE JACK ST-112 364-3B186-00 12-PINS CONNECTORS TJC10-12AW 364-3B186-00 12-PINS CONNECTORS TJC10-12AW 364-3D101-00 10-PINS CONNECTORS TJC3-10A 364-34101-00 4-PINS CONNECTORS TJC3-04A 364-34101-00 4-PINS CONNECTORS TJC3-04A 364-35186-00...
  • Page 62 464-6D610-M0 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C261 464-6D610-M0 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C364 464-6D610-M0 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C365 464-6D610-M0 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C384 464-6D610-M0 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C385 464-6D610-M0 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C362 464-6D610-M0 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C363 464-6D610-M0 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C366 464-6D610-M0 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C301...
  • Page 63 464-6D722-M0 ELECTROLYTIC CAPACITOR CD110-16V-220uF-M C207 464-6D810-M1 ELECTROLYTIC CAPACITOR CD110-16V-1000uF-M C200 464-6F747-M1 ELECTROLYTIC CAPACITOR CD110-35V-470uF-M C196 464-6F747-M1 ELECTROLYTIC CAPACITOR CD110-35V-470uF-M C194 464-6F747-M1 ELECTROLYTIC CAPACITOR CD110-35V-470uF-M C380 464-6F747-M1 ELECTROLYTIC CAPACITOR CD110-35V-470uF-M C419 464-6F747-M1 ELECTROLYTIC CAPACITOR CD110-35V-470uF-M C382 477-40230-00 FIXED INDUCTANCE LH470-1 477-40230-00 FIXED INDUCTANCE LH470-1 477-40230-00 FIXED INDUCTANCE LH470-1...
  • Page 64 342-01380-00 *SMD TRANSISTOR BSS138LT1 342-01380-00 *SMD TRANSISTOR BSS138LT1 342-01440-10 SMD TRANSISTOR DTC144EKA 342-01440-10 SMD TRANSISTOR DTC144EKA 342-01440-10 SMD TRANSISTOR DTC144EKA 342-08470-90 SMD TRANSISTOR BC847AW 342-08470-90 SMD TRANSISTOR BC847AW Q151 342-08570-90 SMD TRANSISTOR BC857 AW 342-39040-00 SMD TRANSISTOR MMBT3904 342-39040-00 SMD TRANSISTOR MMBT3904 353-0JAG0-00 SMD ICJAG-ASM 353-00120-40...
  • Page 65 364-T3001-00 SMD 30-PINSFF-A1255-WRS 455-10022-H9 SMD RESISTOR NCA4R220JR 455-10022-H9 SMD RESISTOR NCA4R220JR RP11 455-10022-H9 SMD RESISTOR NCA4R220JR RP13 455-10022-H9 SMD RESISTOR NCA4R220JR RP12 455-10022-H9 SMD RESISTOR NCA4R220JR RP10 455-10022-H9 SMD RESISTOR NCA4R220JR RP17 455-10022-H9 SMD RESISTOR NCA4R220JR RP19 455-10022-H9 SMD RESISTOR NCA4R220JR RP21 455-10022-H9 SMD RESISTOR NCA4R220JR...
  • Page 66 455-12012-H0 SMD RESISTOR FTR0603120JR 455-12012-H0 SMD RESISTOR FTR0603120JR 455-12012-H0 SMD RESISTOR FTR0603120JR 455-12012-H0 SMD RESISTOR FTR0603120JR 455-12012-H0 SMD RESISTOR FTR0603120JR 455-12012-H0 SMD RESISTOR FTR0603120JR 455-12022-H0 SMD RESISTOR FTR0603220JR 455-12022-H0 SMD RESISTOR FTR0603220JR 455-12022-H0 SMD RESISTOR FTR0603220JR 455-12022-H0 SMD RESISTOR FTR0603220JR 455-12022-H0 SMD RESISTOR FTR0603220JR 455-12022-H0...
  • Page 67 455-12075-H0 SMD RESISTOR FTR0603750JR R308 455-12075-H0 SMD RESISTOR FTR0603750JR R309 455-12075-H0 SMD RESISTOR FTR0603750JR R302 455-12075-H0 SMD RESISTOR FTR0603750JR R303 455-12075-H0 SMD RESISTOR FTR0603750JR R304 455-12075-H0 SMD RESISTOR FTR0603750JR R305 455-12075-H0 SMD RESISTOR FTR0603750JR R241 455-12075-H0 SMD RESISTOR FTR0603750JR R242 455-12075-H0 SMD RESISTOR FTR0603750JR R243...
  • Page 68 455-12110-H0 SMD RESISTOR FTR0603101JR R177 455-12110-H0 SMD RESISTOR FTR0603101JR R231 455-12110-H0 SMD RESISTOR FTR0603101JR R235 455-12110-H0 SMD RESISTOR FTR0603101JR R236 455-12110-H0 SMD RESISTOR FTR0603101JR R237 455-12110-H0 SMD RESISTOR FTR0603101JR R171 455-12110-H0 SMD RESISTOR FTR0603101JR R198 455-12118-H0 SMD RESISTOR FTR0603181JR 455-12122-H0 SMD RESISTOR FTR0603221JR 455-12143-H0 SMD RESISTOR FTR0603431JR...
  • Page 69 455-12247-H0 SMD RESISTOR FTR0603472JR R155 455-12247-H0 SMD RESISTOR FTR0603472JR R156 455-12247-H0 SMD RESISTOR FTR0603472JR R201 455-12247-H0 SMD RESISTOR FTR0603472JR R202 455-12247-H0 SMD RESISTOR FTR0603472JR R227 455-12247-H0 SMD RESISTOR FTR0603472JR R228 455-12247-H0 SMD RESISTOR FTR0603472JR R229 455-12268-H0 SMD RESISTOR FTR0603682JR R240 455-12275-H0 SMD RESISTOR FTR0603752JR 455-12310-H0...
  • Page 70 455-12347-H0 SMD RESISTOR FTR0603473JR R345 455-12347-H0 SMD RESISTOR FTR0603473JR R346 455-12347-H0 SMD RESISTOR FTR0603473JR R347 455-12347-H0 SMD RESISTOR FTR0603473JR R348 455-12347-H0 SMD RESISTOR FTR0603473JR R349 455-12347-H0 SMD RESISTOR FTR0603473JR R350 455-12347-H0 SMD RESISTOR FTR0603473JR R351 455-12347-H0 SMD RESISTOR FTR0603473JR R352 455-12347-H0 SMD RESISTOR FTR0603473JR R353...
  • Page 71 456-2022H-11 SMD CAPACITOR 0603CG220J250BA C456 456-2022H-11 SMD CAPACITOR 0603CG220J250BA C457 456-2022H-11 SMD CAPACITOR 0603CG220J250BA C458 456-2022H-11 SMD CAPACITOR 0603CG220J250BA C459 456-2022H-11 SMD CAPACITOR 0603CG220J250BA C460 456-2022H-11 SMD CAPACITOR 0603CG220J250BA C461 456-2022H-11 SMD CAPACITOR 0603CG220J250BA C462 456-2022H-11 SMD CAPACITOR 0603CG220J250BA C463 456-2310R-C1 SMD CAPACITOR 06032E103Z250BA C401...
  • Page 72 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C186 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C188 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C381 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C383 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C125 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C208 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C206 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C215 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C216...
  • Page 73 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1...
  • Page 74 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C100 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C101 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C102 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C103 456-2410R-C1...
  • Page 75 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C148 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C147 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C149 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C146 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C152 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C153 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C154 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C151 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C393...
  • Page 76 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C300 456-2410R-C1 SMD CAPACITOR C1608Y5V1E104ZT C303 456-2422M-C1 SMD CAPACITOR 06032E224M250BA C320 456-2422M-C1 SMD CAPACITOR 06032E224M250BA C321 456-2422M-C1 SMD CAPACITOR 06032E224M250BA C322 456-2422M-C1 SMD CAPACITOR 06032E224M250BA C228 456-2422M-C1 SMD CAPACITOR 06032E224M250BA C242 456-2422M-C1 SMD CAPACITOR 06032E224M250BA C245 456-2468R-C1 SMD CAPACITOR 06032E684Z250BA C319...
  • Page 77 456-3210H-11 SMD CAPACITOR 0603CG102J500BA C266 456-3215H-11 SMD CAPACITOR 0603CG152J500BA C256 456-3215H-11 SMD CAPACITOR 0603CG152J500BA C237 456-3215H-11 SMD CAPACITOR 0603CG152J500BA C227 456-3215H-11 SMD CAPACITOR 0603CG152J500BA C387 456-3215H-11 SMD CAPACITOR 0603CG152J500BA C388 456-3282K-B1 SMD CAPACITOR 06032R822K500BA C328 456-3282K-B1 SMD CAPACITOR 06032R822K500BA C270 456-3310K-B1 SMD CAPACITOR 06032R103K500BA 456-3310K-B1...
  • Page 78 666-12008-00 SMD FERRITE BEAD STBH2012-501PT FB31 666-12008-00 SMD FERRITE BEAD STBH2012-501PT FB53 666-12008-00 SMD FERRITE BEAD STBH2012-501PT FB52 666-12008-00 SMD FERRITE BEAD STBH2012-501PT FB36 666-12008-00 SMD FERRITE BEAD STBH2012-501PT FB34 666-12008-00 SMD FERRITE BEAD STBH2012-501PT FB56 666-12008-00 SMD FERRITE BEAD STBH2012-501PT FB73 666-12008-00 SMD FERRITE BEAD STBH2012-501PT...
  • Page 79 666-13207-00 SMD FERRITE BEAD STPB3216-380PT 666-13207-00 SMD FERRITE BEAD STPB3216-380PT FB16 666-13207-00 SMD FERRITE BEAD STPB3216-380PT FB75 666-13207-00 SMD FERRITE BEAD STPB3216-380PT FB74 666-13207-00 SMD FERRITE BEAD STPB3216-380PT FB76 666-13207-00 SMD FERRITE BEAD STPB3216-380PT FB24 666-13207-00 SMD FERRITE BEAD STPB3216-380PT FB27 666-13207-00 SMD FERRITE BEAD STPB3216-380PT...
  • Page 80 462-2B433-K0V POLYESTER CAPACITOR MKP62-275V-0.33uF-K ! C902 462-25447-H1 POLYESTER CAPACITOR CL21-400V-474J-P15(II C918 462-25447-H1 POLYESTER CAPACITOR CL21-400V-474J-P15(II C924 464-DE647-M0 ELECTROLYTIC CAPACITOR CD110H-25V-47uF-M C928 464-DE647-M0 ELECTROLYTIC CAPACITOR CD110H-25V-47uF-M C909 464-DE647-M0 ELECTROLYTIC CAPACITOR CD110H-25V-47uF-M C932 464-DF722-M0 ELECTROLYTIC CAPACITOR CD110H-35V-220uF-M C929 464-DF722-M0 ELECTROLYTIC CAPACITOR CD110H-35V-220uF-M C942 464-DF810-M1 ELECTROLYTIC CAPACITOR CD110H-35V-1000uF-M...
  • Page 81 808-80234-00 SILICA PIECE TO-2535 808-80234-00 SILICA PIECE TO-2535 808-80258-00 HEAT CONDUCTIVE GASKET 35X40X2 INSULATING CAP 　 TO-220A 822-10197-00 838-10400-00 SPRING 852-43006-81 SCREW F(+) M3*6-DZn 852-53006-81 SCREW SJ2830 M3X6-D.Zn 340-00001-0S SMD DIODE LL4148 D902 340-00001-0S SMD DIODE LL4148 D911 340-00001-0S SMD DIODE LL4148 D909 340-00001-0S SMD DIODE LL4148...
  • Page 82 455-22247-H0 SMD RESISTOR RC11-1/8W-4.7K-J R939 455-22247-H0 SMD RESISTOR RC11-1/8W-4.7K-J R909 455-22247-H0 SMD RESISTOR RC11-1/8W-4.7K-J R916 455-22291-H0 SMD RESISTOR RC11-1/8W-9.1K-J R903 455-22310-H0 SMD RESISTOR RC11-1/8W-10K-J R952 455-22310-H0 SMD RESISTOR RC11-1/8W-10K-J R937 455-22310-H0 SMD RESISTOR RC11-1/8W-10K-J R936 455-22315-H0 SMD RESISTOR RC11-1/8W-15K-J R910 455-22315-H0 SMD RESISTOR RC11-1/8W-15K-J R906...
  • Page 83 JUMPER WIRE J904 JUMPER WIRE J905 JUMPER WIRE J906 JUMPER WIRE J907 JUMPER WIRE J909 JUMPER WIRE J910 JUMPER WIRE J911 JUMPER WIRE J912...
