XOCECO LC23U7D Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LCD TELEVISION
LC23U7D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC23U7D and is the answer not in the manual?

Questions and answers

Related Manuals for XOCECO LC23U7D

Summary of Contents for XOCECO LC23U7D

  • Page 1 LCD TELEVISION LC23U7D...

  • Page 2: Table Of Contents

    CONTENTS Safety instructions………………………………………………………………………..… Adjustment instructions …………………………….…….…………………………….… Trouble shooting ……………………………………………………….…………………… Working principle analysis……………………………………………………….…………. Block diagram…………………………………..……………….……………….………… IC block diagram………………………………………………………………………..…… Main assembly……………………………………………………………………………..… Identification criteria for the bright spot and dark spot of the LCD screen………..…. Wiring diagram ……………………………………………………………..……………... Troubleshooting charts………………………………………………………………..…… Schematic diagram (CPU and TV board) ……………………………………………..…… Schematic diagram ( power supply board)………………….…........

  • Page 3: Safety Instructions

    This service manual is only for service personnel to take reference with. Before Attention: servicing please read the following points carefully. Safety instructions 1. Instructions Be sure to switch off the power supply before replacing or welding any components inserting/plugging in connection wire Anti static measures to be taken (throughout the entire production process!): a) Do not touch here and there by hand at will;...
  • Page 4 would be unable to work and no way to get it repaired. 2.11 Special care must be taken in transporting or handling it. Exquisite shock vibration may lead to breakage of screen glass or damage to driving circuit. Therefore it must be packed in a strong case before the transportation or handling.

  • Page 5: Adjustment Instructions

    Alignment instruction 1 Alignment equipment PM5518 (video signal generator) K-7253 (VGA signal generator) CA210 (white balancer) 2 Alignment flow-chart The alignment flow-chart is shown as fig-1 Check DDC, HDCP KEY and CPU Factory initialization setup IF channel voltage of TV and AGC voltage adjustment Support format of VGA pre-set Adjustment for sub-brightness and white balance of VGA/HDMI (color temperature 6500k, 9300k and 12000k)
  • Page 6 Table1 sub-menu adjustment Items Range Introduce PW on LOGO ON/OFF Display 5s LOGO of turn on the TV NO Sig LOGO ON/OFF If display LOGO in no signal Black Screen BLUE/BLACK If display blue screen and white noise wave in no signal, setting “BLUE”...
  • Page 7 f. Input PROG852(640*480/75Hz) and the eighth level gray-scale of PATTERN signal of VG-849 to HDMI, repeatedly the b-e course. In the HDMI channel, preset value of offset_R, offset_G and offset_B to 15, preset value of gain_R, gain_G and gain_B to 25. 3.4 Adjustment for sub-brightness and white balance of YPbPr channel a.

  • Page 8: Trouble Shooting

    Item Setting Item Setting Item Setting Picture mode NATURE OSD language English Sound mode NORMAL HALFTONE STEREO WEAK DURATION VGA/HDMI NORMAL SCREEN FULL MAG.C ANTENNA CATV Trouble shooting Before servicing please check to find the possible causes of the troubles according to the table below.
  • Page 9 Deterioration of color phase or color Check if all the picture setups have been corrected. tone Screen position or size is not proper Check is the screen position and size is correctly set Picture is twisted and deformed Check to see if the picture-frame ratio is properly set Picture color changed or colorless Check the “Component”...

  • Page 10: Working Principle Analysis

    control so as to enable the liquid crystal TV set to recheck the signal and then to display correct picture signal Working principle analysis RF signal from the antenna to tuner, via high frequency amplifier and mix frequency to obtain IF signal, and then via pre-IF amplifier in V104, then it send to processed IF filter of SAW (Z103), obtain more idea IF speciality, it processed to IF amplifier, phase locked logic VCO and sync detection of N101 (M52760E) in the TV board to obtain VIDEO;...

  • Page 11: Block Diagram

    BLOCK DIAGRAM AV1-A AV2/S-A YPbPr-A AUDIO VGA/DVI-A HDMI-A NA02 AUDIO SIF DEC AUDIO AMP HEF4052 PROCESSOR N201 N401 N301 LA72700 TPA3008D2 R2S15900SP AV OUT Z102 IF AMP TUNER SPEAKER N101(TV) M52760E Z103 HEADPHONE VIDEO VIDEO1 SCALER DECORDER Y/VIDEO2 CCIR656 A/D D/A N601 8bit DEINTERLACER...

  • Page 12: Ic Block Diagram

    IC block diagram TVP5147 Copy CVBS/Y Data Protection Detector Processor Analog Front End VI_1_A Composite and S-Video Processor CVBS/ VI_1_B C/Pb VI_1_C Luma Y[9:0] CVBS/Y Separation Processing Output YCbCr 5-line Formatter VI_2_A Chroma C/CbCr Clamping Adaptive CVBS/ Processing C[9:0] VI_2_B Comb VI_2_C 11-Bit...
  • Page 13 M52760 2: AFT 3: AGC 4, 5: picture If input 7: sound IF input 13: SIF output 10: mono sound output 18: TV- VIDEO output 14, 17: +5V-1 power supply...
  • Page 14 LA72700 5: SIF input 25: TV sound -R output 26: TV sound- L output 11: SDA 12: SCL 31: +9Vpower supply...
  • Page 15 MST6151 207, 208: HDMI-R input 2, 3: HDMI-G input 5, 6: HDMI-B input 8, 9: HDMI-CLK input 14: HDMI-SDA 15: HDMI-SCL 20, 21: VGA-B input 22: VGA-G input 23, 24: VGA-G input 25, 26: VGA-R input 18: VGA H-sync input 19: VGA V-sync input 27, 28: PB input 29, 30: Y input...
  • Page 16 PIN DIAGRAM (MST5151A) VDDC DVI_G+ DVI_G- VDDM Pin 1 AVDD_DVI DQS[0] DVI_B+ MDATA[0] DVI_B- MDATA[1] MDATA[2] DVI_CK+ MDATA[3] DVI_CK- MDATA[4] AVDD_DVI MDATA[5] REXT MDATA[6] MDATA[7] AVDD_PLL MDATA[8] DDCD_DA MDATA[9] DDCD_CK MDATA[10] MDATA[11] AVDD_ADC HSYNC1 VDDM MDATA[12] VYSNC1 BIN1P MDATA[13] BIN1M MDATA[14] MDATA[15] SOGIN1...
  • Page 17 PIN DESCRIPTION MCU Interface Pin Name Pin Type Function HWRESET Schmitt Trigger Input Hardware Reset, active high w/ 5V-tolerant DBUS[3:0] I/O w/ 5V-tolerant MCU 4-bit DDR Direct bus; 4mA driving strength 75-72 I w/ 5V-tolerant MCU Bus ALE, active high I w/ 5V-tolerant MCU Bus RDZ, active high I w/ 5V-tolerant...
  • Page 18 DVI Interface Pin Name Pin Type Function DVI_R+ Input DVI Input Channel Red + DVI_R- Input DVI Input Channel Red - DVI_G+ Input DVI Input Channel Green + DVI_G- Input DVI Input Channel Green - DVI_B+ Input DVI Input Channel Blue + DVI_B- Input DVI Input Channel Blue -...
  • Page 19 Pin Name Pin Type Function LVA2M Output A-Link Negative LVDS Differential Data Output LVA2P Output A-Link Positive LVDS Differential Data Output LVA3M Output A-Link Negative LVDS Differential Data Output LVA3P Output A-Link Positive LVDS Differential Data Output LVACKM Output A-Link Negative LVDS Differential Data Output LVACKP Output A-Link Positive LVDS Differential Data Output...
  • Page 20 Pin Name Pin Type Function (for differential clocks) MCLK Output DRAM Memory Clock RASZ Output Row Address Strobe, active low CASZ Output Column Address Strobe, active low Output Write Enable, active low DQM[1:0] Output Data Mask Byte Enable 101, 133 DQS[3:0] Output Data Strobe...
  • Page 21 Pin Name Pin Type Function Ground Ground 1, 7, 13, 16, 35, 50, 64, 65, 80, 87, 103, 108, 114, 126, 132, 140, 155, 157, 159, 163, 172, 183, 184, 194, 205, 206...
  • Page 22 R2S15900 2: input L of AV1 27: input R of AV1 3: input L of AV2/S 26: input R of AV2/S 4: input L of YPBPR/VGA/HDMI 25: input R of YPBPR/VGA/HDMI...
  • Page 23 5: input L of TV 24: input R of TV 6: output L of AVOUT 23: output R of AVOUT 11: L output 19: R output 18: SCL 17: SDA 28: +9Vpower supply TPA3008 1: MUTE 3: R input 5: L input 20, 17: L input 41, 44: R input 15, 23, 33, 39, and 47: +18V power supply...

  • Page 24: Main Assembly

    Main assembly NAME MAIN COMPONENT AND it’S NO. TV board 667-L27U6-40 N101 M52760 (352-52760-10) N201 LA72700 (353-72700-10) N301 R2S15900 (353-15900-10) N401 TPA3008D2 (353-30080-10) CPU board 667-L27U6-56 N101 MST6151DA (353-61510-10) N601 TVP5147 (353-51470-10) NA01 CS4340 (353-43400-30) N801 MTV412 (353-04120-10) Keypad board 667-L27U6-05 Remote control 301-RL27U6-27M (RC-R27M)

  • Page 25: Identification Criteria For The Bright Spot And Dark Spot Of The Lcd Screen

    Identification criteria for the bright spot and dark spot of the LCD screen Q’ty allowed Distance between two spots Category criteria 15" 20" 22" 30" 40" 15" 20" 22" 30" 40" One single ≤5 ≤2 ≤5 ≤2 ≤3 spot Bright 2 neighboring ≥15mm ≤2...

  • Page 26: Wiring Diagram

    Wiring diagram...

  • Page 27: Troubleshooting Charts

    Troubleshooting guide 1. No raster Turn-on power supply, check if the red indicator is light in the STANDBY? blue Check if PIN8(5V) of CPU Press POWER button in the board is normal? unit button and sensor control, check the indicator. Check if the PIN12 of X503 in Check STANDBY circuit of CPU board is high-level?
  • Page 28 2. Raster, but no picture Check if the unit button Does display sensor control menu in screen when operation? press submenu? Check channels have signal? HDMI/VGA/YPRP Enter factory-menu, Which is no initialization EEPROM, signal Replacing then turn off the TV, channels CPU board turn on again, display...
  • Page 29 3.no sound Check if PIN15, PIN30 Check PIN11 and PIN38 voltage of PIN19 output wave of Replacing N401 N401 is normal? N301 Check power supply Check PIN25 PIN26 output wave of Replacing N301 N201 Check PIN5 wave of Replacing N201 N201 Check PIN11 wave of TUNER1...

  • Page 41: Schematic Diagram ( Power Supply Board)

    LC-23U7 AND LC-27U7 POWER SUPPLY BOARD...
  • Page 42 Exploded views...
  • Page 43 PART LIST OF EXPLODED VIEW DESCRIPTION PART No. REAR CABINET COVER(LEFT) 808-10694-AF0 REAR CABINET COVER(RIGHT) 808-10695-AF0 BUTTON BOARD ASSY 667-L27U6-05 REAR CABINET 780-U06LHJAF4 LED COLUMN 700-60215-100 BAFFLE 804-2H367-00B FRONT CABINET 780-U07W0JAR0 SPEAKER 384-41916-Q0 SPEAKER BRACKET 870-30085-00 RUBBER WASHER 868-20453-00 LCD PANEL 335-23003-00 VIDEO PROCESSING BOARD 667-L27U6-40...

  • Page 44: Part List

    PART LIST PART# DESCRIPTION LOCA.NO. SOFTWARE PANEL 　 CANADA SL23U70-10A10 N801 100-L23U70-10 LC-23U7D 100-L23U70-02 LC-23U7 N15 335-23003-00 DISPLAY SCREEN V230W1-L02 364-41207-00 ANTENNA SOCKET HR-F 485-10157-00 POWER CORD LAP-31+730 BLACK 2m ! 488-10012-00 BATTERY 7# ENGLISH 604-L23U77-00 OWNER'S MANUAL(DIGISTAR,DZ-1523) 605-L23U77-00 WALL MOUNT GUIDE (1523) 655-41201-307 ( 4-PINS ) LEAD WITH HOUSING 655-41201-97...
  • Page 45 852-13014-81 SCREW P(+) M3X14-D.Zn 852-23006-81 SCREW SJ2829 M3X6-D.Zn 852-23006-81 SCREW SJ2829 M3X6-D.Zn 852-24010-87 SCREW SJ2829 M4X10-D.Zn ( BLACK 852-24010-87 SCREW SJ2829 M4X10-D.Zn ( BLACK 852-34010-81 SCREW B(+) M4X10-D.Zn 852-43006-81 SCREW F(+) M3*6-DZn 852-43006-81 SCREW F(+) M3*6-DZn 852-44008-82 SCREW F(+)M4X8-D.Ni 852-44008-82 SCREW F(+)M4X8-D.Ni 852-45008-82 SCREW F(+)M5X8-D.Ni...
  • Page 46 881-61884-00 CSA WARNING LABEL 881-62875-92 BACK PLATE LABEL (LC-23U7D,DIGSTAR) 881-63329-00 LABEL (FPE2000,AUDIOVOX) 881-63840-00 POWER SYMBOL LABEL 881-63853-00 MylarLabel LABEL LC-23U7D 881-64042-00 TRANSPORTATION LABEL (LC-23U7D,DIGISTAR) 881-80775-00 OPERATION CARD (Digistar, L23U7) 881-80788-00 REGISTER CARD (DIGISTAR) 881-80791-00 EXTENDED CARD (DIGISTAR,21-26LCD) 881-80811-00 ACKNOWLEDGEMENT CARD ((DIGISTAR) 886-31021-00 ACCESSORY BOX (15L) 886-31499-090W...
  • Page 47 615-20455-00 SPEAKER ASS'Y 384-41916-Q0 SPEAKER ST511-07 655-4E301-37 (4-PINS) LEAD WITH HOUSING 851-53012-11 SCREW SJ2825 ST3X12C-D.Zn 868-20453-00 RUBBER WASHER 870-30085-00 SPEAKER BRACKET 667-L27U6-20A POWER PCB ASS'Y 667-L27U6-20A\ POWER PCB ASS'Y (MANUAL INSERTION ) 667-L27U6-20\ POWER PCB ASS'Y (MANUAL INSERTION ) 340-00168-00 DIODE UF4007 D907 340-00168-00...
  • Page 48 464-DF810-M1 ELECTROLYTIC CAPACITOR CD110H-35V-1000uF-M C939 464-DF810-M1 ELECTROLYTIC CAPACITOR CD110H-35V-1000uF-M C940 467-2F210-H0C METAL RESISTOR 1W-1K-JL R960 467-2G310-H0 METAL RESISTOR 2W-10kΩ-JL 467-2G310-H0 METAL RESISTOR 2W-10kΩ-JL 467-2GA47-H0 METAL RESISTOR 2W-4.7Ω-JL R955 467-5HB22-HA CEMENT RESISTOR RX27-6-3W-0.22Ω-J R911 467-5HB22-HA CEMENT RESISTOR RX27-6-3W-0.22Ω-J R942 467-7E491-H0A VITREOUS-ENAMEL RESISTOR RI40-1/2W-910K-J R920 469-40004-00 THERMISTOR 5D2-14LC...
  • Page 49 667-L27U6-20* POWER PCB ASS'Y (SMD AUTOMATIC INSERTION ) JUMPER WIRE C947 JUMPER WIRE J901 JUMPER WIRE J902 JUMPER WIRE J903 JUMPER WIRE J904 JUMPER WIRE J905 JUMPER WIRE J906 JUMPER WIRE J907 JUMPER WIRE J908 JUMPER WIRE J909 JUMPER WIRE J910 JUMPER WIRE J911...
  • Page 50 455-22247-H0 SMD RESISTOR RC11-1/8W-4.7K-J R917 455-22247-H0 SMD RESISTOR RC11-1/8W-4.7K-J R939 455-22291-H0 SMD RESISTOR RC11-1/8W-9.1K-J R903 455-22310-H0 SMD RESISTOR RC11-1/8W-10K-J R936 455-22310-H0 SMD RESISTOR RC11-1/8W-10K-J R937 455-22310-H0 SMD RESISTOR RC11-1/8W-10K-J R952 455-22315-H0 SMD RESISTOR RC11-1/8W-15K-J R906 455-22315-H0 SMD RESISTOR RC11-1/8W-15K-J R910 455-22322-H0 SMD RESISTOR RC11-1/8W-22K-J R904...
  • Page 51 364-34186-00 4-PINS CONNECTORS TJC10-4AWT 467-1C210-H03 CARBON RESISTOR 1/6W-1K-J 467-1C210-H03 CARBON RESISTOR 1/6W-1K-J 467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J 467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J 467-1C315-H03 CARBON RESISTOR 1/6W-15K-J 782-L27U6-0500 BUTTON PCB 877-60621-00B BUTTON 877-60624-0T0 BUTTON COVER (PLATE SILVERY WHITE ) 667-L27U6-09 IR RECEIVE ASS'Y 667-L27U6-09\ IR RECEIVE ASS'Y (MANUAL INSERTION ) 340-10113-20...
  • Page 52 462-00368-K0 POLYESTER CAPACITOR CL11-100V-0.068uF-K C309 462-00368-K0 POLYESTER CAPACITOR CL11-100V-0.068uF-K C318 462-00368-K0 POLYESTER CAPACITOR CL11-100V-0.068uF-K C319 462-B0468-H0 POLYESTER CAPACITOR CL21X-50V-0.68uF-J C425 462-B0468-H0 POLYESTER CAPACITOR CL21X-50V-0.68uF-J C432 464-6B747-M0 ELECTROLYTIC CAPACITOR CD110-6.3V-470uF-M C605 464-6C733-M0 ELECTROLYTIC CAPACITOR CD110-10V-330uF-M C134 464-6C810-M0 ELECTROLYTIC CAPACITOR CD110-10V-1000uF-M C111 464-6C810-M0 ELECTROLYTIC CAPACITOR CD110-10V-1000uF-M C113...
  • Page 53 340-00001-0S SMD DIODE LL4148 D406 340-00001-0S SMD DIODE LL4148 D412 340-00001-0S SMD DIODE LL4148 D503 340-00289-00 SMD DIODE BAV99LT1 D601 340-00289-00 SMD DIODE BAV99LT1 D602 340-00289-00 SMD DIODE BAV99LT1 D603 342-08470-90 SMD TRANSISTOR BC847AW V106 342-08470-90 SMD TRANSISTOR BC847AW V108 342-08470-90 SMD TRANSISTOR BC847AW V201...
  • Page 54 455-12210-H0 SMD RESISTOR FTR0603102JR R103 455-12210-H0 SMD RESISTOR FTR0603102JR R108 455-12210-H0 SMD RESISTOR FTR0603102JR R138 455-12210-H0 SMD RESISTOR FTR0603102JR R214 455-12210-H0 SMD RESISTOR FTR0603102JR R216 455-12210-H0 SMD RESISTOR FTR0603102JR R414 455-12210-H0 SMD RESISTOR FTR0603102JR R415 455-12210-H0 SMD RESISTOR FTR0603102JR R502 455-12210-H0 SMD RESISTOR FTR0603102JR R611...
  • Page 55 455-12347-H0 SMD RESISTOR FTR0603473JR R302 455-12347-H0 SMD RESISTOR FTR0603473JR R307 455-12347-H0 SMD RESISTOR FTR0603473JR R312 455-12347-H0 SMD RESISTOR FTR0603473JR R317 455-12368-H0 SMD RESISTOR FTR0603683JR R142 455-12368-H0 SMD RESISTOR FTR0603683JR R410 455-12410-H0 SMD RESISTOR FTR0603104JR R208 455-12410-H0 SMD RESISTOR FTR0603104JR R209 455-12410-H0 SMD RESISTOR FTR0603104JR R505...
  • Page 56 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C222 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C225 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C407 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C408 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C411 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C421 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C423 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C436 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C437...
  • Page 57 456-3210H-11 SMD CAPACITOR 0603CG102J500BA C610 456-3227H-11 SMD CAPACITOR 0603CG272J500BA C132 462-00215-K02 POLYESTER CAPACITOR CL11-100V-1500PF-K C128 462-00282-K02 POLYESTER CAPACITOR CL11-100V-8200PF-K C307 462-00282-K02 POLYESTER CAPACITOR CL11-100V-8200PF-K C317 462-00315-K02 POLYESTER CAPACITOR CL11-100V-0.015uF-K C310 462-B0468-H02 POLYESTER CAPACITOR CL21X-50V-0.68uF-J C424 462-B0468-H02 POLYESTER CAPACITOR CL21X-50V-0.68uF-J C433 464-60447-M02 ELECTROLYTIC CAPACITOR CD110-50V-0.47uF-M C105...
  • Page 58 464-6D622-M02 ELECTROLYTIC CAPACITOR CD110-16V-22uF-M C206 464-6D710-M02 ELECTROLYTIC CAPACITOR CD110-16V-100uF-M C121 464-6D710-M02 ELECTROLYTIC CAPACITOR CD110-16V-100uF-M C204 464-6D722-M02 ELECTROLYTIC CAPACITOR CD110-16V-220uF-M C323 464-6D747-M02 ELECTROLYTIC CAPACITOR CD110-16V-470uF-M C403 464-6D747-M02 ELECTROLYTIC CAPACITOR CD110-16V-470uF-M C512 464-6D747-M02 ELECTROLYTIC CAPACITOR CD110-16V-470uF-M C514 464-6D747-M02 ELECTROLYTIC CAPACITOR CD110-16V-470uF-M C515 464-6E610-M02 *ELECTROLYTIC CAPACITOR CD110-25V-10uF-M C443...
  • Page 59 364-34186-00 4-PINS CONNECTORS TJC10-4AWT X801 364-34186-00 4-PINS CONNECTORS TJC10-4AWT X802 364-34186-00 4-PINS CONNECTORS TJC10-4AWT XA02 364-38104-00 8-PINS CONNECTORS TJC3-08AWT X501 364-3B104-00 102-PINS CONNECTORS TJC3-12AWT X503 364-3B186-00 12-PINS CONNECTORS TJC10-12AW X803 364-3D186-00 10-PINS CONNECTORS TJC10-10AW X601 364-91227-00 VGA SOCKET SCREW XD01 364-95209-00 AV JACK AV13-05-501 XV01...
  • Page 60 340-00289-00 SMD DIODE BAV99LT1 DV03 340-00372-00 SMD DIODE MMBD1204 DD08 340-00372-00 SMD DIODE MMBD1204 DH12 342-01440-10 SMD TRANSISTOR DTC144EKA V501 342-01440-10 SMD TRANSISTOR DTC144EKA V502 342-01440-10 SMD TRANSISTOR DTC144EKA VB01 342-01440-10 SMD TRANSISTOR DTC144EKA VB02 342-08470-90 SMD TRANSISTOR BC847AW V801 342-08470-90 SMD TRANSISTOR BC847AW V802...
  • Page 61 455-12022-H0 SMD RESISTOR FTR0603220JR R202 455-12022-H0 SMD RESISTOR FTR0603220JR R203 455-12022-H0 SMD RESISTOR FTR0603220JR R204 455-12022-H0 SMD RESISTOR FTR0603220JR R802 455-12022-H0 SMD RESISTOR FTR0603220JR R803 455-12033-H0 SMD RESISTOR FTR0603330JR R205 455-12033-H0 SMD RESISTOR FTR0603330JR R615 455-12033-H0 SMD RESISTOR FTR0603330JR R804 455-12033-H0 SMD RESISTOR FTR0603330JR R805...
  • Page 62 455-12139-H0 SMD RESISTOR FTR0603391JR RH09 455-12147-H0 SMD RESISTOR FTR0603471JR R101 455-12147-H0 SMD RESISTOR FTR0603471JR R811 455-12147-H0 SMD RESISTOR FTR0603471JR RD12 455-12147-H0 SMD RESISTOR FTR0603471JR RV11 455-12210-H0 SMD RESISTOR FTR0603102JR R504 455-12210-H0 SMD RESISTOR FTR0603102JR R810 455-12210-H0 SMD RESISTOR FTR0603102JR RH01 455-12215-H0 SMD RESISTOR FTR0603152JR R806...
  • Page 63 455-12310-H0 SMD RESISTOR FTR0603103JR RA20 455-12310-H0 SMD RESISTOR FTR0603103JR RA21 455-12310-H0 SMD RESISTOR FTR0603103JR RA22 455-12310-H0 SMD RESISTOR FTR0603103JR RA23 455-12310-H0 SMD RESISTOR FTR0603103JR RA24 455-12310-H0 SMD RESISTOR FTR0603103JR RA25 455-12310-H0 SMD RESISTOR FTR0603103JR RA26 455-12310-H0 SMD RESISTOR FTR0603103JR RA27 455-12310-H0 SMD RESISTOR FTR0603103JR RA29...
  • Page 64 456-2310R-C1 SMD CAPACITOR 06032E103Z250BA C812 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C104 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C105 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C106 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C111 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C113 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C114 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C116 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C117...
  • Page 65 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C516 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C517 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C518 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C520 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C522 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C524 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C526 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C527 456-2410M-C1 SMD CAPACITOR 06032E104M250BA C529...
  • Page 66 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CB01 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CB02 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CD09 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CH02 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CV08 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CV09 456-2410M-C1 SMD CAPACITOR 06032E104M250BA CV10 456-2447R-C1 SMD CAPACITOR 06032E474Z250BA CB04 456-2447R-C2 SMD CAPACITOR C2012Y5V1E474ZT C126...
  • Page 67 464-6D622-M02 ELECTROLYTIC CAPACITOR CD110-16V-22uF-M C611 464-6D622-M02 ELECTROLYTIC CAPACITOR CD110-16V-22uF-M C621 464-6D622-M02 ELECTROLYTIC CAPACITOR CD110-16V-22uF-M C626 464-6D622-M02 ELECTROLYTIC CAPACITOR CD110-16V-22uF-M C630 464-6D622-M02 ELECTROLYTIC CAPACITOR CD110-16V-22uF-M C637 464-6D622-M02 ELECTROLYTIC CAPACITOR CD110-16V-22uF-M C803 464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C201 464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C202 464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C500...
  • Page 68 666-13207-00 SMD FERRITE BEAD STPB3216-380PT L506 666-13207-00 SMD FERRITE BEAD STPB3216-380PT L507 666-13207-00 SMD FERRITE BEAD STPB3216-380PT L508 666-13207-00 SMD FERRITE BEAD STPB3216-380PT L509 666-13207-00 SMD FERRITE BEAD STPB3216-380PT L510 666-13207-00 SMD FERRITE BEAD STPB3216-380PT L511 666-13207-00 SMD FERRITE BEAD STPB3216-380PT L512 666-13207-00 SMD FERRITE BEAD STPB3216-380PT...
