Video Pipe Inspection System
Your Gen-Eye Micro-Scope3 Video
Pipe Inspection System is designed to
give you years of trouble-free, profitable
service. However, no machine is better
than its operator.
Read, understand and follow all safety
warnings and instructions provided with
the product. Failure to follow the warnings
and instructions may result in electric
shock and/or serious injury. Save all warn-
ings and instructions for future reference.
SAVE THESE INSTRUCTIONS!
Gen-Eye Micro-Scope3
Operating Instructions
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gen-Eye Micro-Scope3 and is the answer not in the manual?

Questions and answers

Related Manuals for General Pipe Cleaners Gen-Eye Micro-Scope3

Summary of Contents for General Pipe Cleaners Gen-Eye Micro-Scope3

  • Page 1 ® Gen-Eye Micro-Scope3 Video Pipe Inspection System Operating Instructions Your Gen-Eye Micro-Scope3 Video Pipe Inspection System is designed to give you years of trouble-free, profitable service. However, no machine is better than its operator. Read, understand and follow all safety warnings and instructions provided with the product.

  • Page 2: Safety Symbols

    Power tools create sparks which may ignite the dust or fumes. These instructions are intended to familiarize all personnel with the safe operation and maintenance proce- Always wear safety glasses dures for the Gen-Eye Micro-Scope3 rubber soled, non-slip shoes. Use of this safety equip- Video Pipe Inspection System.

  • Page 3: General Safety Rules

    ® Gen-Eye Micro-Scope3 Video Pipe Inspection/Location System GENERAL SAFETY RULES Do not overreach. Keep proper footing and balance at all times. Proper footing and balance enables better control of the tool in unexpected situations. WARNING Always wear safety glasses and rubber soled, non-slip Read and understand all instructions.

  • Page 4: Specific Safety Rules

    ® Gen-Eye Micro-Scope3 Video Pipe Inspection/Location System SPECIFIC SAFETY RULES FEATURES Keep the device out of the reach of children. Top View: Do not look directly into the camera lens at the end of the Probe Rod Connector probe rod. Your eyesight may be seriously damaged.
  • Page 5 Video Play and Pause icons Brightness, Contrast, and Grey scale Video fast-forward and fast-rewind GEN-EYE MICRO-SCOPE3 COMMAND MODULE The Command Module should not be used in wet locations or in the rain, as moisture may cause damage to the unit.

  • Page 6: Main Display

    ® Gen-Eye Micro-Scope3 Video Pipe Inspection/Location System Main Display (Row 2) Set the clock (hours, minutes, seconds). Use the UP and DOWN arrow buttons to select the hours, minutes, and seconds The main display appears as shown. field and use the VIDEO (increase) and PHOTO (decrease) but- Camera image area tons to set the time.

  • Page 7: Power Input

    ® Gen-Eye Micro-Scope3 Video Pipe Inspection/Location System Video Recording & Viewing Setting up Wi-Fi See pages 8 and 9 for instructions for Apple and Android devices. NOTE: The Gen-Eye Micro-Scope is equipped with an integral micro- phone. The microphone is always on. Therefore, if you are recording video, please be aware that you are also recording audio.
  • Page 8 ® Gen-Eye Micro-Scope3 Video Pipe Inspection/Location System How to Set-Up the Wi-Fi Feature for Gen-Eye Camera Systems On an Apple device Make sure the Command Module is turned ON and you are next Icon Key: to the unit. Home—takes you back to the main screen (devices list) On your cell phone, tablet, or other Wi-Fi Tools—opens the settings menu for video, camera and audio.
  • Page 9 ® Gen-Eye Micro-Scope3 Video Pipe Inspection/Location System How to Set-Up the Wi-Fi Feature on Gen-Eye Camera Systems On an Android device Make sure the Command Module is You should see the image transmitted by the camera on your turned ON and you are next to the unit.
  • Page 10 ® Gen-Eye Micro-Scope3 Video Pipe Inspection/Location System SET UP - COMMAND MODULE Press and hold POWER button. Start up screen will appear in a few seconds. 1. To set up for the Probe rod, connect the Probe Rod to the con- When the image from the camera appears on the screen, begin nector at the top of the Command Module.
  • Page 11 ® Gen-Eye Micro-Scope3 Video Pipe Inspection/Location System CAMERA LOCATION Watch the Gen-Eye Hot Spot monitor display as you approach the transmitter’s location. Turn on Gen-Eye Camera system. When you reach the vicinity of a NULL point the screen will Press and hold the Hot Spot Locator produce this display: On/Off button.

  • Page 12: Maintenance

    ® Gen-Eye Micro-Scope3 Video Pipe Inspection/Location System Picture BUT No Lights: MAINTENANCE • Check if Power switch is ON. DISCONNECT MACHINE FROM POWER SOURCE • BEFORE PERFORMING MAINTENANCE ON MACHINE! Check to see if LED Dimmer control (located on the panel of the Command Module) is turned up.
