4. VIDEO PCB
Proceeding : TOP COVER
(1) Cut the wire clamp, then remove the connector.
5. INPUT PCB
Proceeding : TOP COVER
(1) Remove the connector.
BACK CHASSIS
DIGITAL PCB
→
→
BN28B
BN27B
→
BACK CHASSIS
→
DIGITAL PCB
BN24C
BN26C
BN64C
BN23C
VIDEO PCB
→
BN21B
CUT x4
→
VIDEO PCB
From AMP PCB
CN706
16
→
INPUT PCB
