Hawking HAR11A Specifications

C A R E F R E E N E T W O R K I N G
Get Connected with Hawking
The HAR11 Hawking DSL Modem with Router functionality is the perfect solution for sharing your
DSL Internet connection with others across your network. With advanced routing capabilities, the
HAR11 can be configured as a secure gateway between your computers and the Internet.
routing, DHCP configuration, static routing, NAT, and simultaneous USB and Ethernet operation
are just some of the HAR11's enhanced capabilities.
the HAR11 is easy to configure and easy to use.
Features
. IEEE 802.3 and 802.3u over UTP (10/100Base-T) compliant for easy installation and configuration
. Full rate operation with up to 8 Mbps downstream data rate and up to 1 Mbps upstream data rate
. Built-in DHCP server automatically assigns IP addresses to all workstations on your LAN
. Ethernet to ADSL self-learning Transparent Bridging (IEEE 802.1D)
. Supports full VPI range (8 bits, 0-255) and VCI range (16 bits, 0-65535) over PVC. VPI is limited to VPI 0
only over SVC
. Supports up to 8 PVCs for RFC 1483 and ATM Forum UNI 3.0, 3.1 and 4.0 signaling for SVC
. Supports ADSL always-on
. Connect distance: Up to 18,000 feet on 26 AWG wire
. Easy USB Configuration
System Requirements:
USB Operating System Requirements:
Windows 98 / ME / 2000 / XP
Ethernet:
All Operating Systems
1-Port ADSL Modem Router
With Additional
C O N N E C T W H E R E V E R Y O U W A N T
H A R 11 A
ADSL Modem and 1-Port Router with an
Additional USB Network Port
Plug and Play USB Configuration
Two Year Warranty
PACKAGE CONTENTS:
With web and USB configuration flexibility,
USB
• W H E N E V E R Y O U W A N T
One ADSL Modem Router
One Power Adapter
One Setup CD
Easy-to-follow Quick Installation Guide
Port
IP
