Page 2: Limited Warranty
(2) years from the date of purchase. If the product proves defective during this two-year warranty period, call Hawking Customer Service in order to obtain a Return Authorization number. The warranty is for repair or replacement only. Hawking Technology does not issue any refunds. BE SURE TO... - Page 3 Hawking Technology reserves the right to revise or update its products, software, or documentation without obligation to notify any individual or entity. Please direct all inquiries to:...
- Page 4 Introduction Features Package Contents Hardware Description Hardware Installation N-way Process Specifications...
- Page 5 100-Mbps Fast Ethernet and up to a hundredfold increase over 10-Mbps Ethernet. It utilizes the same packet structure and format, as well as support for CSMA/CD protocol, full duplex, flow control, and management objects. Because...
- Page 6 Gigabit Ethernet supports video conferencing, complex imaging, and similar data-intensive applications. Likewise, since data transfers occur at speeds up to 10 times greater than Fast Ethernet, servers outfitted with Gigabit Ethernet NIC’s (Network Interface Cards) are able to perform 10...
- Page 7 • Supports Auto-Negotiation for 10/100/1000Mbps and duplex mode • Supports Auto-MDIX for each port • Supports Full/Half duplex transfer mode for 10 and 100Mbps • Supports Full duplex transfer mode for 1000Mbps • Full wire speed reception and transmission •...
- Page 8 The complete H-GS5T package consists of: • One H-GS5T 5-Port 10/100/1000M Auto-sensing Gigabit Ethernet Switch • Four Rubber Feet with Adhesive Backing • One External Power Adapter • One User’s Manual Check to make sure that the unit was not damaged during shipping and that no items are missing.
- Page 9 Rear Panel The rear panel of the switch consists of a DC power connector and five 10/100/1000M auto-negotiation RJ-45 ports. The figure on the previous page shows the rear panel of the switch.
- Page 10 The LEDs blink whenever reception or transmission (i.e., Activity) o Speed These LEDs are Off when there is (10/100/1000M) a 10Mbps connection (or link) to a 10Mbps Ethernet device at the associated port; they are lit Green when connection (or link) to a 100Mbps...
- Page 11 (For best results, use a CAT 5E cable.) Step 4. Repeat Step 3 as necessary for the remaining ports. Also, if needed, another hub/switch can be connected to any port on the unit. Step 5. Ensure that each device is connected properly.
- Page 12 “Auto-negotiation” (N-way) mode automatically sets the best possible bandwidth (10Mbps, 100Mbps, or 1000Mbps) when a connection is established with another network device. Auto-negotiation functions are determined by these set data- transfer rate priorities: a. 1000Base-T Full Duplex (2000Mbps) b. 1000Base-T Half Duplex (1000Mbps) c.
- Page 13 IEEE 802.3ab 1000BASE-T IEEE 802.3u 100BASE-TX Standards IEEE 802.3 10BASE-T IEEE 802.3x Flow Control Protocol CSMA/CD Ethernet 10Mbps 20Mbps Data Fast Ethernet 100Mbps Transfer 200Mbps Rate Gigabit 1000Mbps Ethernet 2000Mbps Ethernet 2-Pair UTP CAT 3, 4, 5, 5E Unshielded (UTP) Cable Fast Ethernet 2-Pair UTP CAT 5, 5E Network...
- Page 14 Full duplex: IEEE 802.3x 802.3x) Auto Auto-crossover on each port Crossover Packet Filtering/ Full wire speed Forwarding Rate 437.5K Bytes per device Buffer Address Self-learning, auto aging Learning DC Inputs 12V DC 1A Power 7.5 Watts Consumption Operating 10ºC - 55ºC Temp.
- Page 15 Humidity 0% - 90% RH, non-condensing 187 x 30 x 100mm (W x H x D) Dimensions 7.36” x 1.18” x 3.94” (W x H x D) Certifications FCC Class A, CE Marking Class A, VCCI Class A...
