Summary of Contents for Condux CableGlider LW

  • Page 1 USER’S GUIDE & SAFETY MANUAL CableGlider® LW Cable Puller...
  • Page 3 WARNING: When using electric tools, basic safety precautions should always be followed to reduce the risk of fire, and personal injury, including the following: Read and understand all procedure and safety instructions before using the Condux CableGlider Cable Puller. Observe all safety information on this page and note specific safety requirements as explained by procedures called out in this manual.
  • Page 4: Table Of Contents

    Table of Contents General Information………………………………………. 5 Safe Operating Practices………………………………..6 Puller Assembly Instructions………………………….. 10 Operating Instructions………………………………….. 12 Appendices………………………………………………….. 14 LW Cableglider Assembly………………………………. 14 LW Cableglider Wiring Diagram……………………… 16 LW Cableglider Accessories…………………………….17 LW Cableglider Accessories…………………………….18 Warranty Information…………………………………….22...
  • Page 5: General Information

    B. Each model includes a wheeled canvas-carrying bag and includes the following: fork and drill motor. C. The Condux LW Cable Puller provides up to 3,000 pounds of pulling force. It operates on 115V at 30 feet per minute. The frame is made of high quality tubular steel.
  • Page 6: Safe Operating Practices

    Safe Operating Practices Important Safety Instructions Electrical Requirement 1. This puller should be grounded while in use to protect the operator from electric shock The power pack is equipped with a 3-conductor cord and 3-prong grounding type plug to fit the proper grounding type receptacle. The green conductor in the cord is the grounding wire.
  • Page 7 7. Do not use the puller if the switch is malfunctioning. Have it replaced by an authorized service center. Disconnect Tools 8. Always disconnect the power when not in use and before installing, removing, or servicing the puller. Keep Work Area Clean 9.
  • Page 8 SAVE THESE INSTRUCTIONS Table of Contents Puller Operation: Condux Cable Pullers are designed for safe operation, but these safety precautions should be practiced: 1. Stay clear of the area directly behind the puller while in operation 2. Use only 10 gauge 3 wire extension cords.
  • Page 9 Four Safety Rules When Working With Rope RIGHT ROPE FOR THE JOB: Use adequate size rope recommended to accommodate your pulling load. CORRECT HANDLING AND USAGE: Observe the recommended working load. Make sure all pulleys, fairleads, etc. are proper size and free of grit and rust. Avoid knots or severe bending that will reduce rope strength.
  • Page 10: Puller Assembly Instructions

    Puller Assembly Instructions Sheave Extension Power Unit Square Extension Fork Base 1. Remove puller components from the carrying case. 2. Place Power Unit into the Base Plate and secure with Clevis Pin (See Figure 1) Figure 1...
  • Page 11 3. Remove Lock Pins from square adapter and slide over Mounting Tube on Power Unit. Reinstall Lock Pins. (See Figure 2) Figure 2 4. Slide Sheave Extension into Square Adapter. Reinstall Lock Pin. (See Figure 3). Sheave Extension can be adjusted to desired height during puller set-up.
  • Page 12: Operating Instructions

    Operating Instructions 1. Select an adapter that corresponds to conduit size and fit it into the retaining fork. 2. Screw thumbscrew on retaining fork into adapter. (See Figures 5 & 6) Figure 5 Figure 6 3. Position and adjust cable puller for desired application. 4.
  • Page 13 7. Plug cable puller into 110-120V 15 amp standard outlet. WARNING: Electrical equipment is very hazardous in wet areas. Properly ground puller, wear insulated footwear and gloves, keep the operator zone dry, and keep cords in good condition. Failure to do so could result in serious personal injury or death.
  • Page 14: Appendices

    Appendices LW CableGlider Assembly...
  • Page 15 LW CableGlider BOM ITEM PART NO. DESCRIPTION 02001900 FLATWSHR,FENDER .375 X 1.50 02004500 LOCKWSHR 0.37 REGULAR ST CZ 02203901 PIN,HAIR .62 SHAFT-.15 DIA 02288429 CAPSRW 0.31-18X0.75 HHSTGR5 CZ 02288686 CAPSRW 0.50-13X2.50 HHSTGR5 CZ 02289016 PIN, .375 DIA - 2.250 LG QUICK 02289407 PIN,QUICK RELEASE - 0.50 X 5.50 02289408...
  • Page 16: Lw Cableglider Wiring Diagram

    LW CableGlider Wiring Diagram...
  • Page 17: Lw Cableglider Accessories

    LW CableGlider Accessories Internal Adapter External Adapter Duct Adpaters Part Number Description 08678240 External Adapter, 1.00" Conduit 08678245 External Adapter, 1.25" Conduit 08678250 External Adapter, 1.50" Conduit 08678255 External Adapter, 2.00" Conduit 08678260 External Adapter, 2.50" Conduit 08678265 External Adapter, 3.00" Conduit 08678270 External Adapter, 3.50"...
  • Page 18: Lw Cableglider Accessories

    Replacing Fork Thumbscrew: 1. Remove thumbscrew with a tap and hammer. (See Figure 7) 2. Insert new thumbscrew (See Figure 8) Figure 7 Figure 8 3. Place lockwasher on thumbscrew (See Figure 9), use a 5/16” socket to push lockwasher onto the thumbscrew (See Figure 10).
  • Page 19 NOTES:...
  • Page 20 NOTES:...
  • Page 21 NOTES:...
  • Page 22: Warranty Information

    Condux International, Incorporated warrants to the original purchaser for use that the goods or any component thereof manufactured by Condux International will be free from defects in workmanship for a period of 1 year form the date of purchase, provided such goods are installed, maintained, and used in accordance with Condux’s written instructions.
