ASP STERRAD 100 Service Manual

Sterilization system
Hide thumbs
Table of Contents

Advertisement

Quick Links

STERRAD
100 Sterilization System
®
Service Guide
Advanced Sterilization Products
33 Technology
Irvine, California 92618
1-888-STERRAD
TS-02859-0-002 REV D
®
This guide contains information on servicing the STERRAD
100 S Sterilizer. The
STERRAD 100 S Sterilizer is for international use only. No use other than testing related
to the development and submission of information to the FDA is authorized in the
United States.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STERRAD 100 and is the answer not in the manual?

Questions and answers

Related Manuals for ASP STERRAD 100

Summary of Contents for ASP STERRAD 100

  • Page 1 This guide contains information on servicing the STERRAD 100 S Sterilizer. The STERRAD 100 S Sterilizer is for international use only. No use other than testing related to the development and submission of information to the FDA is authorized in the...
  • Page 2 © 1997 Advanced Sterilization Products Services, Inc. All rights reserved ALLIANCE Service Program is a registered service mark of Advanced Sterilization Products Services, Inc. Other products mentioned in this publication are trademarked by their respective corporations. Reproduction, adaptation or translation of this publication without prior written permission is prohibited.

  • Page 3: Table Of Contents

    Phase 4 - Venting ......2-21 STERRAD 100 S Process Times ....2-21 CHAPTER 3.
  • Page 4 Cassettes ......5-3 Error Handling ......5-4 i-iv STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 5 ....6-24 Replace the Control Enclosure ....6-25 ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 6 AC Calibration ......9-2 AC Removal/Replacement ....9-3 i-vi STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 7 System Reset ......11-19 Verify Voltages ......11-19 ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 8 Leak Back Test ......13-10 i-viii STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 9 Printer Test ......B-42 ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 10 REV A/B Information ..... . . 1-3 What’s New Table ......1-4 ASP Service Guide rev. D STERRAD® 100 Sterilizer...

  • Page 11: Chapter 1. About The Service Guide

    The parts lists have been eliminated. The STERRAD Sterilization Systems Parts Book contains all the parts available for the STERRAD 50, 100 and 100 S Systems. STERRAD 100 SI GMP Sterilizer parts are contained in a separate Parts Book addendum.

  • Page 12: Revision C Information

    STERRAD 100 S Sterilizer you should perform all procedures according to the model type (Block 1.8 or Block 2.) If the servicing procedure is different because of the STERRAD 100 S Software, this is noted in the text and you should be certain you are performing the correct procedure for a STERRAD 100 S System.

  • Page 13: What's New Table

    What’s New Table The What’s New Table features brief descriptions of various changes to the STERRAD 100 sterilizer that make up Block 2 and information on STERRAD 100 S differences. Where Block 2 components and procedures changed from Block 1.8 or where information on older components is presented, these are noted in the table and detailed in various sections in the guide.
  • Page 14 Analog to digital set point test point are in a different location. Microprocessor PCB is different All STERRAD 100 S Systems have a Change from rev C Z180 CPU. AC subsystem AC circuit breakers are on the exterior of the system in Block 2.
  • Page 15 If a Block 1.8 system is upgraded to use the STERRAD 100 S Software, he membrane switch must be changed to accommodate the software and language differences. Installation...
  • Page 16 If you wish, using the form as a guide, email your information. The email address is: RTAPPY@aspus.JNJ.COM. Be sure to enclose your full name, location phone number and fax number. ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 17 Phase 4 - Venting ......2-21 STERRAD 100 S Process Times ..... 2-21 ASP Service Guide rev.

  • Page 18: Chapter 2. System Operation

    10 Sterility Assurance Level (SAL) in a cycle time of approximately 75 minutes (51-72 minutes for the STERRAD 100 S System). This process does not create toxic by-products nor dangerous heat levels and requires no special venting or piping. Many types of medical instruments and equipment can be safely and completely sterilized with this process.

  • Page 19: Routine Maintenance

    Service Philosophy Sterilizer servicing is limited to the service activities described in this guide. All planned and corrective maintenance activities must be performed by ASP or its authorized representative. Unauthorized repairs void the warranty. The Sterilization Cycle The sterilization cycle is automatically controlled by a programmed microprocessor that monitors operating parameters and controls each of the five stages of the cycle.
  • Page 20 If the cycle was interrupted by an apparent malfunction, the printout indicates the reason for the interruption and suggests appropriate corrective action. STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 21 6.0 Torr 14.0 Torr Diffusion Pump Down Phase Time 2:00 min:sec 2:01 min:sec Pressure control point 475 mTorr 525 mTorr Plasma Stage Delivered power 365 Watt 450 Watt Pressure 475 mTorr 525 mTorr ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 22 If 300 mTorr is not reached within 20 minutes, the system aborts the process and restarts automatically. If the sterilizer restarts automatically and the cycle cancels again for the same error, the abort cycle occurs. STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 23 “Over Pressure In Diffusion.” If the chamber pressure drops below 6 Torr, some absorptive material may be in the load and the cycle is canceled with the message “Low Pressure in Diffusion.” ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 24 The combined use of hydrogen peroxide vapor and plasma, safely and rapidly sterilizes most medical instruments and materials without leaving toxic residues. STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 25 LCD displays “Process Complete.” First Vent Duration Parameter Limit Variable Pressure switch ~690 Torr Pump Down Duration Parameter Limit Variable Pressure 1 Torr Final Vent Duration Parameter Limit Variable Pressure switch ~690 Torr ASP Service Guide rev. D STERRAD® 100 Sterilizer...

  • Page 26: Canceled Cycles

    RF power and the vacuum pump are turned OFF; the chamber is vented to atmosphere. F The alarm is sounded again for 10 seconds. F The appropriate cancellation message is printed. F The door opens. 2-10 STERRAD® 100 Sterilizer ASP Service Guide rev. D...

  • Page 27: Alarm Limits By Parameter

    Pressure recovery time after turning on Plasma (RF) 1 min. Pressure out of range 15 min. Plasma on period 8 min. Vent stage maximum time 100 min. Process time-out 15 sec Cassette acceptance time-out ASP Service Guide rev. D STERRAD® 100 Sterilizer 2-11...
  • Page 28 6 Torr Low injection pressure alarm (6-20 min.) 12 Torr Upper injection pressure alarm ( min.) 6 Torr Low diffusion pressure alarm (20-48 min.) 14 Torr Upper diffusion pressure alarm (6 min.) 2-12 STERRAD® 100 Sterilizer ASP Service Guide rev. D...

  • Page 29: Software Overview

    The software controls the machine in the monitor state including the processing of hydrogen peroxide cassettes. ASP Service Guide rev. D STERRAD® 100 Sterilizer 2-13...
  • Page 30 All other sensors used as inputs to the system are digital. Digital and analog inputs are used to monitor all phases of the process, just as digital outputs control the process. 2-14 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 31 F The RF power can not be activated if the chamber pressure is over 700 mTorr. F If a failure occurs, a 10 minute CANCEL CYCLE runs to prevent exposure of the operator to H vapor. ASP Service Guide rev. D STERRAD® 100 Sterilizer 2-15...

  • Page 32: User Interface And Operator Controls

    Frequency, User Interface, and AC Interface are all subsystems of the STERRAD® 100 Sterilizer. Each fabricated part is indelibly marked with the ASP part number and revision. A visible, major component of each service module is marked with the assembly part number and revision level. Major subassemblies also bear a serial number.

  • Page 33: Additional Documentation

    Manual - English F 90-04679-0-001 STERRAD 100 Sterilization System Feedthrough Removal and Replacement Service Video F 90-04680-0-001 STERRAD 100 Sterilization System Door Removal and Replacement Service Video The videos are also available in PAL and SECAM formats. Service Guide Changes Changes to procedures that occur between updates are usually communicated by Service Technical or TSNews Bulletins.

  • Page 34: Sterrad 100 S Theory Of Operation

    10-6 Sterility Assurance Level (SAL) for devices within label claims,. The STERRAD 100 S Sterilizer has two separate peroxide injections/plasma stages, rather than one, in the sterilization cycle.

  • Page 35: Phase 2 - Sterilization A

    STERRAD 100 S Theory of Operation System Operation Step Three At the end of the 15 minutes, the chamber is vented to atmospheric pressure with filtered air. Step Four After the chamber reaches atmospheric pressure, there is a reduction of pressure in the chamber from 760 Torr (atmospheric pressure) to 0.4...

  • Page 36: Phase 3 - Sterilization B

    System Operation STERRAD 100 S Theory of Operation Step Five At the conclusion of the plasma stage, pressure is reduced in the chamber from 0.5 Torr to 0.4 Torr through the use of a vacuum pump. Phase 3 - Sterilization B This is a repeat of the Sterilization A phase, excluding the final step.

  • Page 37: Phase 4 - Venting

    STERRAD 100 S Theory of Operation System Operation Phase 4 - Venting Step One At the conclusion of the plasma step, the chamber pressure is returned to atmospheric pressure by venting with filtered air. This concludes the process and the instruments are ready to be removed for use or for storage.
  • Page 38 System Operation STERRAD 100 S Theory of Operation Figure 2-3. Long Cycle Process Curve 2-22 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 39 STERRAD 100 S Theory of Operation System Operation Step Cycle Parameters Short Cycle Time Long Cycle Time Vacuum to 700 mTorr 5 minutes (approx) 5 minutes (approx) Pre-Plasma at 800 mTorr 10 minutes 15 minutes Vent to 760 Torr 1 minute...
  • Page 40 Introduction ....... . . 3-2 Using System Messages ......3-2 ASP Service Guide rev D STERRAD® 100 Sterilizer...

  • Page 41: Introduction

    Cycle Canceled display. Using System Messages Messages with þ next to them are exclusive to STERRAD 100 S systems. IMPORTANT!: Your first step when troubleshooting a system is to verify that the system is properly connected to the power source, and to make sure all the subsystems are properly connected to the AC system and all circuit breakers are on and functioning normally.
  • Page 42 This cassette has expired or the sterilizer system date is incorrect. Action F The cassette automatically exits to the collector box. Insert a new cassette. F Check system date—pay particular attention to the year. Reset if incorrect. ASP Service Guide rev D STERRAD® 100 Sterilizer...
  • Page 43 F If you are not processing a flexible scope, press START to start a short cycle. F If you are processing a flexible scope, press CANCEL to go to the CYCLE 2 (long cycle) option. STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 44 F Take the pneumatic door cylinder pressure hoses and switch them. (One hose blows air.) Door should open but cannot now be closed. F Replace door pneumatics solenoid. F Check vacuum switch. ASP Service Guide rev D STERRAD® 100 Sterilizer...
  • Page 45 Cassette ejection is greater than 20 seconds or cassette capture is more than 30 seconds. Action F A cassette is stuck in the injector pump. Remove it. F Check injector pump optics F Check injector pump pneumatic solenoid. INCORRECT CASSETTE TYPE STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 46 There is no printed message for this condition. Problem/Condition F The inserted cassette is not the correct type for the STERRAD® 100 Sterilizer. F The inserted cassette is not the correct type for the STERRAD 100 S Sterilizer. Action F Insert a STERRAD 100 Cassette.
  • Page 47 The faulty cassette ejects into the collection box. F Insert a new cassette. F Repackage the load. F Restart the sterilizer. Injector heater failure. Call ASP Technical Service. Problem/Condition The current sensor has not detected activation of the vaporizer heater.
  • Page 48 F Repackage the load. F Restart the sterilizer. INSERT NEW CASSETTE There is no printed message for this condition. Problem/Condition There is no cassette in the machine. Action Insert a new cassette. ASP Service Guide rev D STERRAD® 100 Sterilizer...
  • Page 49 No cassette is in the machine. Action Insert a new cassette INSERT NEW CASSETTE MAINTENANCE DUE There are two possible printed messages F PM interval due L1. F PM interval due L2. 3-10 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 50 Using System Messages System Messages Low Pressure In Diffusion Call ASP Technical Service Problem/Condition The system did not reach atmospheric pressure by the end of the diffusion stage. For the second consecutive cycle, diffusion pressure is under 6 Torr. There is insufficient H2O2 for diffusion or it is being absorbed by the load.
  • Page 51 Action Check customer log to determine if there is an ongoing problem in this area. Additional customer training may be necessary. Low pressure in injection. Call ASP Technical Service. Problem/Condition F For the second consecutive cycle, the pressure did not rise above 6 Torr at the end of the injection stage.
  • Page 52 F Make sure heater is plugged in and voltage is 24 VAC F Inspect the injection subsystem for malfunction including possible dissolved outer coating due to excessive hydrogen peroxide contact. F Replace injector valve ASP Service Guide rev D STERRAD® 100 Sterilizer 3-13...
  • Page 53 F Make sure the load is not in contact with the electrode. F Repackage the load. F Restart the sterilizer. Low RF Power in Vacuum. Call ASP Technical Service Problem/Condition RF delivered power is less than 365 W but greater than 200 W.
  • Page 54 Using System Messages System Messages Low plasma power. Call ASP Technical Service. Problem/Condition RF delivered power is less than 365 W but greater than 200 W. Action F Remove the shelves and run an empty chamber cycle. If completed correctly, reinstall the shelves.
  • Page 55 F Insert a new cassette. F Repackage the load. F Restart the sterilizer. NO DISPLAY Software anomaly SP = XXXXX Call ASP Technical Service Problem/Condition There is a software error. The printed message contains the memory address of the error.
  • Page 56 Using System Messages System Messages No RF Power in Vacuum. Call ASP Technical Service Problem/Condition RF delivered power is less than 100 W. Action F Check the load and make sure it is not in contact with the electrode. F Check the shelves and make sure they are not in contact with the door, or the chamber.
  • Page 57 Operator cancellation. Repackage load. Restart sterilizer. Problem/Condition F Operator canceled cycle. F Operator canceled cycle during the first part of the vacuum stage. Action F Repackage the load. F Restart the sterilizer. 3-18 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 58 Action F Check the over center sensor. F Replace the over-center sensor. F Check injector pump harnesses. Over pressure in diffusion. Call ASP Technical Service Problem/Condition F For the second consecutive cycle, diffusion pressure is over 14 Torr, F During empty chamber cycle a steady rise in chamber pressure is seen in injection stage and then in diffusion stage with sudden shut-down in diffusion.
  • Page 59 F Remove any plastic-like materials from the load. They may be out-gassing. F Repackage the load. F Restart the sterilizer. Over pressure in injection. Call ASP Technical Service. Problem/Condition For the second consecutive cycle, the chamber pressure is above 12 Torr in the injection stage.
  • Page 60 Over Pressure In Injection See Op Manual Appendix A Problem/Condition The chamber pressure is above 14 Torr in the injection stage of the STERRAD 100 S System. Action F Replace cassette. F Inspect injection system. F Perform leak back test.
  • Page 61 System Messages Using System Messages Plasma not lit. Call ASP Technical Service. Problem/Condition RF delivered power is less than 200 W but greater than 100 W. Action F Check shelves and make sure they are not in contact with the electrode or chamber door.
  • Page 62 1450-1499 cycles have been counted since the last PM. PM 2 is due. Also, there is no cassette in the sterilizer. Action F Insert a cassette to continue the current cycle. F Perform the Level 2 PM as soon as possible. ASP Service Guide rev D STERRAD® 100 Sterilizer 3-23...
  • Page 63 Check customer log to determine if there is an ongoing problem in this area. If this is a chronic problem, site may have chronic power problems that need to be addressed by ASP Technical Services and customer’s engineering department. Power interrupted. Call ASP Technical Service.
  • Page 64 Action F Repackage the load and restart the sterilizer. If the problem persists: F Check incoming power supply. Verify that phase is correct. F Check for loose connections. F Replace enclosure. ASP Service Guide rev D STERRAD® 100 Sterilizer 3-25...
  • Page 65 System Messages Using System Messages Pressure out of range. Call ASP Technical Service. Problem/Condition F For the second consecutive cycle, pressure did not stabilize within the range of 475 mTorr to 525 mTorr after 5 minutes or was out of range more than 60 seconds.
  • Page 66 There is no printed message for this condition. Problem/Condition F The printer buffer has exceeded the maximum allowed value of 23. F Cycle completed or canceled with no printout. Action Perform a Master Reset. ASP Service Guide rev D STERRAD® 100 Sterilizer 3-27...
  • Page 67 “Auto-restart performed” and one or more of the following informational messages: 4 4 Note: STERRAD 100 S Systems do not have an auto-restart feature. STERRAD 100 S Process Complete...
  • Page 68 Using System Messages System Messages PROCESS COMPLETE CALL TECHNICAL SERVICE F Level 1 PM Interval Past Due. Call ASP Technical Service. F Level 2 PM Interval Past Due. Call ASP Technical Service. Problem/Condition F The Level 1 PM is past due.
  • Page 69 System Messages Using System Messages STERRAD 100 S Process Complete Messages Any of the following printed messages can be received along with the PROCESS COMPLETE display. If the process was completed without an auto-restart, the printed message contains all the process parameters. I...
  • Page 70 There is no printed message for this condition. Problem/Condition This message appears for 5 seconds on power-up in all cases except: when the system was idle or following a master reset. Action No action is required. ASP Service Guide rev D STERRAD® 100 Sterilizer 3-31...
  • Page 71 A cassette is stuck at the top of the exit chute. Action F YOU MUST WEAR GLOVES! Open the door on the right side, and remove the cassette from the chute. Place it in the collection box. 3-32 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 72 Service. Problem/Condition F RF delivered power is less than 100 W. 4 4 Note: This message does not appear on the STERRAD 100 S Sterilizer. Action F Check the load and make sure it is not in contact with the electrode.
  • Page 73 System Messages Using System Messages TEMP SENSOR DISCONNECTED NO MORE CYCLES CAN RUN Temperature Sensor Disconnected. Call ASP Technical Service Problem/Condition The temperature sensor is disconnected or has failed. Action F Check the temperature sensor and make sure it is connected and operating normally.
  • Page 74 F Replace solid state relay board F Replace analog board F Replace thermistor. TEMP. OVER THRESHOLD. NO MORE CYCLES CAN RUN Temperature Over Threshold. Call ASP Technical Service. Problem/Condition The temperature of the door or chamber has risen above the specified limits. Action F Replace state relay board.
  • Page 75 System Messages Using System Messages TEMP. SENSOR FAILURE. NO MORE CYCLES CAN RUN. Temperature sensor failure. Call ASP Technical Service Problem/Condition Temperature of door or chamber is 0° C. Action F Test the thermistors for possible failure. F Perform the heater test.
  • Page 76 F Check vacuum pump and add oil if needed. F Check PM log and perform PM if needed. F Replace throttle valve. F Replace vacuum pump. Vacuum Insufficient for Plasma. Call ASP Technical Service. Problem/Condition For the second consecutive cycle, the vacuum did not reach 525 mTorr in the first 3 minutes of the plasma stage.
  • Page 77 F For the second consecutive cycle, vacuum did not reach 300 mTorr after an auto-restart. Action Run an empty chamber cycle. If the cycle runs successfully, the problem is with the load. F Repackage the load. F Restart the sterilizer. 3-38 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 78 F Remove any cloth, paper or foam items from the load. F Repackage the load. F Restart the sterilizer. Vacuum System Interrupted Call ASP Technical Service Problem/Condition The chamber is still at atmospheric pressure after the first 30 seconds of vacuum.
  • Page 79 System Messages Using System Messages VACUUM SYSTEM INTERRUPTED. NO MORE CYCLES CAN RUN. Vacuum system interrupted. Call ASP Technical Service. Problem/Condition The chamber is still at atmospheric pressure after the first 30 seconds of vacuum. Action F Test the vacuum system F Check power for proper CBA phase rotation.
  • Page 80 Using System Messages System Messages Vaporizer out of range Call ASP Technical Service Problem/Condition The current sensor has not detected activation of the vaporizer heater. Action F Check vaporizer heater. Replace if necessary. F Replace current sensor. VENT TIME OUT...
  • Page 81 System Messages Using System Messages VENT TIME-OUT CALL TECHNICAL SERVICE Vent time-out. Call ASP Technical Service. Problem/Condition Atmospheric pressure was not detected by the end of the vent stage in vacuum, diffusion or at the end of the sterilization cycle.
  • Page 82 The leak back test results are greater than 25 mTorr; or there is evidence of a large leak in that the system cannot pump down below 700 mTorr. Action F Identify source of leak. F Replace the failed unit. ASP Service Guide rev D STERRAD® 100 Sterilizer 3-43...
  • Page 83 F Make sure electrode screw is tight. F Make sure all RF system connectors and screws are tight. F Replace the electrode. 3-44 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 84 RF match connector and the RF connector with alcohol. Then CAREFULLY scuff the connector with needle nose pliers to make a better contact. F Replace the RF cable. ASP Service Guide rev D STERRAD® 100 Sterilizer 3-45...
  • Page 85 If the leak, continues the vent valve may be the problem.. 3-46 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 86 1. If you notice the door touching the left rail as it ravels to the top, loosen both lower door cables. 2. Tighten the left cable first and then tighten the right one. ASP Service Guide rev D STERRAD® 100 Sterilizer 3-47...
  • Page 87 Vacuum Pump Ballast Valve Adjustments ....4-7 Removal/Replacement Procedures ....4-8\ ASP Service Guide rev. D STERRAD® 100 Sterilizer...

  • Page 88: Chapter 4. Vacuum Subsystem

    If a Block 1.8 system with a D16A pump is going to be used with STERRAD 100 S Software, the pump musts be upgraded with a D16B oil return system as well as other upgrades so that it works correctly with the software.

  • Page 89: Theory Of Operation

    1 liter/sec of helium leaks into the chamber with the pump turned off. 4 4 Note: The vacuum system has the capability of evacuating the ® empty, dry, STERRAD sterilizer chamber to a pressure of 300 mTorr within 5 minutes. ASP Service Guide rev. D STERRAD® 100 Sterilizer...

  • Page 90: Exhaust Filter

    Oil Return Valve This part is on Block 2 and STERRAD 100 S Devices. The oil return valve, a normally closed solenoid valve, is opened at the beginning of the vacuum stage for 5 seconds or 10 seconds (STERRAD 100 S Systems) to allow oil to return into the vacuum pump from the exhaust filter.
  • Page 91 Once you have verified these things, proceed with your troubleshooting steps. Calibration Topics: F Adjusting The Vacuum Switch F Vacuum Pump Ballast Valve Adjustments F Vacuum Subsystem Tests (AutoTest) ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 92 2. When P1 through P4 are all set to 0, the vacuum switch should be detecting atmosphere, and it beeps to indicate this. 0 is displayed and the red/green LEDs turn OFF. STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 93 4. On the D16A pump align one of the cap holes with the hole in the valve so that it is fully exposed. Cover it with your finger to verify suction. 4 4 Note: Visually aligning the holes may require the use of an inspection mirror. ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 94 4. Disconnect the throttle valve wiring harness. Using two wrenches, unfasten the VCO connector holding the vacuum switch assembly to the throttle valve assembly. Remove by hand taking care not to lose or damage the O-ring inside the vacuum switch. STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 95 Removal/Replacement Procedures Vacuum Subsystem Figure 4-2. Vacuum System Remove Steps ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 96 Remove the Drain Valve 11. Unscrew the drain valve as an entire unit. 4 4 Note: Drain valve replacement requires the use of the drain valve kit. 4-10 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 97 Remove the Oil Return Valve 12. Unfasten the VCO connector securing the oil return valve to the pump. (Block 2 and STERRAD 100 S Systems). Remove the Pump 13. Remove the 8 bolts and washers securing the pump to the sump plate.
  • Page 98 Vacuum Subsystem Removal/Replacement Procedures Figure 4-3. Vacuum Subsystem Replacement Procedures 4-12 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 99 8. Verify that the valve actuator is vertical and the intake filter side is on the HI VAC side of the pump. 9. Attach the elbow to the chamber port. Align the elbow to the throttle valve. ASP Service Guide rev. D STERRAD® 100 Sterilizer 4-13...
  • Page 100 Plug the connectors together and join the ground lugs with the external tooth lockwasher trapped between them. Secure with the flat washer and lock nut. The proper connectors are included in the conversion kit. 4-14 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 101 Removal/Replacement Procedures Vacuum Subsystem 17. Route the harness beneath the pump platform. Connect the pump to the AC enclosure. ASP Service Guide rev. D STERRAD® 100 Sterilizer 4-15...
  • Page 102 Block 2 Injector Valve/Vaporizer Removal ....5-12 Replace the Injector Valve ..... . . 5-12 ASP Service Guide rev D STERRAD® 100 Sterilizer...
  • Page 103 Configurations The STERRAD® 100 system is currently in the Block 2 and STERRAD 100 S System phases. The Block 2 version of the STERRAD 100 Sterilizer is different, with regard to the injection subsystem, from previous versions of the STERRAD 100 system. The injector pump has the same appearance from Block 1.8 to Block 2.
  • Page 104 IF THE INDICATOR IS RED, THE CASSETTE HAS BEEN DAMAGED. Return all damaged cassettes, unopened, to ASP Customer Support. An inserted cassette is pressed under a roller and sensed by the cassette sensor (a reflective optical device) and advanced to read the bar-code.
  • Page 105 1. Manually extend the injector cam and insert the cassette gap tool (injector valve gage) from the back of the platen. Position it on the injector valve seal retainer plate over the injector valve needle seals. STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 106 Perform the check with the cam fully extended and adjust if necessary so that tool is fully contacting seal clamp plate of injector valve and clamp base (not the O-ring) of the injector pump clamp. ASP Service Guide rev D STERRAD® 100 Sterilizer...
  • Page 107 Injection Subsystem Calibration 4 4 Note: Be sure to use the appropriate cassette for STERRAD 100 Systems or for STERRAD 100 S Systems. They are different. 4. Place a piece of tape (Scotch Brand type) on the bottom of a used, empty cassette.
  • Page 108 1. Start the cassette adjustment test and press START on the control panel. 2. Insert an appropriate cassette (STERRAD 100 Cassette or STERRAD 100 S Cassette) so that the leading edge is approximately 20 mm past the drive roller. Watch the cassette as it travels on to the rear portion of the injector pump.
  • Page 109 Figure 5-2. Floating Guide Adjustment Injector Pump Pneumatics The injector pump pneumatics are factory set with the aid of optical and air flow sensors. Do not attempt to adjust the speed control valves in the field. STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 110 Attachment procedures are shown below. 1. Place the injector pump on the chamber. Align the front and center mounting holes. (See the diagram.) ASP Service Guide rev D STERRAD® 100 Sterilizer...
  • Page 111 3. Attach the cassette chute assembly to the injector pump. 4. Attach the connections to the injector pump. 5. Insert an appropriate cassette (STERRAD 100 Cassette or STERRAD 100 S Cassette) into the pump through the cassette door prior to securing the pump.
  • Page 112 2. Disconnect the vaporizer heater cable. 3. Place your hand inside the chamber to catch the injector valve. Press down on the injector valve to drop the entire unit into the chamber. ASP Service Guide rev D STERRAD® 100 Sterilizer 5-11...
  • Page 113 5. Once the vaporizer is hand tight, use the spanner wrench to tighten completely. 6. Reinstall the injector valve into the vaporizer and reinsert the screws; do not tighten at this point. 5-12 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 114 Controller Calibration ... . 6-23 Power Supply Adjustment ..6-23 Analog To Digital (Set Point) ..6-24 ASP Service Guide rev D. STERRAD® 100 Sterilizer...

  • Page 115: Introduction

    ® 100 system is currently in the Block 2.0 and The STERRAD STERRAD 100 S System phase. These versions of the STERRAD 100 Sterilizer are different, with regard to the user interface, from the Block 1.8 STERRAD system. F The printer paper outlet is higher up on the panel.
  • Page 116 F When the process is complete, the RF energy is turned off, the vacuum is released and the chamber is returned to atmospheric pressure by venting through a High Efficiency Particulate Air (HEPA) filter. The items within are sterilized and ready for use. ASP Service Guide rev D. STERRAD® 100 Sterilizer...

  • Page 117: Theory Of Operation

    The STERRAD 100 S System uses the same membrane switch panel as Block 2 systems. This panel has multiple language choices on the key pad.
  • Page 118 For these three areas the software uses a 10 millisecond interrupt as an interrupt for faster processing: F the throttle valve controller F the bar code reading F cassette positioning mark detector ASP Service Guide rev D. STERRAD® 100 Sterilizer...
  • Page 119 F OPEN DOOR - Opens the door when the machine is in idle mode. F CLOSE DOOR - Closes the door. F PAPER ADVANCE - Advances the printer paper while the switch is pressed. Edit Mode STERRAD® 100 Sterilizer ASP Service Guide rev D.

  • Page 120: Controller Operation

    RS232 controller, a 16 bit programmable timer and a twelve source interrupt controller. The CPU also has two 8-bit parallel digital I/O with handshaking capabilities (8420 PIO) and a counter/timer controller with four additional 8 bit counter/timers (8430 CTC). ASP Service Guide rev D. STERRAD® 100 Sterilizer...
  • Page 121 F Straps for user-selectable address decoding F Crystal controlled clock· F 20 pin external header connection for the analog signal input. F 14 pin external DIP switch for interrupt priority. F +5.00 VDC at 0.7 amps STERRAD® 100 Sterilizer ASP Service Guide rev D.
  • Page 122 2 Amps (5 Amps peak) The second power supply, which is used for the throttle valve stepper motor, printer, and cassette drive motor, is a single output switching type: +12.85V at 6.5 Amps. ASP Service Guide rev D. STERRAD® 100 Sterilizer...

  • Page 123: User Interface Calibration

    F Setting the Printer DIP Switches F Setting the Audible Alarm F Setting the LCD Contrast F STERRAD 100 S System Settings F Setting System Parameters F Setting the System Clock F Setting the System Serial Number and Total Machine Cycles...

  • Page 124: Setting The Printer Dip Switches

    User Interface and Control Subsystems Setting the Printer DIP Switches The diagrams below show the DIP switch settings for Block 1.8. Figure 6-2. DIP Switch Settings Block 2. Figure 6-3. Block 2 DIP Switch Settings ASP Service Guide rev D. STERRAD® 100 Sterilizer 6-11...

  • Page 125: Setting The Audible Alarm

    System parameters or defaults are those settings that keep track of system activities. System activities are regularly included in the messages printed by the system. They are: F STERRAD 100 S System Settings F Setting the System Serial Number and Total Machine Cycles F Setting the System Clock...
  • Page 126 Total Machine Cycles are reset to 0 (this sets the cycle to the default). Enter the Edit Mode-STERRAD 100 S Systems 1. To enter the EDIT mode, press CANCEL. 2. Press and hold CANCEL and simultaneously press START. This opens the Date-Time menu.
  • Page 127 3. Press CLOSE or CANCEL to go to the Cycle Type menu. If you not setting the cycle type, press CANCEL twice to enter the Serial Number Menu Setting the Serial Number- STERRAD 100 S Systems The serial number menu looks like this: SERIAL NUMBER XXXXXX OPEN(chng) - CLOSE(accept) XXXXXX represents the machine serial number;...
  • Page 128 Then simultaneously press START and CANCEL to return to the active display. Setting the Cycle Type - STERRAD 100 S Systems 4 4 Note: The Cycle Type menu actually appears after the Clock Mode Menu.

  • Page 129: Setting The System Clock

    User Interface and Control Subsystems User Interface Calibration Parameter Printout- STERRAD 100 S Systems 1. When you exit the editor from the CYCLE TYPE menu by pressing START and OPEN DOOR, the values of the parameters are stored in the printer buffer.

  • Page 130: Setting The System Serial Number And Total Machine Cycles

    OPEN DOOR to set the digits to correspond to the machine cycles noted in Step 1. 7. Press CANCEL to change the fields. The serial number fields should be displayed. ASP Service Guide rev D. STERRAD® 100 Sterilizer 6-17...

  • Page 131: Master Reset

    CANCEL simultaneously. 3. Continue to hold CANCEL until you hear the beep signal, then release. 4. Remove the cassette collection box. Wait for the beep tone and then reinstall the empty box. 6-18 STERRAD® 100 Sterilizer ASP Service Guide rev D.

  • Page 132: Controller Calibration

    TB1 (terminal block 1). On Block 2 devices, locate the connector distribution connector J121 (TB1). The diagrams below show the adjustments for Block 2 (top diagram) and Block 1.8 (bottom diagram) ASP Service Guide rev D. STERRAD® 100 Sterilizer 6-19...
  • Page 133 12 volt power supply board. On Block 2 devices the trim pot is located in the lower right area of the 12 V power supply board. 6-20 STERRAD® 100 Sterilizer ASP Service Guide rev D.

  • Page 134: Analog To Digital (Set Point)

    Verify the temperature settings after adjusting the A/D set point. The A/D set point should be verified after any power supply voltage adjustment, or power supply replacement. ASP Service Guide rev D. STERRAD® 100 Sterilizer 6-21...

  • Page 135: User Subsystem Replacement Procedures

    3. Lift up on the printer to remove it. 4. Replace the printer by tipping it into place and replacing the screws. 5. Plug in the ribbon cable. Replace the paper roll. 6-22 STERRAD® 100 Sterilizer ASP Service Guide rev D.

  • Page 136: Remove/Replace The Printer (Block 2)

    The membrane then pulls away easily from the bezel. 4. To replace the membrane switch, press it into place and replace the screws or, on Block 2 devices, make sure it snaps into place. ASP Service Guide rev D. STERRAD® 100 Sterilizer 6-23...

  • Page 137: Control Subsystem Replacement

    4. Unscrew the control enclosure from the frame and remove it from the system. 4 4 Note: The Block 2 control enclosure is slightly different looking, on the inside, from the Block 1.8. Figure 6-6. Control Enclosure 6-24 STERRAD® 100 Sterilizer ASP Service Guide rev D.

  • Page 138: Replace The Control Enclosure

    2. Reattach the power supplies using the standoffs (Block 1.8, 5 V), or the 4 nuts (Block 1.8 12 V) or the 4 screws (Block 2) 3. Replace the control enclosure side panel. ASP Service Guide rev D. STERRAD® 100 Sterilizer 6-25...

  • Page 139: Remove/Replace The Firmware

    Pay close attention to the orientation of the chip. 7. Replace the microprocessor board. 8. Turn the main power circuit breaker to ON. 9. Perform a Master Reset. 6-26 STERRAD® 100 Sterilizer ASP Service Guide rev D.
  • Page 140 User Interface and Control Subsystems 10. Verify that the software parameters are displayed on the LCD. These parameters include the month and year, the words STERRAD 100 and the software part number and CS number. The parameters change with each software release.
  • Page 141 Door and Chamber Alignment ....7-7 Removal/Replacement ......7-13 ASP Service Guide rev D STERRAD® 100 Sterilizer...

  • Page 142: Introduction

    The door has no window (and is very heavy), though it can be pushed downward by hand if there is no vacuum in the chamber. STERRAD® 100 Sterilizer ASP Service Guide rev D...

  • Page 143: Door And Chamber Theory Of Operation

    F The operator closes the door (opens the door) using CLOSE DOOR (OPEN DOOR). F Pressing START begins the process by closing the door if it is open, and continues through a complete sterilizing cycle. ASP Service Guide rev D STERRAD® 100 Sterilizer...

  • Page 144: Calibration

    4 4 Note: Assure the system has had power applied for at least 45 minutes. 1. Remove the system panels. Begin an empty chamber cycle. 4 4 Note: On STERRAD 100 S Systems, perform the steps below during the second injection stage, not the diffusion stage. STERRAD® 100 Sterilizer...
  • Page 145 T/C 3 and T/C 4 are located on the lower right of the door. 4 4 Note: On STERRAD 100 S Systems, perform the steps below during the second injection stage, not the diffusion stage. 3. Connect an Omega thermocouple tester (J-type) to T/C 1. Verify that the temperature measured during the diffusion stage is 42º...

  • Page 146: Door Top, Bottom, And Over Center Sensors

    60 PSI, and to cut-out at 80 PSI. 2. Loosen the speed control valve locking nut on the control valve located on the exhaust (lower) side of the door cylinder. STERRAD® 100 Sterilizer ASP Service Guide rev D...

  • Page 147: Door And Chamber Alignment

    2. Using gage T.2270 align the frame to the right guide rail by adjusting upper edge of guide rail at top panel bracket. See the diagram. 3. Tighten all hardware securing the right guide rail to the frame, leaving the chamber hardware loose. ASP Service Guide rev D STERRAD® 100 Sterilizer...
  • Page 148 4. Tighten the three bolts securing the right guide rail to the chamber. 5. Tighten the stand-off between the guide rail and the frame. 6. Using gage T.2266 verify that the alignment of the chamber and the right guide rail has not changed. STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 149 4. Tighten the three bolts securing the left guide rail to chamber. 5. Using gage T.2266 verify that the alignment of the chamber and the left guide rail has not changed. ASP Service Guide rev D STERRAD® 100 Sterilizer...
  • Page 150 OUTER groove of the counterweight pulley. On Block 2 systems skip this step. Misalignment is not a problem on Block 2 systems. 7-10 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 151 12. Reconnect the air lines to the door cylinder. Replace the front panel. Perform the alignment procedures for Door Top, Bottom, And Over Center Sensors. ASP Service Guide rev D STERRAD® 100 Sterilizer 7-11...
  • Page 152 1. Loosen the brackets and gently move the chamber from side to side to bring it into alignment. 2. On Block 2, loosen the bracket at the side to move the chamber. 7-12 STERRAD® 100 Sterilizer ASP Service Guide rev D...

  • Page 153: Removal/Replacement

    9. Scrub the chamber, electrode and feedthrough connection with deionized water and a Scotch-Brite type scrub pad used for Teflon coated pans. (Performed as needed and routinely every year (PM2)). ASP Service Guide rev D STERRAD® 100 Sterilizer 7-13...
  • Page 154 5. Replace the Allen screw (located at the left, lower middle of the electrode) fastening the electrode to the chamber feedthrough. 6. Insert the upper and lower shelves into the chamber. (The diagram shows the shelves, shelf supports and spacers correctly installed.) 7-14 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 155 Information on installing a “show” door is included in the replacement section. 4 4 Note: One step in this procedure requires the assistance of another person. 1. Remove the system panels. Be sure to unplug the cassette door harness. ASP Service Guide rev D STERRAD® 100 Sterilizer 7-15...
  • Page 156 17. Loosen, but do not remove, the hex screw fastening the rail to the bottom of the frame. 18. Remove the screws fastening the rail to the chamber. Leave the middle screw in place, but loose. 7-16 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 157 There should be no play under the locknuts. 10. Manually raise the door and adjust the door stops so that the door over-center mechanism extends and evenly closes the door against the O-ring. ASP Service Guide rev D STERRAD® 100 Sterilizer 7-17...
  • Page 158 Following are the steps for removing a defective heater, cleaning the chamber of adhesive residue and installing a new heater. In addition, here is a list of additional supplies you will need to remove and install the chamber heaters. 7-18 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 159 3. For the bottom heater measure from the stiffener rib CLOCKWISE around the chamber and make a mark at 875 mm and one at 951 mm on the circumference of the chamber. See the diagram ASP Service Guide rev D STERRAD® 100 Sterilizer 7-19...
  • Page 160 Door and Chamber Subsystem Removal/Replacement Figure 7-7. Heater Measurements 7-20 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 161 9. Verify the correct heater voltage from the markings on the heater (120V for -001 or 240V for -002) 10. Clean the unprinted side of the heater with 3M Citrus Base Natural Cleaner and then isopropyl alcohol. ASP Service Guide rev D STERRAD® 100 Sterilizer 7-21...
  • Page 162 6. Smooth the heaters so they are completely attached to the chamber surface. 7. Plug in the heater power supplies and perform a heater test to verify heater temperatures as shown in the product certification section. 7-22 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 163 8. Block 2 only. CAREFULLY use a punch to remove epoxy from the air holes in the feedthrough port lip. Make sure these holes are completely free of epoxy as these holes release trapped air when the new epoxy is applied. ASP Service Guide rev D STERRAD® 100 Sterilizer 7-23...
  • Page 164 5. Fit 2 O-rings onto the feedthrough. See the diagram. 6. Block 2 only. Install one O-ring as shown in the Block 2 feedthrough diagram. Screw the epoxy tool, without the prominent edge, onto the end of the feedthrough. 7-24 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 165 10. Carefully and slowly pour the adhesive into the feedthrough opening. Be careful not to trap air while pouring. Use a metal probe to break any trapped air pockets. ASP Service Guide rev D STERRAD® 100 Sterilizer 7-25...
  • Page 166 19. Reinstall the RF match. Perform the RF power test and a second leak back test as shown in the Product Certification section. 20. Run a complete empty chamber cycle. 7-26 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 167 2. Place the quartz window against the O-ring between the bezel and plate. Loosely attach the screws. 3. Tighten the screws in a “star” pattern (similar to the method used to tighten bolts on a tire.) ASP Service Guide rev D STERRAD® 100 Sterilizer 7-27...
  • Page 168 Pneumatics Pressure Switch ..... . . 8-3 Pneumatics Removal/Replacement Procedures ... . 8-5 ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 169 100 system is currently in the Block 2.0 and STERRAD The STERRAD 100 S System phase. These versions of the STERRAD 100 Sterilizer is slightly different, in appearance only, from the Block 1.8 STERRAD 100 system. The calibration differences are noted in the text.
  • Page 170 4 Note: You do not need to remove the front panel to calibrate the pneumatic switch on a Block 2 device. 1. Remove the cover from the pneumatic pressure switch, and note the instructions diagram located inside the cover. ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 171 3. Adjust the left screw until the pneumatics pump stops operation at 80 ±3 PSI, as indicated by the air pressure gage located on the pneumatics panel (clockwise rotation increases the pressure set point). STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 172 The jumper on the pneumatic board should be configured as shown in the diagram above. Note the differences between Block 1.8 and Block 2. Figure 8-3. Pneumatics Panel Figure 8-4. Pneumatic Board ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 173 Remove the Solid State Relay PCB ....9-5 Replace the Solid State Relay PCB ....9-5 ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 174 The STERRAD® 100 system is currently in the Block 2.0 and STERRAD 100 S System phases. (100 S denotes a short cycle configuration.) The Block 2.0 version of the STERRAD 100 Sterilizer is slightly different, with regards to the AC interface, from previous versions of the STERRAD 100 System.
  • Page 175 They are held in place by screws and some are plug in parts. Because the removal of these components is self-evident, they are not detailed here. The following diagrams can be used with all AC replacement procedures. Figure 9-1. AC Enclosure Block 1 ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 176 5. (Block 2) Remove the thermal overload relay and the configuration board from the old enclosure and set them aside. Be sure to place the configuration board in a static safe area. STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 177 On Block 2 systems the screws are located on the outside of the enclosure. 4. From outside the enclosure, reconnect all electrical harnesses to the solid state relay board. 5. Close the AC enclosure panel. 6. Turn the main circuit breaker ON. ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 178 Remove the RF Enclosure ..... . 10-4 Remove the RF Match ..... . . 10-4 ASP Service Guide rev. D STERRAD® 100 Sterilizer...
  • Page 179 100 system is currently in the Block 2 and STERRAD The STERRAD 100 S System phase. These versions of the STERRAD 100 Sterilizer is slightly different, in appearance only, from the Block 1.8 STERRAD 100 System. The calibration differences are noted in the text.
  • Page 180 If any of the above situations occur, appropriate error messages are generated. See the System Messages section or look up RF using Find+ to view the RF related error messages. Figure 10-1. RF Subsystem ASP Service Guide rev. D STERRAD® 100 Sterilizer 10-3...
  • Page 181 1. Remove the 5 screws securing the RF match cover. Remove the RF match cover. 2. Remove the nut and screw securing the RF match to the feedthrough. See the RF diagram. To replace the RF match, do the following: 10-4 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 182 Radio Frequency (RF) Subsystem 1. Attach the RF match to the feedthrough using the nut and screw. 2. Replace the RF match cover. Figure 10-2. RF Enclosure Figure 10-3. RF match ASP Service Guide rev. D STERRAD® 100 Sterilizer 10-5...
  • Page 183 System Acceptance ......11-15 International System Configurations ....11-16 ASP Service Guide rev. D STERRAD® 100 Sterilizer...

  • Page 184: Introduction

    If you have an unusual circumstance where you are installing a system version that precedes Block 2, please contact ASP Technical Services. Pre-Installation Perform the following steps prior to uncrating the system. It is a good idea to have performed these steps prior to delivery of the system.

  • Page 185: Uncrating The System

    4 4 Note: The crate panels fit together with a tongue and groove mechanism. The top must be lifted off the sides and the sides must be lifted up from the pallet base. ASP Service Guide rev. D STERRAD® 100 Sterilizer 11-3...
  • Page 186 Remove the boxes from inside the system. 4 4 Note: The boxes shipped with the system contain vacuum system parts and other system accessories. Be sure to unpack the boxes completely before discarding. 11-4 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 187 System Installation 19. If you are going to move the unit to a different site, replace the side and lower back panels. 20. Once the unit is in position in the installation site, remove all exterior panels and temporarily store them in a safe location. Figure 11-2.
  • Page 188 System Installation Uncrating the System Figure 11-3. Assembled Vacuum System 11-6 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 189 Uncrating the System System Installation Prior to assembling the unit make sure the following are completed or verified: F All vacuum fittings must be clean and free of foreign material. F Lightly coat all O-rings and seals with a thin film of high vacuum grease before installation.
  • Page 190 5. Remove both control enclosure panels and ensure that all cables attached to the connector distribution PCBs are secure. Verify that the 3 PCBs are fully inserted into their sockets. Plug the system into the outlet. 11-8 STERRAD® 100 Sterilizer ASP Service Guide rev. D...

  • Page 191: Installing The Seismic Restraints

    System Installation Installing the Seismic Restraints This procedure is for both Block 1.8 and Block 2 STERRAD 100 Sterilizers since the restraints can be used with either system type. This procedure is approved by the State of California Building Code as a valid seismic restraint procedure.

  • Page 192: Installing The Subframe

    4. Slide the front subframe piece (the one with the flange) into the groove on the unit. 5. Slide the rear subframe piece into the rear of the STERRAD 100 Sterilizer frame. Make sure it slides into the hollow track of the frame.

  • Page 193: Installing The Brackets

    4. If the drilling template was used, it should be completely removed, including the tape holding it, by this point. 5. Move the STERRAD 100 Sterilizer so that the subframe channels align with locating pins on the rear seismic bracket.

  • Page 194: Preparing The System For Use

    2. Install all the accessories in their proper locations. Make sure to wipe off any fingerprints or packaging material that may be present. 3. For STERRAD 100 S Systems set the cycle type according to the customer’s needs. Phase Rotation 1.

  • Page 195: Initialization

    4 4 Note: The reset is not accomplished until you exit the edit mode. 6. Reenter the edit mode, as shown above and change the total machine cycles to the number you wrote down in step 4. ASP Service Guide rev. D STERRAD® 100 Sterilizer 11-13...

  • Page 196: Cassette Collector Box

    Press CLOSE DOOR each time to move the cursor to the next field. After the YY is updated, the following message is displayed on the LCD: 11-14 STERRAD® 100 Sterilizer ASP Service Guide rev. D...

  • Page 197: Pm Log

    P.M. N: NEXT PM XXX OPEN (reset) - CANCEL (next) For STERRAD 100 S Systems press OPEN DOOR and START to enter the edit mode. Then proceed with step 1 above. 4 4 Note: The cursor flashes on the N/Y field. The NEXT PM field displays the total remaining cycles before the system stops running cycles.

  • Page 198: International System Configurations

    The receiving organization finishes the system and returns the completion notification to ASP. The instructions for this configuration are as follows; 4 4 Note: This information is for configuring a system for international shipment only.
  • Page 199 10. Install CR3 to CR2 by hooking CR3 into the cover of CR2 and inserting pins into CR2-T1, T2 and T3. Secure the terminal screws. 11. Attach the configuration board to the standoffs in the control enclosure and plug the connectors into the board. ASP Service Guide rev. D STERRAD® 100 Sterilizer 11-17...
  • Page 200 CAUTION! Pay particular attention to the orientation of the EPROM during insertion into its IC socket. Additionally, exercise care to ensure that the EPROM pins are not bent, broken, or otherwise damaged during insertion. 11-18 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 201 1. Measure AC voltages for chamber and door heaters, control enclosure, RF generator, vaporizer and compressor. Refer to chart for version main line voltage and nominal voltages expected ±10% for each circuit. ASP Service Guide rev. D STERRAD® 100 Sterilizer 11-19...
  • Page 202 Feature Measure Input Voltage At CB7 A-B Generator Chamber CB6 A-B Heaters Door CB4 A-B Heaters Control CB3 A-B Enclosure Vaporizer J-89 pin 7 Compressor Utility J-83B Figure 11-7. Terminal Block 11-20 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 203 1. Enter the complete system serial number. 2. Enter the configuration kit number. 3. Fill in your name, ASP service location, country, date and phone/fax numbers. 4. Enter the LC number from the label.
  • Page 204 Level 1 Planned Maintenance ..... 12-4 Level 2 Planned Maintenance ..... 12-9 ASP Service Guide rev. D STERRAD® 100 Sterilizer...

  • Page 205: Introduction

    Be sure you use the correct planned maintenance procedure. There is no particular PM procedure that is exclusive to the STERRAD 100 S Sterilizer. All the procedures in this section apply to this version of the STERRAD System.
  • Page 206 Replace Exhaust Filters Clean Door and Inside Chamber Assembly Clean Platen Surface Clean Door Seal and Replace Door Seal O-ring Replace Upper Shelf Stops Replace Electrode Spacers Product Certification Update PM Log ASP Service Guide rev. D STERRAD® 100 Sterilizer 12-3...

  • Page 207: Level 1 Planned Maintenance

    Open the valve to drain the oil. 3. After the flow has stopped, close the drain valve. Make sure the main circuit breaker is off before proceeding. 12-4 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 208 1. Place a towel below the pressure regulator trap prior to drainage. 2. Press upwards through the towel on the button at the bottom of the trap and permit water to escape. ASP Service Guide rev. D STERRAD® 100 Sterilizer 12-5...
  • Page 209 2. Clean the fan (Block 1.8 only.) 3. Thoroughly dry the filter and snap it back in place. 4. Vacuum the screen on the outside of the RF generator. Carefully vacuum inside the sterilizer. 12-6 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 210 Some oil may remain in the bottle when the pump oil is at the specified fill level. 8. Replace the oil fill plug on the pump. 9. Dispose of the drained oil following standard customer procedures for lubrication oils. ASP Service Guide rev. D STERRAD® 100 Sterilizer 12-7...
  • Page 211 2. Press CANCEL (display moves to date), then press START and CANCEL at the same time. The system display returns to the ready state and the printer prints the maintenance log. 12-8 STERRAD® 100 Sterilizer ASP Service Guide rev. D...

  • Page 212: Level 2 Planned Maintenance

    7. Seat the upper housing section on the lower section and tighten the screws. 8. Replace the filter assembly on the vacuum pump, then fit and hand tighten the clamp. ASP Service Guide rev. D STERRAD® 100 Sterilizer 12-9...
  • Page 213 2. Loosen the wing nut on the clamp holding the exhaust filter assembly on the vacuum pump, then open the clamp and remove the filter assembly. Be careful not to damage the O-ring seal. 12-10 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 214 2. Remove the new filter from its package, then fasten it into its receptacle. Firmly hand tighten the filter body. 4 4 Note: Do not use Teflon tape to re-seal the filter. 3. Discard the used filter according to hospital procedures. ASP Service Guide rev. D STERRAD® 100 Sterilizer 12-11...
  • Page 215 3. Close the chamber door. Close the storage drawer. Clean Platen Surface 1. Clean the surface of the injector pump platen with deionized water and a lint free cloth. 12-12 STERRAD® 100 Sterilizer ASP Service Guide rev. D...
  • Page 216 4. Press CANCEL (display moves to date), then press START and CANCEL at the same time. The system display returns to the ready state and the printer prints the maintenance log. ASP Service Guide rev. D STERRAD® 100 Sterilizer 12-13...
  • Page 217 Door Temperature ......13-11 Chamber Temperature ..... . 13-11 ASP Service Guide rev. D STERRAD® 100 Sterilizer...

  • Page 218: Introduction

    Block 2 and STERRAD 100 S Systems. It is important to note that Block 1.8 systems can be upgraded to run the STERRAD 100 S Software. If that has been done, perform the Block 1.8 tests unless the instructions indicate to do otherwise.
  • Page 219 All tests All Service Leak back test RF power measurement door and chamber temperature injection and diffusion pressure after 20 minutes (diffusion pressure does not apply to STERRAD 100 S Systems). Replace vacuum subsystem Leak back test RF power measurement door/chamber components temperature manual injection procedure (run complete cycle).

  • Page 220: Certification Procedures

    F Chamber Temperature F Block 2 Door and Chamber Temperatures System Preparation 1. Remove the access panels from the control enclosure and apply power to the enclosure by enabling the safety interlock. 13-4 STERRAD® 100 Sterilizer ASP Service Guide rev. D...

  • Page 221: Compressor Pressure Switch Test

    Voltage to be Positive Lead Negative Lead Acceptable Range Measured +5.2 VDC ±0.02 VDC Pin #3 Pin #1 +5.18 to +5.22 VDC +12.85 VDC ±0.05 Pin #4 Pin #1 +12.80 to +12.90 VDC ASP Service Guide rev. D STERRAD® 100 Sterilizer 13-5...

  • Page 222: Analog To Digital Set Point Test

    4 4 Note: On newer boards the test points and adjustment pot are located at the edge of the board. 2. Measure the voltage between IC-8 pin 39, and IC-8 pin 36. Verify the voltage measured is 2.048 VDC ±0.005 VDC. 13-6 STERRAD® 100 Sterilizer ASP Service Guide rev. D...

  • Page 223: High-Low Pressure Range Divider Voltage Verification

    6. Turn on the TM-20, the display indicates 7.6 X 10+2 Torr (760 Torr). In the video clip, the demonstrator indicates the major parts of the TM-20 that need to be assembled. ASP Service Guide rev. D STERRAD® 100 Sterilizer 13-7...
  • Page 224 TM-20 vacuum gauge. 10. After completion of the test remove the gauge, re-assemble the vacuum pump. 11. Perform a complete leak back test. If the test fails, inspect the system for leaks. 13-8 STERRAD® 100 Sterilizer ASP Service Guide rev. D...

  • Page 225: Injector Pump Floating Guide Check

    4. Set up a Bird Watt meter on the X10 kilowatt scale. The slug arrow should point towards the RF match. Start the Vacuum RF Test in AutoTest. At this point you may continue the entire RF Power Test using the AutoTest Vacuum_RF menu. ASP Service Guide rev. D STERRAD® 100 Sterilizer 13-9...

  • Page 226: Leak Back Test

    Be sure to perform these procedures in the sequence given. F Temperature Continuity Check F Vaporizer Heater Voltage F Door Temperature F Chamber Temperature Block 2 Door and Chamber Temperatures 13-10 STERRAD® 100 Sterilizer ASP Service Guide rev. D...

  • Page 227: Temperature Continuity Check

    (when viewed from the front), 40 mm in from the edge. 3. During the diffusion stage, the door temperature should measure 46° C ±2°C. 4. For STERRAD 100 S Systems, measure the temperature during the second injection stage. Chamber Temperature 1.
  • Page 228 T/C 3 and T/C 4 are located on the lower right of the door. 4 4 Note: For STERRAD 100 S Systems measure the temperature during the second injection stage. 3. Connect an Omega thermocouple tester (J-type) to T/C 1. Verify that the temperature measured during the diffusion stage is 42-50º...
  • Page 229 Thermocouples ........A-9 Tools and Test Equipment ......A-10 ASP Service Guide rev. D STERRAD 100 Sterilizer ®...

  • Page 230: Physical Specifications

    Approximately 350 Kg (750 lbs) Chamber Volume 173 liter (6.1 cubic feet) Usable Volume 100 liter (3.5 cubic feet) Inside Length 810 mm (32 inches) Inside Diameter 510 mm (20 inches) STERRAD 100 Sterilizer ASP Service Guide rev D ®...

  • Page 231: Environmental Conditions

    Operation Ambient +10 to 40° C (50 to 104° F) Temperature Altitude -100 to 3000 m above msl (-330 to 10,000 ft above msl) Relative Humidity 0 to 95% RH, non-condensing ASP Service Guide rev. D STERRAD 100 Sterilizer ®...
  • Page 232 Technical Data Overview Atmospheric 700 hPa to 1060 hPa Pressure Surface The floor at the installation is flat and level to + 5 mm/M. STERRAD 100 Sterilizer ASP Service Guide rev D ®...

  • Page 233: Electrical Requirements

    415V (Block 2) phase, 380V circuit with separate neutral and ground conductors. Phase Rotation The system requires CBA phase rotation. The phase rotation is adjusted to match the system requirements at installation. STERRAD 100 Sterilizer ASP Service Guide rev D ®...

  • Page 234: Heater Impedance

    Block 2 190 Ohms Chamber Block 2 100 Ohms Chamber top Block 1.8 50 Ohms Chamber bottom Block 1.8 50 Ohms Chamber rear Block 1.8 190 Ohms Door Block 1.8 50 Ohms ASP Service Guide rev D STERRAD 100 Sterilizer ®...

  • Page 235: Standards

    The shipping container includes an integral pallet which meets US and International standards. The package provides protection for the machine to pass NSTA tests ASTM D-999 and FED-STD-101. Block 2 meets UL standard 1262-Laboratory NRTL/C Equipment. STERRAD 100 Sterilizer ASP Service Guide rev D ®...

  • Page 236: Product Version

    05-02800-0-XXX. For Block 2 it is 05-02378-0-XXX. XXX is defined below. Version Description Germany France Australia Canada (English) Canada (French) Chile Japan South Africa Austria Italy Benelux (Eng) Benelux (Fr) Benelux (Dutch) Benelux (Ger) ASP Service Guide rev D STERRAD 100 Sterilizer ®...
  • Page 237 Technical Data Version Description Sweden Ireland Switzerland (German) Switzerland (French) Switzerland (Italian) Spain Taiwan Middle East Columbia Argentina Mexico Uruguay Korea Thailand Hong Kong Malaysia Brazil Venezuela Singapore ASP Service Guide STERRAD 100 Sterilizer ®...

  • Page 238: Thermocouples

    42°-50° C Edge of door Tools and Test Equipment The following items may be needed to perform the service procedures for the STERRAD 100 Sterilizer. Included are parts needed for chamber heater and feedthrough replacement. Manufacturer Model or ASP Part...
  • Page 239 Technical Data Manufacturer Model or ASP Part Where Used Number Block 2. Long arm Allen 35-01249-205 Planned maintenance wrench, metric 35-01249-108 Block 2. Vaporizer 35-03000-001 Repairs spanner wrench Block 2. Omega Omega HH-81 Product certification and calibration Thermometer with J-...
  • Page 240 Printer Test ......B-42 ASP Service Guide rev D STERRAD® 100 Sterilizer...

  • Page 241: Introduction

    Differences in configurations are shown where applicable. The tests are presented as follows: Test Name This heading indicates what subsystem is being tested. Display Shows the messages displayed on the LCD read-out. SAMPLE LCD Display STERRAD® 100 Sterilizer ASP Service Guide rev D...

  • Page 242: User Interface Tests

    F Verify that software part number and revision are correct. F Verify display is working and has proper contrast. F Adjust contrast with R1 pot on rear of display board. F Press a LONG CANCEL. ASP Service Guide rev D STERRAD® 100 Sterilizer...
  • Page 243 W/ LONG CLOSE Action Press a LONG CLOSE. Display OUTPANEL W/ START or NEXT Menu W/ LONG CANCEL Action To repeat the test, press the START key; otherwise press a LONG CANCEL. STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 244 Press CANCEL Display CANCEL SWITCH OK! PRESS CLOSE SWITCH Action Press CLOSE DOOR. Display CLOSE SWITCH OK!! PRESS OPEN SWITCH Action Press OPEN DOOR. Display OPEN SWITCH OK!! PRESS LONG CLOSE TO EXIT ASP Service Guide rev D STERRAD® 100 Sterilizer...
  • Page 245 Press START. Display ON/OFF LIGHTS W/ START NEXT LIGHT W/ CANCEL Action F Press START. F Verify both alarm lamps are on. F Press START to turn light off. F Press CANCEL. STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 246 F Press START. Verify both diffusion lamps are on. F Press START to turn light off. F Press CANCEL for next light test. Display ON/OFF LIGHTS W/ START NEXT LIGHT W/ CANCEL ASP Service Guide rev D STERRAD® 100 Sterilizer...

  • Page 247: Sensor Tests

    F Check bulbs and replace if necessary. F Check control signal from CPU to control panel board. F Check/replace control panel assembly. Sensor Tests Display SENSOR TEST W/ START NEXT Menu W/ LONG CANCEL Action F Press START. STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 248 F Since the door is usually open at this time, the sensor is blocked by the flag. Use the blue override button on the pneumatic solenoid to verify the sensor is working, by moving the door up. F Press CANCEL for the next sensor test. ASP Service Guide rev D STERRAD® 100 Sterilizer...
  • Page 249 NEXT SENSOR W/ CANCEL Action F Use a cassette to block the cassette sensor. A beep occurs when sensor is blocked. Remove cassette. Display CASSETTE SENSOR BLOCKED NEXT SENSOR W/ CANCEL B-10 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 250 F Replace the digital I/O board. Display with collection box removed. TURN BOX SWITCH ON NEXT SENSOR W/ CANCEL or with collection box in place. BOX SWITCH ON NEXT SENSOR W/ CANCEL ASP Service Guide rev D STERRAD® 100 Sterilizer B-11...
  • Page 251 F Adjust the vacuum switch. SMC Vacuum Switch Test 4 4 Note: This test is for Block 2.0 systems only. Display TEST SMC VAC SWITCH W/ START OR NEXT W/ CANCEL B-12 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 252 F Press RESET on the vacuum switch for 2 seconds. F Replace the vacuum switch. F Replace the wiring. ASP Service Guide rev D STERRAD® 100 Sterilizer B-13...

  • Page 253: Injection And Pneumatics Tests

    NEXT OUTPUT W/ CANCEL Action F Press START. Verify that the pawl has lifted. F Insert a cassette and verify that the pawl clears the cassette by 0.2 mm minimum (.008). Remove the cassette. B-14 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 254 ON/OFF MOTOR IN W/ START NEXT OUTPUT W/ CANCEL Action F Observe the cassette as it travels through the pump. F Observe floating guide gap. It should be within specifications. F Press START. ASP Service Guide rev D STERRAD® 100 Sterilizer B-15...
  • Page 255 F The cassette travels backward through the injector pump and the cassette door swings open. F Press START or CANCEL. Display STOP MOTOR W/ START NEXT OUTPUT W/ CANCEL Action Press CANCEL. B-16 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 256 4. Turn the injector valve mounting screws to raise the valve until no gap exists between seal block and tool or between the needle seal retainer plate and tool. 5. Remove the cassette gap tool. ASP Service Guide rev D STERRAD® 100 Sterilizer B-17...
  • Page 257 F Replace wire harness. F Replace solid state relay board. F Replace current sensor if no beep tone sounds. F Verify correct heater impedance. F Replace injector valve. F Check connection at injector pump. B-18 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 258 F Verify that the door is sealed. F Verify that door meets chamber door stop. F Check that door actuator arms are extended but not over center. F Check that guide cables are tensioned. ASP Service Guide rev D STERRAD® 100 Sterilizer B-19...
  • Page 259 F Make adjustments to stops and guide cables as necessary. F Replace door solenoid F Replace pneumatics board. Display CLOSE CHAMBER DOOR W/ START OR NEXT W/ CANCEL Action Press CANCEL. B-20 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 260 F Verify cassette door closes completely. F Check that voltage at P43 is 0 VDC. Corrective Action Replace injector pump board. Display OPEN CASSETTE DOOR W/ START OR NEXT W/ CANCEL Action Press CANCEL. ASP Service Guide rev D STERRAD® 100 Sterilizer B-21...

  • Page 261: Throttle Valve/Heater Menus

    Display 4 4 Note: Winding tests are normally not performed. They are presented here for information only. ON/OFF WINDING W/ START NEXT OUTPUT W/ CANCEL Action Press CANCEL for next output. B-22 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 262 F LED on throttle valve controller board is green in the open position, and red in the closed position. F Press START to stop cycling. F Press CANCEL. Corrective Action Replace throttle valve assembly. ASP Service Guide rev D STERRAD® 100 Sterilizer B-23...
  • Page 263 HEAT OFF W/ START AXXX.XV NEXT OUTPUT W/ CANCEL Action F Press START. F Verify voltage at P115 in the chamber reads 1 VAC. There is only one connector on Block 2.)· B-24 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 264 Oil Return Valve Tests Display 4 4 Note: The following test is for Block 2 and all STERRAD 100 S machines. On Block 2 there is a 120 VAC on the connector. On Block 1.8 (with STERRAD 100 S software) there is a 12 VDC connector.
  • Page 265 4 4 Note: This signal can only be measured if the machine is equipped with the harness or tool for the cassette feeder or if the machine is a Block 2 system. Display CASSETTE SW ON W/ START NEXT OUTPUT W/ CANCEL B-26 STERRAD® 100 Sterilizer ASP Service Guide rev D...

  • Page 266: Door Test

    CLOSE THE DOOR W/ START or EXIT DOORTST, LONG CLOSE Action F With the door open, place a protective block on the door shelf to protect from scratches and press START. ASP Service Guide rev D STERRAD® 100 Sterilizer B-27...
  • Page 267 F Press START. F When the door opens the LCD displays: CHECK BOTTOM SENSOR IS NOT BLOCKED Verify that the bottom sensor is not blocked. Corrective Action Adjust flag or replace bottom sensor. B-28 STERRAD® 100 Sterilizer ASP Service Guide rev D...

  • Page 268: Analog Test

    Action Press START. Display CHAN #0 CHAMBER PRESSURE CONTINUE W/ START Action Press START. Display 4.095 V. PRESSURE INPUT NEXT INPUT W/ CANCEL Action F Initial reading is a reference reading. ASP Service Guide rev D STERRAD® 100 Sterilizer B-29...
  • Page 269 CONTINUE W/ START Display 0.589 V., DEL. POWER NEXT INPUT W/ CANCEL Display CHAN #3 FLOATING INPUT CONTINUE W/ START Action Press START. Display 4.095V., FLOATING POINT NEXT INPUT W/ CANCEL B-30 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 270 CHAN #5 DOOR TEMPERATURE CONTINUE W/ START Display #.### V. DOOR TEMP. NEXT INPUT W/ CANCEL Display CHAN #6 CHAMBER TEMP CONTINUE W/ START Display #.### V. CHAMBER TEMP. NEXT INPUT W/ CANCEL ASP Service Guide rev D STERRAD® 100 Sterilizer B-31...
  • Page 271 EXIT ANALOG INPUT WITH LONG CLOSE Action Press a LONG CLOSE. Display ANALOG W/ START NEXT Menu W/ LONG CANCEL Action F To restart test, press START, otherwise press a LONG CANCEL. B-32 STERRAD® 100 Sterilizer ASP Service Guide rev D...

  • Page 272: Vacuum Subsystem Tests

    F Press motor starter override to start pump. F Check the wiring. F Replace the solid state relay board. F Replace the motor starter. Display PUMP IS ON NEXT W/ LONG CANCEL Action Press a LONG CANCEL. ASP Service Guide rev D STERRAD® 100 Sterilizer B-33...
  • Page 273 Corrective Action Realign door. Display DOOR CLOSE, NEXT VENT NEXT W/ LONG CANCEL Action Press a LONG CANCEL. Display CLOSE VENT W/ START Action F Press START. F Verify vent is closed. B-34 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 274 F Observe the pressure reading on the control panel, it should increase rapidly. Release the button when the pressure reading stops increasing. F After 500 mTorr is reached and is stable, press a LONG CANCEL for the next menu. ASP Service Guide rev D STERRAD® 100 Sterilizer B-35...
  • Page 275 F Verify operation of RF by observing RF power measurement using the Bird Watt meter. Observe for 15 minutes. F Clean the electrode, RF feedthrough and chamber using deionized water and a Scotch Brite-type scrub pad. B-36 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 276 F Replace the electrode if necessary. F Replace the RF delivery system if plasma is not induced or RF power failure. Leak Back Test Display LEAKTEST W/ START NEXT W/ LONG CANCEL Action Press START once. ASP Service Guide rev D STERRAD® 100 Sterilizer B-37...
  • Page 277 Display EXIT VAC-RF W/ START NEXT W/ LONG CANCEL Action Press START. Display DOOR WILL OPEN AT 730 T NEXT W/ LONG CANCEL B-38 STERRAD® 100 Sterilizer ASP Service Guide rev D...

  • Page 278: Cassette Adjustments

    If a repair cannot be made, it may be necessary to replace one or more of the system assemblies. Cassette Adjustments Display CASSETTE ADJ W/ START or NEXT Menu W/ LONG CANCEL Action Press START. ASP Service Guide rev D STERRAD® 100 Sterilizer B-39...
  • Page 279 1/4 turn increments until the cassette no longer cycles and is ejected to the front of the injector pump. Note the BC minWH number displayed on the LCD. B-40 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 280 NEXT Menu W/ LONG CANCEL Action Press a LONG CANCEL. 4 4 Note: The following test is not performed at this time. Display SLOT ADJ. W/ START NEXT Menu W/ LONG CANCEL ASP Service Guide rev D STERRAD® 100 Sterilizer B-41...

  • Page 281: Printer Test

    Corrective Action F Check printer cables. F Replace ribbon. F Replace printer. Display RESTART W/ START EXIT W/ LONG CLOSE Action To go to beginning of main menu, press a LONG CLOSE. B-42 STERRAD® 100 Sterilizer ASP Service Guide rev D...
  • Page 282 ® STERRAD 100 Schematics The schematics listed below pertain to both Block 1.8 and Block 2 unless otherwise stated. If there is more than one schematic, both are shown. Click on the schematic name to jump to that schematic. Or, click on the third button from the left on the tool bar above.
  • Page 283 • • Stepper motor driver PCB 10-01090-100-F • • Throttle valve PCB 10-01707-0-100-B • • Connector distribution 10-01766-2-100-B Block 2 • • Configuration PCB 208 VAC 10-02195-0-101 Block 2 • • Configuration PCB 380 VAC 10-02195-0-102 Block 2 • • Configuration PCB 398 VAC 10-02195-0-103 Block 2 •...
