- Page 1 SignWave 14” Door Card Installation Guide Version 1.4 January 2016...
- Page 2 Step 1: Determine the Installation Location ..........3 STEP 2: Run the Signal & Power Cables to the Display Location ....4 STEP 3: Installing the Wall Mount Plate ............. 5 STEP 4: Installing the SignWave Display Device .......... 6 Frame Maintenance .................. 6 Specifications ..................... 7 Copyright ©...
- Page 3 NSTALLATION UIDE STEP 1: DETERMINE THE INSTALLATION LOCATION A . If the SignWave display device is to be installed in a public area for public use, please review all information on www.ada.gov for touch screen and tactile sign compliance requirements.
- Page 4 NSTALLATION UIDE STEP 2: RUN THE SIGNAL & POWER CABLES TO THE DISPLAY LOCATION A. SignWave display devices include built-in Power-over-Ethernet (PoE) handling. Network connectivity and power can be delivered to the display over one Ethernet cable (Cat-5e cable standard or better).
- Page 5 UIDE STEP 3: INSTALLING THE WALL MOUNT PLATE A. If installing the SignWave display device on hollow drywall, then insert screw anchors at each of the four countersink mounting screw locations marked in the diagram below. B. Ensure the signal cable(s) are routed through the access port and install the wall mount using flat head (counter-sink ready) screws applicable for anchors used in previous step.
- Page 6 B. The SignWave display device in wall mount configuration has two keyholes in the back plate. Align the keyholes with the barrel buttons protruding from the wall mount. Then, align the bottom of the display so the left and right edge uprights on the wall mount slide into the display evenly as the display is slid down over the barrel buttons and the wall mount uprights.
- Page 7 Width: 13.8125" (13-13/16") Height: 9.375" (9-3/8") Depth: 1.5" (1-1/2") Operating Temperature Range: 23F to 104F SignWave 14” Door Card Connections Copyright © 2015 Keywest Technology, Inc. All Rights Reserved 14563 W 96th Terrace • Lenexa KS 66215 USA • Need Support? Mailto:Support@keywesttechnology.com...
- Page 8 14” D NSTALLATION UIDE SPECIFICATIONS SignWave 14” Door Card Wall Mount Copyright © 2015 Keywest Technology, Inc. All Rights Reserved 14563 W 96th Terrace • Lenexa KS 66215 USA • Need Support? Mailto:Support@keywesttechnology.com...
