Safe Fleet DH6 Quick Installation Manual

Service & Support
If your POE device is to be returned for service, please contact the Safe Fleet technical support team, provide
the part and/or serial # of your unit, and ask for a Return Merchandise Authorization (RMA) number. An RMA
# allows the support team to better track your product when it comes in for service. Please show the RMA #
on the outside of the package.
ANY PRODUCT SENT WITHOUT AN RMA # MAY BE REFUSED!
Documentation and Warranty
Information is subject to change without notice. For the latest product details, please visit the Safe Fleet
Community. Additional copies of this guide along with other documentation and product warranty can also be
found on the Safe Fleet Community.
Safe Fleet Community Web site: https://community.safefleet.net
Technical Support
Phone: 1.844.899.7366 Email: PTsupport@safefleet.net
2002/96/EC (WEEE directive): This product cannot be disposed of as unsorted municipal waste
in the European Union. For proper recycling, return the product to your local supplier upon the
purchase of equivalent new equipment, or dispose of it at designated collection points, for more
information, see www.recyclethis.info.
2006/66/EC (battery directive): This product does not contain batteries.
DH6/DH8 48V POE Injector Kit
About
This guide covers installation procedures for connecting a POE (Power Over Ethernet) injector kit to a DH6 or
DH8 recorder.
A POE injector kit enables connection of a single IP camera to the recorder's rear-panel LAN2 port.
Pre-requisites
Before proceeding, you must have a DH6 or DH8 recorder installed and functioning in a vehicle. Do not
proceed with this document if you haven't installed the recorder. The DH6/DH8 installation documentation is
available on the Safe Fleet Community (https://community.safefleet.net).
Note: You will need login credentials to access the documentation. Please contact Safe Fleet Technical
Support if you do not have access to the Community.
Kit Contents
48 V POE Injector Kit (Part # DH-POEKIT48-A):
• POE Injector (Part #: 085-1106) - Qty 1
• POE Adapter Cable (Part #: APPINJ) - Qty 1
• F/F Inline Coupler (Part #: 444-1028) - Qty 1
Specifications
48 V POE Injector
Input 12VDC/1.5A to 16VDC/1.1A.
Output 48 VDC, up to 15.4 W max. IEEE 802.3af compliant. Short circuit protection.
Ethernet Connectivity: RJ45, auto-crossover. Wire type: 4-pair CAT5e.
Distance: up to 100 m. Speed: 10/100BaseT, half/full duplex, auto negotiation.
Indicators (LED) Red LED: Port status.
Yellow & Green LED (by RJ45 jack): IP Link status, 10/100Base-T/active.
Agency Listings UL/cUL: UL60950-1 (Information Technology Equipment).
CE European Conformity.
Dimensions (W x L x H) 2.5" x 3.8" x 1" (63.5 mm x 96.52 mm x 25.4 mm).
Weight (approx.) Product Weight: 0.2 lbs. (0.1 kg). Shipping Weight: 0.25 lbs. (0.11 kg).
Temperature Operating: 0º C to 40º C (32º F to 104º F).
Storage: -40º C to 70º C (-40º to 158º F).
Relative Humidity 85% +/-5%.
Operating Altitude: -304.8 to 3,048 m (-1000 to 10,000 ft.).
© Safe Fleet | All rights reserved
Quick Installation Guide
• 1.5 ft CAT5e Cable (Part #: 085-0065) - Qty 2
• 1" Stainless Steel Philips Rounded Head Drilling
Screw (Part #: 600-1022) - Qty 1
2022 | Part #: 700-1279 R2
