• Please read, understand and follow the directions in the DM9 owner’s manual. • Always fit a barrel blocking device to your DM9 when not in use on the field of play. • Eye protection that is designed specifically for paintball and meets ASTM/CE standards must be worn by user and persons within range.
Hyper3™ in-line regulator at a regulated pressure of no more than 850 psi. The Hyper3™ in-line HOPPER regulator comes factory preset at 145psi. To get the best performance out of your DM9, it is recommended that you use a motorized loader. Preferably one that force feeds the paint really fast. GASSING UP YOUR DM9...
Page 5
To turn the eyes back on, hold the lower button until the LED turns either red or green. FIRING THE DM9 NOTE: With the eye off the DM9 will shoot the rate of fire value set in Configuration Mode. As soon as the marker is turned on and the LED’s turn from blue to either red or green, the DM9 is ready to fire.
Page 6
• When you reach the setting where the marker begins to fire, get some paint and a loader and go to a chronograph. • The DM9 is not water resistant. Excess moisture can cause damage to electronic parts. • Keep the board and all electrical components clean of dirt, paint and moisture.
Page 7
Values 1 - 34 (factory default 13.33 bps) TO CHANGE A VALUE OF A SETTING The ROF setting is used to set the maximum rate of fire of the DM9. 1. While in the configuration mode, choose the color you wish to change by pulling the trigger.
As you turn the knob • Finally, turn out the back frame screw and slide the frame back and down until it comes off the DM9. out, the residual gas between the Hyper3™ and the To connect the frame follow above steps in reverse order.
FIGURE 1 FIGURE 2 The trigger’s forward and over travel, spring tension, and The DM9 has a new external reach adjustment for reach are fully adjustable so that you can fine-tune the the Ultralite trigger. trigger to your exact liking. You do not need to remove...
• Make sure there are no paintballs in the breech of the DM9. • Always remove the air supply and relieve all gas pressure in the DM9 before When the DM9 is aired up, air is transferred by the solenoid to the front of the cylinder. This air disassembly.
Page 11
If you do not grease the bolt, you will run the risk of damaging O-rings. This will create excessive friction and drag on the bolt, ultimately resulting in breaking the bolt. When greasing the DM9 Fuse™ bolt, pay special attention to all O-rings that are on the bolt and that ride on a surface of the bolt.
Page 12
• Make sure your hopper is removed from the DM9. • Make sure there are no paintballs in the breech of the DM9. • Always remove the air supply and relieve all gas pressure in the DM9 before disassembly. • It is not recommended for the user to remove the LPR from the body...
Page 13
” Allen wrench. is consistent. 4 Pull out the LPR, making sure that the piston is not left in the DM9 body. 5 Insert a new LPR Assembly. 6 Tighten LPR screw lightly, being sure to align it with the keyway cut on the LPR body.
Page 14
Always discharge the marker in a safe direction to relieve this residual gas pressure. every 6 months or 60,000 shots. Shooting the DM9 a few times between each small adjustment to • Always remove the regulator from the DM9 before servicing.
Normally it is enough to just fire the DM9 to clean anything blocking the eyes. If this does not clear the blockage use a swab to Be careful not to over-flex the clean the inside of the breech.
• Both of these problems are caused because the • Change the #011 O-ring on the top cap of the the DM9. If the bolt kit is loose, it will start to leak. button(s) are being held down. Remove the board Hyper3™...
Page 17
• Check that the LPR pressure is not set too low. should be changed as soon as possible. is too much friction in the bolt it will cause the DM9 See page 23 for instructions on how to set your •...
Warranty card and proof of purchase 5 DM9 Body must be submitted to DYE Precision for warranty to be in effect. This warranty is not transferable. This warranty does not cover performance. Paintball markers are non- 6 FUSE™...
