Hatco Atmospheric AWD-12 Specifications

At the simple push of a button, the
Hatco Atmospheric Water Dispenser
delivers pre-measured quantities of hot
water for food preparation or cleaning.
FLEXIBILITY
The Atmospheric Hot Water Dispenser
quickly provides 2, 3, or 4 quarts
(1.9, 2.8, or 3.8 liters) of hot water,
up to 200°F (93°C), for fast, easy food
preparation like hot beverages, sauces,
soups, gravy, hot cereals, rice, pasta,
potatoes, gelatins, and other applications.
The program can be interrupted for
versatility and convenience. A manual
dispense button permits additional water
volume options. The 12-gallon (45 liter)
stainless steel tank provides up to
8 gallons (30 liters) of continuous hot
water and the removable stainless steel
shelf allows access to dispense water
into large containers.
Compact and durable, this dispenser
requires minimal counter space. The
tank can be emptied easily with
convenient bottom drain.
QUALITY
The following features assure the finest
performance for years to come:
• Quickly delivers 2, 3, or 4 quarts
(1.9, 2.8, or 3.8 liters) of hot water
with touch of a button for fast, easy
food preparation.
• Program can be interrupted for
versatility and convenience.
• Manual dispense button permits
additional water volume options.
• Compact and durable unit requires
minimal counter space.
• 12-gallon (45 liter) stainless steel tank
provides up to 8 gallons (30 liters) of
continuous hot water.
• Removable shelf allows access to
dispense water into large containers.
• Tank is emptied easily with convenient
bottom drain.
• Setpoint temperature can be adjusted
from 75°F up to 200°F (24°-93°C),
with the factory default setting at
195°F (91°C).
ATMOSPHERIC
Model AWD-12
WATER QUALITY REQUIREMENTS
Incoming water in excess of 3.0 grains of hardness per gallon (GPG) (.75 grains of
hardness per liter) must be treated and softened before being supplied to booster
heater(s). Water containing over 3.0 GPG (.75 GPL) will decrease the efficiency
and reduce the operating life of the unit.
Note: Product failure caused by liming or sediment buildup is not covered
ANSI/NSF 4
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A.
(800) 558-0607 • (414) 671-6350 • Fax (800) 543-7521 • Int'l. Fax (414) 671-3976
www.hatcocorp.com • E-mail: equipsales@hatcocorp.com
Form No. AWD-1006(S)
ITEM#
HOT WATER DISPENSER
under warranty.
Model AWD-12
Printed in U.S.A.
