SOLAR ROYAL SR1800 SERIES QUICK INSTALL GUIDE
ank you for purchasing a Solar Royal SR1800.
installation guide at manual.solarroyal.com. Please make sure to register your product, as this is necessary for activating your
warranty. Once again, it is crucial that the end user registers the products installed within ninety days or your product will not be
warranty. Once again, it is crucial that the end user registers the products installed within ninety days or your product will not be
covered by our warranty. You may register with the enclosed form or online at reg.solarroyal.com.
covered by our warranty. You may register with the enclosed form or online at reg.solarroyal.com.
Prior to the Installation:
Tools Required:
• Safety Goggles
• Measuring Tape
• Marking Pencil
• Utility Knife
• Screws (Provided)
• Caulk (MP1 or similar)
• Caulk (MP1 or similar)
REVIEW INSTALLATION OVERVIEW:
REVIEW INSTALLATION OVERVIEW:
https://www.youtube.com/user/solarroyal
Installing an attic fan is fairly easy but Solar Royal, LLC recommends that if you have
Installing an attic fan is fairly easy but Solar Royal, LLC recommends that if you have
no experience working with these materials or are not familiar with working on a
no experience working with these materials or are not familiar with working on a
roof, you should hire an insured and bonded professional to install anything on your
roof, you should hire an insured and bonded professional to install anything on your
roof, including a solar attic fan.
Step 1: Measure and Cut the Hole
On either 24" or 16" center construction, we recommend cutting a 15" round hole between the raft ers. We recommend installing
the SR1800 between the raft ers but if not possible it is OK to install the SR1800 over a raft er.
Measuring the hole
Step 2: Insert the Flashing
Once the hole as been made, trim away shingles as needed to accommodate the metal base ashing so that you have a clean and
tight fi t. Normally, if you cut a clean 15" hole, we recommend trimming away from the top rows of shingles an additional 1" (one
inch) to allow the base fl ashing to slip under the top row(s) of shingles and over the bottom row(s). Slip the fl at metal base under
the top rows of shingles and center the unit over the opening.
Before attempting to slide in the fl ashing, remove any roofi ng nails or other obstructions. Avoid scratching the powder-coating.
Removing
obstructions
e following is a quick guide to installing your attic fan. You may nd the full
• Stud Finder
• Drill w/Phillips Bit
• Flat Pry Bar
• Caulk Gun
• Reciprocating Saw
• String and 2 Nails (Recommended)
• String and 2 Nails (Recommended)
e hole cut out
e base is square so it does not matter which side is installed rst.
Flashing a er
sliding in
