Installation and Operations Manual
Single Packaged Heat Pump
13.4 SEER2 Convertible, 2 — 5 Ton
4WCC4024E1000A
4WCC4030E1000A
4WCC4036E1000A
4WCC4042E1000A
4WCC4048E1000A
4WCC4060E1000A
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning
equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person
could result in death or serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that
are attached to the equipment.
February 2022
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
1 1 8 8 - - B B B B 4 4 1 1 D D 1 1 - - 1 1 A A - - E E N N
N N o o t t e e : : "Graphics in this document are for representation
only. Actual model may differ in appearance."
N N o o t t e e : : "Unit specific Service Facts available online."
