Summary of Contents for triOS Dissolved Oxygen
- Page 1 Dissolved Oxygen OPERATING INSTRUCTIONS...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents 1 General Information 5.3 Measurement Properties 1.1 Introduction 5.3.1 Influences on the measurement 1.2 Health and Safety Information 5.3.2 Temperature Compensation 1.3 Warnings 5.3.3 Atmospheric pressure 1.4 Users and Operating Requirements 5.3.4 Salinity 1.5 Intended Use 6 Malfunction and Maintenance 1.6 Disposal Information 6.1 Cleaning and Upkeep... -
Page 4: General Information
The “smart” Oxygen sensor stores calibration and history data within the sensor. This allows you a “plug and play” system without re-calibration. In this manual, you will find all of the information you will need to commission the Dissolved Oxygen sensor. Technical specifi- cations, detection limits and dimensions can be found in chapter 7. -
Page 5: Health And Safety Information
Devices that radiate strong electromagnetic waves can influence the measurement data or result in a malfunction of the sen- sor. Avoid using the following devices in the same room as the TriOS sensor: mobile phones, cordless phones, transmitters/ receivers and other electrical devices that produce electromagnetic waves. -
Page 6: Warnings
Make sure that the cord is not placed near hot surfaces. • If the sensor cord is damaged, it must be replaced with an original part by the customer service of TriOS Mess- und Datentechnik GmbH or by an authorized TriOS workshop. -
Page 7: Disposal Information
• Drinking water monitoring The use of other media can damage the sensor. For the use of the Dissolved Oxygen sensor in media other than those specified this manual, please contact the customer service of TriOS Mess- und Datentechnik GmbH (support@trios.de). -
Page 8: Introduction
Modbus RTU TriOS eCHEM Serie 903-17-A7135 In addition to the product bar code, the rating plate includes the TriOS Mess- und Datentechnik GmbH logo and the quality label. Please note that the specifications given here are for illustration purposes only and may be different depending on the version of the product. -
Page 9: Scope Of Delivery
The shipment contains the following components: Sensor Operating Instructions Accessories (if applicable) Keep the original packaging in case the device needs to be returned for maintenance or repairs. 2.3 Measurement Principle and Design Stainless steel membrane Cable bushing Membrane cap seal D01-903en201912 Manual Dissolved Oxygen... -
Page 10: Commissioning
A line is put on the B line. The A-B difference is decisive where the transmission is most resistant to interactive interference signals. The used protocol is Modbus RTU. A detailed description of the Modbus protocol commands can be found in the Annex. D01-903en201912 Manual Dissolved Oxygen... -
Page 11: Use
Dissolved Oxygen 4 Use The Dissolved Oxygen sensor can be operated with any of the TriOS controllers. Instructions for correct installation can be found in the controller manual. 4.1 Normal Operation Once the sensor is connected to your Controller, the sensor is settled in its accessory of assembly and the parameterization has been carried out on the display unit, the sensor is ready for initial startup. -
Page 12: Support Tube Installation
4.3 Support Tube Installation PF-ACC-C-00271 FOR C4E/NTU SENSOR (1550 mm, RING SHUTTER) TriOS provides two adapter pieces for installing the TpH-D sensor in existing tube systems: • NPT1 adapter ZM12 ( incl. cap nut ZM13) Long pole The long poles are available in elbow version, for installations in aeration basin, and straight, for •... - Page 13 Dissolved Oxygen 2. Pull the complete cable through. 3. Fix the sensor with the mounting cap. 4. The sensor and adapter can now be installed in the support tube. D01-903en201912 Manual Dissolved Oxygen...
-
Page 14: Calibration
The sensor must be kept dry during the calibration process. Drops of water adhering to the sensor mem- brane could distort the measurement. By positioning the sensor in air-saturated water (air is directed through water until the water is saturated with it). The air pressure and temperature must remain constant during the calibration. D01-903en201912 Manual Dissolved Oxygen... -
Page 15: One-Point Calibration
The default value of the atmosphere used for the compensation is 1013 hPa. 5.3.4 Salinity The value for the salinity of the measurement medium could be transmitted to the sensor by your terminal. The default value of the salinity used for the compensation is 0 g/Kg. D01-903en201912 Manual Dissolved Oxygen... -
Page 16: Malfunction And Maintenance
If the zero point is moved, a complete two-point calibration must be carried out. NOTICE Avoid touching the membrane, because it can become scratched or dirty. If this happens, the func- tionality of the device can no longer be guaranteed. D01-903en201912 Manual Dissolved Oxygen... -
Page 17: Changing The Membrane Cap
Please make sure that the sensor is cleaned and disinfected before shipping. In order to ship the goods undamaged, use the original packaging. If this is not on hand, make sure that safe transport is guaranteed and the sensor is safely packed using enough packing material. D01-903en201912 Manual Dissolved Oxygen... -
Page 18: Technical Data
~ 450 g ~ 1 lbs Weight titanium ~ 300 g ~ 0.7 lbs Interface RS-485 (Modbus RTU) Power consumption Power supply 12 V (± 10 %) Sensor cable 2 m and 10 m D01-903en201912 Manual Dissolved Oxygen... -
Page 19: External Dimensions
~ +32 °F... +122 °F Ambient temperature 0...+50 °C ~ +32 °F... +122 °F Storage temperature -10...+60 °C ~ +14 °F... +140 °F 7.2 External Dimensions All dimensions are indicated in mm. Polyamid gland Sensor body Membrane Cap D01-903en201912 Manual Dissolved Oxygen... -
Page 20: Accessories
Digital, 4-channel display and control unit with integrated solenoid valve for compressed-air con- trol TriBox3 is a measurement and control system for all TriOS sen- sors. The device has 4 sensor channels with selectable RS-232 or RS-485 function. In addition to the Modbus RTU, various other protocols are available. -
Page 21: Warranty
Damage due to improper handling and use of the device is not covered by the warranty. • Damage resulting from modification or unprofessional attachment of accessories by the customer is not covered by the warranty. NOTICE Opening the sensor voids the warranty! D01-903en201912 Manual Dissolved Oxygen... -
Page 22: Customer Service
Contact Dissolved Oxygen 10 Customer Service If you are having a problem with the sensor, please contact TriOS customer service. To send back the sensor, please request an RMA number from customer service. Technical support contacts: support@trios.de Telephone: +49 (0) 4402 69670 - 0 Fax: +49 (0) 4402 69670 –... -
Page 23: Contact
If you have found an error or bug in one of the devices or programs, please let us know: Customer service: support@trios.de General questions/sales: sales@trios.de Website: www.trios.de TriOS Mess- und Datentechnik GmbH Bürgermeister-Brötje-Str. 25 26180 Rastede Germany Telephone +49 (0) 4402 69670 - 0 +49 (0) 4402 69670 - 20... -
Page 24: Keyword Index
Biological safety Bypass installation Calibration CE certification Certificates & approvals M12 industrial plug Cleaning Maintenance Contact Measurement properties Copyright Membrane Cap Customer service Normal operation Disposal Offset Calibration Electrical installation One-Point Calibration Electromagnetic waves Operating requirements FlowCell D01-903en201912 Manual Dissolved Oxygen... - Page 25 Dissolved Oxygen User requirements Product Identification Warnings Rating plate Warranty Reagents Waste Returns RMA number Safety instructions Salinity Scope of delivery Slope Calibration Specifications Structure of the sensor Support Tube Installation Technical Specifications Temperature Compensation Two-Point Calibration D01-903en201912 Manual Dissolved Oxygen...
-
Page 26: Annex
Bürgermeister-Brötje-Str. 25 D- 26180 Rastede Konformitätserklärung Declaration of Conformity Déclaration de Conformité Die TriOS GmbH bescheinigt die Konformität für das Produkt The TriOS GmbH herewith declares conformity of the product TriOS GmbH déclare la conformité du produit Bezeichnung eCHEM Sauerstoff... - Page 27 Read the serial number, firmware version and of course measurement Read multiple registers 0x03 data Write single register 0x06 Write a value in one register Write multiple registers 0x10 Write data into a sequence of registers Report slave ID 0x11 Get the sensor identification D01-903en201912 Manual Dissolved Oxygen...
- Page 28 Current temperature measurement in °C Oxygen saturation Float Measured oxygen saturation in % Dissolved oxygen Float The concentration of dissolved oxygen in mg/l Dissolved oxygen Float The concentration of dissolved oxygen in ppm Modbus slave address Int16 Modbus slave address from 1 to 247...
- Page 29 All three corrections are activated 00 00 00 00 01 10 00 00 0x0060 Salinity and pressure activated, temperature internal 0x0040 00 00 00 00 01 00 00 00 Salinity activated, pressure deactivated and temperature internal D01-903en201912 Manual Dissolved Oxygen...
- Page 30 5 (10 Min) minutes trigger measurement and remove sensor from water, read results, write target trigger measurements and value read results, write target value set bit 3 set bit 6 calibration values alright? save calibration D01-903en201912 Manual Dissolved Oxygen...
- Page 31 Then take the sensor out, hold it in air and continuously perform measurements by writing the value 31 into register 1and waiting for about 2 seconds until reading the measurements. Trigger frame measurement: 0A 06 00 01 00 1F 98 89 Read frame result: 0A 03 00 53 00 08 B5 66 D01-903en201912 Manual Dissolved Oxygen...
- Page 32 Finally you have to switch back to the saved coefficients. To do so, write the value 0 into register 332 and 333. Frame: 0A 10 01 4C 00 02 04 00 00 00 00 DF 7E D01-903en201912 Manual Dissolved Oxygen...
