  • Page 1 OPERATING INSTRUCTIONS...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS nanoFlu Chapter Table of Contents 1 General Information 6 Malfunction and Maintenance 1.1 Introduction 6.1 Cleaning and Upkeep 1.2 Health and Safety Information 6.1.1 Cleaning the Housing 1.3 Warnings 6.1.2 Cleaning the Measuring Window 1.4 Users and Operating Requirements 6.1.3 Preparing the Sensor for the Function Test...

  • Page 4: General Information

    In this manual, you will find all the information you will need to commission the nanoFlu. Technical specifications as well as detection limits and the dimensions can be found in chapter 7.

  • Page 5: Health And Safety Information

    Devices that radiate strong electromagnetic waves can influence the measurement data or result in a malfunc- tion of the sensor. Avoid using the following devices in the same room as the TriOS sensor: mobile phones, cordless phones, transmitters/ receivers and other electrical devices that produce electromagnetic waves.

  • Page 6: Warnings

    Make sure that the cord is not run near hot surfaces. • If the sensor cord is damaged, it must be replaced with an original part by the customer service of TriOS Mess- und Datentechnik GmbH or by an authorized TriOS technician.

  • Page 7: Disposal Information

    The use of other media can damage the sensor. For the use of the nanoFlu in other media than those specified in this manual, please contact the customer service of TriOS Mess- und Datentechnik GmbH (support@trios.de).

  • Page 8: Introduction

    Product type Power supply Interface In addition to the product bar code, the rating plate includes the TriOS Mess- und Datentechnik GmbH logo and the quality label. Please note that the specifications given here are for illustration purposes only and may deviate depending on the version of the product.

  • Page 9: Measurement Principle And Design

    Filter Lens Photodiode Essentially, the nanoFlu consists of four parts: a defined light source, a lens system, the optical path and a detector with ambient light suppression. The arrangement of these parts is represented schematically in the above illustration. The light source consists of an LED with a defined wavelength depending on the version or parameter.

  • Page 10: Fluorescence

    2.4 Browser nanoFlu is equipped with a web interface, which can be used to configure the sensor. To access the web inter- face, you will need the G2 interface box and an Ethernet-capable device with a web browser, e.g. a notebook.
  • Page 11 In the menu on the left, the subpoints are listed. There is a “Help” link on the right side that will take you to the TriOS Mess- und Datentechnik GmbH website. An active Internet connection is required to access the website.
  • Page 12 On this page, it is also possible to scale the measured value with the help of entries for “Offset” and “Scaling”. The new measurement can be triggered at any time. To do this, click on the “Measure Now!” button. A new measurement will then be carried out with the saved settings. D01-060en202008 Manual nanoFlu...
  • Page 13 If the previous measurement has not yet been completed after the interval has elapsed (e.g. because the nanoFlu simply needs more time to calculate the average), this previous measure- ment will be waited out before the next one is started.

  • Page 14: Commissioning

    3. RS232 TX / RS485 B (data) 4. Power (12...24 VDC) 5. ETH_RX- 6. ETH_TX- 7. ETH_RX+ 8. ETH_TX+ Connect the male end of the connecting cable into the connector by making the pins align with the slots of the cable. D01-060en202008 Manual nanoFlu...

  • Page 15: Fixed Cable With M12 Industrial Plug

    2. RS232 TX / RS485 B (data) 3. ETH_RX- 4. ETH_RX+ 5. ETH_TX- 6. ETH_TX+ 7. Ground (Power + Ser. Interface) 8. Power (12...24 VDC) Ensure correct polarity of the operating voltage, because otherwise the sensor NOTICE may be damaged. D01-060en202008 Manual nanoFlu...

  • Page 16: Interfaces

    3.2 Interfaces 3.2.1 Serial Interface The nanoFlu provides two lines for digital, serial communication with a control device. It is equipped with a configurable digital serial interface as RS-232 (also EIA 232) or RS-485 (also EIA 485). The interface cannot be switched and is already defined when delivered.

  • Page 17: Network

    Network with a single G2 sensor The easiest way to connect to the nanoFlu is with the G2 interface box. It serves as both the connection and the power supply for the sensor and can be used with all TriOS G2 sensors.
  • Page 18 URL options. Automatic measurement by the nanoFlu is stopped when an Ethernet-capable device is connected. As soon as the LAN connection between the sensor and the Internet capable device is disconnected, the measurements will be continued at the set interval if the timer is activated.
  • Page 19 Like any G2 sensor, the nanoFlu delivers a simple DHCP server as well as a simple DNS server, which is con- figured exclusively for direct connection, as described in the previous section. For a complex sensor network, the servers must be supplied by the user.

  • Page 20: Use

    4 Use The nanoFlu can be operated with all TriOS controllers. Instructions for correct installation can be found in the controller manual. 4.1 Normal Operation 4.1.1 Immersion Operation For immersion operation, the nanoFlu can be completely or partially immersed in the water / measuring me- dium.

  • Page 21: Flowcell / Bypass

    4.1.3 FlowCell / Bypass With the optional flow cell, the nanoFlu can be installed as a bypass. For this purpose you need the nanoFlu FlowCell (Art.No.: 10A090000) and a nanoFlu with a special housing, which was especially designed for the operation in the FlowCell (Art.No.: 32SX03X10).

  • Page 22: Calibration

    5 Calibration 5.1 Manufacturer Calibration All TriOS sensors are delivered calibrated. The calibration factors of the nanoFlu are stored in the sensor, meaning that all values that are output are calibrated values. The conversion from the original measurement parameter to the scaled measurement parameter is carried out by means of the following equations.
  • Page 23 Local calibration is adjusted by means of a linear equation. Two constants are required for this: the scaling factor and offset, which are used according to the following equation: A = parameter - offset B = A ∙ scaling With A being the parameter output, which is output by the nanoFlu. offset corrected value offset value Offset customer-calibrated parameters For local calibration, at least two data points, i.e.
  • Page 24 The offset can also be found using the abscissa of the straight line (intersection with X axis). For the above example, this means: 90 - 30 scaling factor = 40 - 20 offset = 40 - = 40 - 30 = 10 D01-060en202008 Manual nanoFlu...
  • Page 25 Measured concentration [µg/L] All TriOS controllers have the ability to set scaling factors and offset values for the measurement parameters. Please refer to the appropriate manual. Make sure not to carry out double scaling with the sensor: once in the...

  • Page 26: Malfunction And Maintenance

    6.1.2 Cleaning the Measuring Window You can clean the window with a lint-free cloth, a clean paper towel or a special optical paper from TriOS Mess- und Datentechnik GmbH with a few drops of acetone. Make sure that you do not touch the window surface...

  • Page 27: Preparing The Sensor For The Function Test And Zero Value Determination

    When using an upright meas- uring cylinder which requires the sensor to be positioned vertically, make sure to watch out for air bubbles in the optical path. Make sure the measurement container is sufficiently stable! D01-060en202008 Manual nanoFlu...

  • Page 28: Maintenance And Inspection

    The zero value of the nanoFlu is checked via the web interface. To access the web interface, you will need the G2 interface box and an Ethernet-capable device with a web browser, such as a notebook / laptop.

  • Page 29: Restore Point

    The following error messages and warnings are possible: • File not OK. The calibration file could not be read correctly. Make sure that you have selected the correct file and repeat the process. If the error persists, please contact TriOS customer support at support@ trios.de. •...

  • Page 30: Returns

    Please make sure that the sensor is cleaned and disinfected before shipping. In order to ship the goods un- damaged, use the original packaging. If this is not on hand, make sure that safe transport is guaranteed and the sensor is safely packed using enough packing material. D01-060en202008 Manual nanoFlu...

  • Page 31: Technical Data

    Subconn 30 bars Max. with fixed cable 3 bars pressure in flow cell 1 bar, 2...4 L/min Protection type IP68 Sample temperature +2...+40 °C Ambient temperature +2...+40 °C Storage temperature -20...+80 °C Inflow velocity 0.1...10 m/s D01-060en202008 Manual nanoFlu...

  • Page 32: Measurement Ranges And Detection Limits

    The following table provides an overview of the measurement ranges of various parameters and their limits of detection: Parameters Unit Measurement range Detection limit 0...200 µg/L 0,2 µg/L Chl_a µg/L 0...500 µg/L 1 µg/L 0...200 µg/L 0,3 µg/L blue µg/L 0...500 µg/L 3 µg/L CDOM µg/L 0...200 µg/L 0,3 µg/L *under laboratory conditions D01-060en202008 Manual nanoFlu...

  • Page 33: External Dimensions

    Polyoxymethylene (POM) optic optical glass screws stainless steel sealings nitrile butadine rubber (NBR) Name: nanoFlu CHL Nullersie Date: 03.07.2017 Rev.: NF011705 TriOS Mess- und Datentechnik GmbH Bgm.-Brötje-Str. 25 26180 Rastede Germany ● ● ●...

  • Page 34: Accessories

    8.2 TriBox Mini Digital 2-channel controller Mini controller with two digital sensor inputs and two 4...20mA outputs. All measured values and diagnos- tics data which are stored can be selected using an integrated web browser. D01-060en202008 Manual nanoFlu...

  • Page 35: Warranty

    Damage due to improper handling and use of the device is not covered by the warranty. • Damage resulting from modification or unprofessional attachment of accessories by the customer is not covered by the warranty. NOTICE Opening the sensor voids the warranty! D01-060en202008 Manual nanoFlu...

  • Page 36: Customer Service

    10 Customer Service If you are having a problem with the sensor, please contact the TriOS customer service. We recommend sending the sensor in for maintenance and calibration every 2 years. To do this, please request an RMA number from customer service.

  • Page 37: Contact

    If you have found an error or bug in one of our devices or programs, please let us know: Customer service: support@trios.de General questions / sales: sales@trios.de Website: www.trios.de TriOS Mess- und Datentechnik GmbH Bürgermeister-Brötje-Str. 25 D-26180 Rastede Germany Tel. +49 (0) 4402 69670 - 0 +49 (0) 4402 69670 - 20...

  • Page 38: Keyword Index

    Cleaning the housing IP address Cleaning the measuring window Contact Copyright Customer calibration Customer service Declaration of conformity M12 industrial plug Detection limit Maintenance Dimensions Manufacturer calibration Disposal Measurement principle Diving Operation Modbus Electrical installation Electromagnetic waves D01-060en202008 Manual nanoFlu...
  • Page 39 Offset Operating requirements Warnings Warranty Parameters Waste Product Identification Rating plate Reagents Zero-value check Recovery Recovery Point Returns RMA number Safety instructions Scaling factor Scope of delivery Software updates Specifications Structure of the sensor SubConn 8-pin Connector D01-060en202008 Manual nanoFlu...

  • Page 40: Annex

    Bürgermeister-Brötje-Str. 25 D- 26180 Rastede Konformitätserklärung Declaration of Conformity Déclaration de Conformité Die TriOS GmbH bescheinigt die Konformität für das Produkt The TriOS GmbH herewith declares conformity of the product TriOS GmbH déclare la conformité du produit Bezeichnung nanoFlu Product name...
  • Page 41 Annex Modbus RTU Serial Interface When delivered, the nanoFlu has the following settings for the serial interface (RS232 or RS485): • Baud rate: 9600 bps • Data bits: 8 • Stop bits: 1 • Parity: none Data types Name...
  • Page 42 Measurement timeout Uint16 measurement process will still require (see also “Trigger measurement”) Device serial number Char[20] Serial number of the nanoFlu sensor. Firmware version Char[10] Version number of the installed firmware. Indicates whether the sensor is in automatic Self-trigger activated Bool mode (only necessary for first installation).
  • Page 43 Trigger measurement A single measurement is taken. Report slave ID (0x11) Provides the sensor designation followed by the serial number followed by the firmware version each as a null-terminated ASCII character string. Example: 0x00 D 0x00 0x00 D01-060en202008 Manual nanoFlu...
