triOS eCHEM 90S220000 Operating Instructions Manual

Chlorine dioxide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Chlorine Dioxide
OPERATING INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eCHEM 90S220000 and is the answer not in the manual?

Questions and answers

Related Manuals for triOS eCHEM 90S220000

Summary of Contents for triOS eCHEM 90S220000

  • Page 1 Chlorine Dioxide OPERATING INSTRUCTIONS...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Table of Contents 1 General Information 6 Malfunction and Maintenance 1.1 Introduction 6.1 Cleaning and Upkeep 1.2 Health and safety information 6.2 Maintenance and inspection 1.3 Warnings 6.2.1 Electrolyte Replacement 1.4 Users and Operating Requirements 6.2.2 Membrane cap replacement 1.5 Intended use 6.2.3 Sensor Check 1.6 Disposal Information...

  • Page 4: General Information

    All of the content in this manual, including texts, photographs and graphics, are protected by copyright. Unless expressly stated otherwise, TriOS Mess- und Datentechnik GmbH is the owner of the copyright. Persons who violate the copyright shall be liable pursuant to § 106 et seq of the copyright law, they will be warned at their own expense and must pay compensation.

  • Page 5: Health And Safety Information

    Devices that radiate strong electromagnetic waves can influence the measurement data or result in a malfunction of the sen- sor. Avoid using the following devices in the same room as the TriOS sensor: mobile phones, cordless phones, transmitters/ receivers and other electrical devices that produce electromagnetic waves.

  • Page 6: Warnings

    Devices from TriOS Mess- und Datentechnik GmbH meet the highest safety standards. Repairs to the device (which involve the replacement of the connecting cable) must be carried out by TriOS Mess- und Datentechnik GmbH or by a workshop authorized by TriOS. Defective, improper repairs can lead to accidents and injuries.

  • Page 7: Intended Use

    This product meets all of the requirements of the harmonised European standards. It therefore meets the legal requirements of the EU guidelines. TriOS Mess- und Datentechnik GmbH confirms the successful testing of the product by affixing the CE marking. (See Annex.)

  • Page 8: Introduction

    Product type Power supply Interface In addition to the product bar code, the rating plate includes the TriOS Mess- und Datentechnik GmbH logo and the quality label. Please note that the specifications given here are for illustration purposes only and may be different depending on the version of the product.

  • Page 9: Scope Of Delivery

    Introduction Chlorine Dioxide 2.2 Scope of Delivery The shipment contains the following components: Sensor with membrane cap M10.1N 100 ml gel electrolyte ECD4/W*ECD7/W Fine sandpaper S2 1 G-holder with O-ring Tweezers Operating instructions Keep the original packaging of the device in case it needs to be returned for repairs. 2.3 Measurement Principle and Design The chlorine dioxide sensor is a membrane-covered am- perometric 2-electrode sensor.

  • Page 10: Commissioning

    Commissioning Chlorine Dioxide 3 Commissioning This chapter deals with the commissioning of the chlorine dioxide sensor. Please pay particular attention to this section and follow the safety precautions to protect the sensor from damage and yourself from injury. Prior to electrical installation (chap - ter 3.2) of the sensor, it must first be filled with gel electrolyte as described in chapter 3.1.
  • Page 11 Commissioning Chlorine Dioxide Place the membrane cap on a clean surface and fill to the rim with gel electrolyte. Place the G-holder on a clean surface with the fabric facing down and moisten the G-holder with gel electrolyte. Use the tweezers [1] to grasp the G-holder [2] with the fabric facing down and place the G-holder centrally on the memb - rane in the membrane cap [3].

  • Page 12: Electrical Installation

    8. Power (9...30 VDC) Insert the connector into one of the supplied TriOS cables. Connect the male end of the cable into the connector on the sensor by making the pins align with the slots of the cable. The next step is to turn the locking sleeve clockwise to secure the end of the connector.

  • Page 13: Interfaces

    The sensor must be used for measurements in the flow cell type FLC (see chapter 4). The use of the sensor in other flow cells must be approved by TriOS GmbH. Otherwise, no warranty will be given for the proper functioning of the sensor or for resulting damage to property or personal injury.

  • Page 14: Use

    Chlorine Dioxide 4 Use The chlorine dioxide sensor can be operated with all TriOS controllers. Instructions for correct installation can be found in the relevant controller manual. A bypass installation of the sensor is essential for correct results. Therefore we strongly recommend to use the sensor in the flow cell type FLC for permanent use.

  • Page 15: Installation With Retaining Ring In The Flow Cell

    Chlorine Dioxide A sudden failure of the sensor can lead to dangerous over-metering. Take appropriate precautions in this case! Check system for odour, check water for abnormal discolouration. In case of strong over- NOTICE metering, the DPD-1 measurement can remain colourless because the dye is bleached by the chlorine present.

  • Page 16: Calibration

    1.9. Recommendation: Weekly control, if necessary more frequently. In case of a necessary recalibration, operation with a TriOS controller is recommended. An integrated wizard guides the user step by step through a calibration menu. The value determi- ned analytically in parallel by the DPD method is set as the reference value in the controller.

  • Page 17: Measurement Properties

    Calibration Chlorine Dioxide 5.3 Measurement properties The following instructions must be observed when operating the sensor: • The sensor must be operated in an upright position so that the incoming flow of sample water comes from below up against the membrane. •...

  • Page 18: Malfunction And Maintenance

    6.2. If you have further questions on this topic, we would be pleased to help you. Please contact our customer service at support@ trios.de. 6.2 Maintenance and inspection The sensor should be checked regularly for contamination, fouling and bubbles on the outside of the membrane. Avoid con- tamination of the membrane with particles, condensation etc.

  • Page 19: Electrolyte Replacement

    Malfunction and Maintenance Chlorine Dioxide 6.2.1 Electrolyte Replacement It is recommended to replace the gel electrolyte at least twice a year or when an adjustment is no longer possible due to readings that are unstable or too low. Carry out the following steps one after the other: Unscrew the membrane cap.

  • Page 20: Sensor Check

    Malfunction and Maintenance Chlorine Dioxide 6.2.3 Sensor Check An adjustment or a check of the sensor according to the DPD-1 method should be carried out regularly at specific intervals, depending on the requirements. Recommendation: Weekly control, if necessary more frequently. It is recommended to replace the electrolyte at least twice a year.

  • Page 21: General Troubleshooting

    Malfunction and Maintenance Chlorine Dioxide 6.3.1 General Troubleshooting Fault Possible cause Action Sensor cannot be calibrated / measured Run-in time too short Repeat calibration after a few hours value deviates from DPD measurement Membrane cracked Replace membrane cap (see chapter 6.2.2) Membrane cap damaged Replace membrane cap (see chapter...
  • Page 22 Malfunction and Maintenance Chlorine Dioxide Fault Possible cause Action Unstable measuring signal Membrane cracked Replace membrane cap (see chapter 6.2.2) Air bubbles in the electrolyte (especially Empty the membrane cap and fill during operation under pressure) with new electrolyte bubble free (see chapter 6.2.1) Gas bubbles on the outside of the Briefly increase the flow rate, check and...
  • Page 23 Malfunction and Maintenance Chlorine Dioxide Fault Possible cause Action No signal The measuring line is interrupted. Replace the measuring line. The sensor is not supplied with power. Establish correct power supply. The sensor is defective. Send in sensor to the supplier to be checked / overhauled.

  • Page 24: Special Troubleshooting On The Sensor

    Malfunction and Maintenance Chlorine Dioxide 6.3.2 Special Troubleshooting on the Sensor If the electrode finger turns shiny silver or white, the sensor must be serviced by the manufacturer. Brown-grey discolourations are common. Tightness test of mem- 1. Unscrew the membrane cap from the sensor brane cap 2.
  • Page 25 Malfunction and Maintenance Chlorine Dioxide Zero point test After electronics test: 1. Prepare the sensor for commissioning according to chapter 3.1 of the operating instructions 2. Connect the sensor to the measuring/control unit 3. Carefully place the sensor in a beaker with clean tap water (no disinfectant!) 4.
  • Page 26 Malfunction and Maintenance Chlorine Dioxide Signal test After zero point test: 1. Add some disinfectant containing chlorine to the beaker filled with clean tap water from the "zero point test" 2. Stir as evenly as possible for at least 5 minutes with the sensor connected to the measuring instrument 3.

  • Page 27: Returns

    If this is not available, make sure that safe transport is guaranteed and that the sensor is safely packed with enough packing material. Should you require further information, please contact the TriOS customer service (see chapter 10). D01-915en201911 Manual eCHEM Chlorine Dioxide...

  • Page 28: Technical Data

    Technical Data Chlorine Dioxide 7 Technical Data 7.1 Technical Specifications Measurement technology Membrane-covered, amperometric 2-electrode system Measurement principle Amperometry Parameters Chlorine Dioxide Measurement range 0...2 mg/L, 0...20 mg/L Measuring range 2 mg/L: at 0.4 mg/L & 1.6 mg/L < 1 % Accuracy Measuring range 20 mg/L: at 1.5 mg/L <...

  • Page 29: Accessories

    Chlorine Dioxide 8 Accessories 8.1 Controller The sensor can be connected to all TriOS controllers. Below you will find an overview of the available TriOS devices: 8.1.1 TriBox3 Digital, 4-channel display and control unit with integrated solenoid valve for compressed-air control TriBox3 is a measurement and control system for all TriOS sensors.

  • Page 30: Warranty

    Warranty Chlorine Dioxide 9 Warranty The warranty period of our devices within the EU and the United States is 2 years from the date of the invoice. Elsewhere the war- ranty period is one year. Excluded from the warranty are all normal consumables, such as membrane caps and electrolyte, and service work to be carried out (cleaning of parts that have come into contact with electrolyte gel, replacement of the reference electrode and cleaning of the electrode tip with fine sandpaper).

  • Page 31: Customer Service

    Chlorine Dioxide 10 Customer service If you are having a problem with the sensor, please contact TriOS customer service. We recommend sending the sensor in for maintenance and calibration every 2 years. To do this, please request an RMA number from customer service.

  • Page 32: Contact

    If you have found an error or bug in one of the devices or programs, please let us know: Customer service: support@trios.de General questions / sales: sales@trios.de Website: www.trios.de TriOS Mess- und Datentechnik GmbH Bürgermeister-Brötje-Str. 25 D-26180 Rastede Germany Telephone +49 (0) 4402 69670 - 0 +49 (0) 4402 69670 - 20...
  • Page 33 Contact Chlorine Dioxide D01-915en201911 Manual eCHEM Chlorine Dioxide...

  • Page 34: Keyword Index

    Keyword Index Chlorine Dioxide 12 Keyword Index Accessories Health and safety information Baud rate Biological safety Intended use Interfaces Care CE certification Certificates & approvals Cleaning Contact Copyright Customer calibration Manufacturer Calibration Customer service Measurement Measurement principle Measurement properties Declaration of conformity Membrane cap replacement Disposal Mounting...
  • Page 35 Keyword Index Chlorine Dioxide Product Identification Technical Specifications Troubleshooting User requirements Rating plate Reagents Retaining ring Returns Warnings RMA number Warranty Waste Safety instructions Scope of Delivery Specifications Storage Structure of the sensor D01-915en201911 Manual eCHEM Chlorine Dioxide...

  • Page 36: Annex

    Bürgermeister-Brötje-Str. 25 D- 26180 Rastede Konformitätserklärung Declaration of Conformity Déclaration de Conformité Die TriOS GmbH bescheinigt die Konformität für das Produkt The TriOS GmbH herewith declares conformity of the product TriOS GmbH déclare la conformité du produit Bezeichnung eCHEM Chlordioxid...
  • Page 37 Annex Chlorine Dioxide Modbus RTU Modbus sensor short data Electrochemical sensor with digital signal processing and Modbus RTU interface. Power supply • 9...30 VDC, max. 56 mA 8-pin screw connector, M12, reverse polarity protection • 1 RS485 A • 2 RS485 B Pin assignment •...
  • Page 38 Annex Chlorine Dioxide Device data Address Access Data type Parameters Value range Default 0x0400 R / W slave-address 1 … 247 0x0401 R / W baud rate 2400 4800 9.600 0x0402 R / W parity/stop none/2 even none/1 Process data parameters Address Access Data type...
  • Page 39 Annex Chlorine Dioxide 0x0222 R / O float X_Null [3] 0x0224 R / O float X_Span [3] 0x0226 R / O unsigned longint DateTime [3] yymmddhhmm 0x0228 R / O float X_Null [4] 0x022a R / O float X_Span [4] 0x022c R / O unsigned longint...
  • Page 40 Annex Chlorine Dioxide D01-915en201911 Manual eCHEM Chlorine Dioxide...
