- Page 2 • Critical Warning • Over view • LONG RANGE SYSTEMS o Description the main unit keys • Geophysical system o Description the main unit keys o Start working with the geophysical system o First step: o Second step • No result message o First case ▪...
- Page 3 Critical Warning -Please be sure that all precautions taken against all risks. -Do not use your device while it is raining or on wet ground -You have to be sure that you are connecting the electric cables correctly - Use the four probes and you have to Plant it under the ground more than 25 CM. - don’t ever try to Plant the probes into the rocks.
- Page 4 Dear customer, “Thank you for choosing FRESH RESULT 2 systems plus” ✓ This product enables you to detect the presence of underground water. ✓ FRESH RESULT 2 systems product is based on resistance principle. ✓ It measures the resistance between the four probes placed on surface of the region predicted to have water.
- Page 5 1- LONG RANGE SYSTEMS This system specializes to cover vast areas and locate the water up to depth of 1200 Below the surface of the ground and Front Range of 2,000 meters. unit: the main unit of the device is placed on the ground in the transmission middle of the area to be discovered, we connect the antenna of the signal Transmitter to the main unit and plant the probes on...
- Page 6 We move between the search systems through navigation buttons and we select the “long range system” This screen will popup to inform you to “turn on” the Long range unit (infomation screen) After you turn on the long range unite you will see on the screen that the device start to send signals to the ground...
- Page 7 Description of the main unit keys – LONG RANG UNIT Description Keys Navigation button Selection button Power button Back button Note Before opening the device, the user should connect all parts of the system and connect the Handel to be able to open the device power We turn the device through...
- Page 8 We move between the languages through “navigation buttons” And we conform our selection by pressing button After selecting the Language, we choose the type of water that we will search for it 1- Fresh Water 2- Natural Water Then we choose the Front Range of the search.
- Page 9 • After selecting, the front-range the device will Begin the process of search. • Carry the device as in the photo. ➢ The user should position them self from the north to the south which is the best method to detect underground water. ➢...
- Page 10 2- Geophysical system This system allows you to discover more details about the discovered water after using the long-range system, a survey and analysis of the underground water and the way the system works in the following way Description the main unit keys – Geophysical system...
- Page 11 Description Keys 4.3 inch Screen for result display BACK button to return back to return the previous page Ok button to conform the options selected Navigation buttons between the options (up – down – right – left) Fuse to protect the electronic circuit v.
- Page 12 Second step: ➢ turn on the device and wait for a period of not more than 5 seconds until the device power up and display the language options of the device ➢ The device works on 4 languages, (English. Germany. Arabic. French) you can choose the language search by using the navigation button up and down keys...
- Page 13 ➢ “Soil type” to choose the type of soil in which to search ➢ “Probe spacing” to enter the distance between the probes according to your measurements on the ground by using a meter ➢ “Brightness” to adjust the lighting of the screen ➢...
- Page 14 ➢ This scanning process will takes a maximum of 3 minutes, Since the device is searching among the 4 probes in 6 different way to collect all information required to determine the depth and the water type and all the necessary information ➢...
- Page 15 ➢ Dear customer, When a "No result" message appears on the final search screen results Please follow the solution of this case carefully. First case The solution of this case The image above 1- Move the probe 3- Redistribute 4- Re-search showing us that the “3”...
- Page 16 Second case The solution of this case The image above 1-Determine the 3-Redistribute probes 4-Re-search showing us that the center of triangle “1” , “2” and “3” again to get device found water which consist of lines Depending on the new complete results only under the "A","B"...
- Page 17 Third case The solution of this case The image above 1- Or move the 2- Redistribute 3- Re-search showing us that the probes “1”, “2” again probe “4” From device found water and “3” its current only under the line Depending on location “A”...
- Page 18 “Important information and notes” ✓ If the device displays the results “no water” in the search this will means two different things o 1- Could be the cable not connect correctly between the main unite and the probs. o 2- could be the device had detected very salty water. ✓...
- Page 19 “Important information and notes” ✓ the Salinity of the water is to Measure the percentage of the Salts in the water ✓ When you see the depth in the results, for example: (110-130 meters) and you research again and give you, for example, (120-160 meters) or (40-170 meters) for example, that is mean there is more than 1 water well under the ground (there are several Water wells with different depths at the same place) ✓...
- Page 20 Warning If you want the device work well without errors, you have to follow next steps When using the device please do not wear any watches When using the device please do not wear any jewelry When using the device please get away from metals, lighter and mobile phone and video games.
-
Page 21: Parts And Accessories
Parts and accessories Geophysical system (main unit ) Long rang system (main unit) Long rang system (antennas) Long rang system (handle) Charger to be used for: 1- Long range system 2- Geophysical system 4 Cables for Geophysical system... - Page 22 4 Probes x (45 cm) External rechargeable battery...
