Summary of Contents for Quanmax KPC-1560
- Page 1 KPC-1560 15” Fanless Industrial Panel PC with Dual Core Intel ® Atom™ Processor D2550 + Intel ® NM10 Express Chipset User’s Guide KPC-1560 User’s Manual...
- Page 2 Quanmax, nor the rights of others. Quanmax is a registered trademark of Quanmax. All trademarks, registered trademarks, and trade names used in this user’s guide are the property of their respective owners.
-
Page 3: Table Of Contents
Chapter 3 AMI BIOS Setup ..................25 Overview ..................... 25 Main Menu ..................26 Advanced Menu .................. 27 Boot Menu ..................35 Security Menu ..................36 Save & Exit Menu ................36 Chapter 4 D river Installation .................. 38 KPC-1560 User’s Manual... -
Page 4: Figures & Tables
Figure 8 VESA Mounting Hole Locations ........... 22 Figure 9 Panel Mount Cut-out hole and maximum panel thickness ... 23 Figure 10 Panel Mounting ................24 Table 1 KPC-1560 product specification ............ 14 Table 2 BIOS Main Menu ................26 Table 3 Advanced Menu ................27 Table 4 Advanced Menu –... -
Page 5: Safety Instructions
Use extreme caution when installing or removing components. Refer to the installation instructions in this user’s guide for precautions and procedures. If you have any questions, please contact Quanmax Post-Sales Technical Support. Access can only be gained by service persons or by users who have ... -
Page 6: When Working Inside A Computer
Also, before connecting a cable, make sure both connectors are correctly oriented and aligned. CAUTION Do not attempt to service the system yourself except as explained in this user’s guide. Follow installation and troubleshooting instructions closely. KPC-1560 User’s Manual... -
Page 7: Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. Quanmax strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment. -
Page 8: Preface
Remove all items from the box. If any items listed on the purchase order are missing, notify Quanmax customer service immediately. Inspect the product for damage. If there is damage, notify Quanmax customer service immediately. Refer to “Warranty Policy” for the return procedure. -
Page 9: Warranty Policy
Quanmax or its authorized agent; or if the failure is caused by accident, acts of God, or other causes beyond the control of Quanmax or the manufacturer. Neglect, misuse, and abuse shall include any installation, operation, or maintenance of the product other than in accordance with the user’s guide. -
Page 10: Maintaining Your Computer
Quanmax. Limitation of Liability In no event shall Quanmax be liable for any defect in hardware, software, loss, or inadequacy of data of any kind, or for any direct, indirect, incidental, or consequential damages in connection with or arising out of the performance or use of any product furnished hereunder. - Page 11 Line conditioners keep a system’s AC power source voltage at a fairly constant level and, therefore, can handle brownouts. Because of this added protection, line conditioners cost more than surge protectors. However, line conditioners cannot protect against a complete loss of power. KPC-1560 User’s Manual...
- Page 12 Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. KPC-1560 User’s Manual...
-
Page 13: Chapter 1 Introduction
Chapter 1 Chapter 1 Introduction Overview ® The KPC-1560 Fanless Panel PC is combining the latest Intel Atom™ processor ® with the high integration of the Intel NM10 Express chipset. Featured are DDR3 800/1066MHz SODIMM up to 4GB, includes a 2.5" SATA hard drive or a solid-state drive (SSD). -
Page 14: Product Specifications
DC 12V Input (Optional: DC 24V) OS Support Windows 7 Dimensions 409.98mm x 317.98 mm x 49mm (WxDxH) Environment Operation Temp: 0ºC 50ºC Storage Temp.: -20ºC 60ºC Humidity: 0% - 95% Certification CE, FCC Class A Table 1 KPC-1560 product specification KPC-1560 User’s Manual... -
Page 15: System Tour
Power Switch The power switch allows powering ON and OFF the system. Ethernet The eight-pin RJ-45 LAN port supports a standard Ethernet cable for connection to a local network. KPC-1560 User’s Manual... - Page 16 MIC-IN (Pink) The microphone jack is designed to connect the microphone used for video conferencing, voice narrations, or simple audio recordings. Line-IN (Blue) The Line-in jack is designed to take input from a higher-powered sound source. KPC-1560 User’s Manual...
-
Page 17: Mechanical Dimensions
Chapter 1 Mechanical Dimensions 409.98 x 317.98 x 49 mm (W x D x H) Figure 2 Mechanical Dimensions KPC-1560 User’s Manual... -
Page 18: Chapter 2 Getting Started
Chapter 2 Chapter 2 Getting Started Setting up your PC Connecting the monitor Connect the DP/ VGA/ HDMI cable from your display to the DP/ VGA/ HDMI port. HDMI Figure 3 DP/ VGA/ HDMI KPC-1560 User’s Manual... - Page 19 Chapter 2 Connecting USB mouse & keyboard Your KPC-1560 does not come with a keyboard and mouse, but you can use any USB keyboard or mouse with your computer. Figure 4 Connect USB mouse & keyboard NOTE Using a third-party USB mouse or keyboard may require software drivers.
- Page 20 COM1RS-232 / 422 / 485 Port DB-9 Half Duplex Full Duplex RS-232 RS-422 RS-485 RS-485 DATA- DATA+ COM2 RS-232/422/485 Port 2 D-SUB 9P Half Duplex Full Duplex RS-232 RS-422 RS-485 RS-485 DATA- DATA+ Figure 6 COM ports KPC-1560 User’s Manual...
- Page 21 Chapter 2 Turning on the system Connect the power adapter cable to the DC jack (DC IN) of the KPC-1560 Connect the power cable to the power adapter Connect the power cable to a power outlet Press the power switch on the front panel to turn on the system...
-
Page 22: Vesa Mounting
Use 4 screws with the appropriate length for your mounting bracket. Figure 8 VESA Mounting Hole Locations NOTE To fasten the metal shelf, your monitor must comply with VESA75 or VESA100 standard. The VESA mounting kit is optional. KPC-1560 User’s Manual... -
Page 23: Panel Mounting
The Panel PC can be panel mounted and comes with brackets and screws for this purpose. The required cutout for panel mounting and maximum panel thickness is shown below. Figure 9 Panel Mount Cut-out hole and maximum panel thickness KPC-1560 User’s Manual... - Page 24 Chapter 2 Below are the demonstrations of how to do panel mounting. Step1 Tightening the screws as shown right. Step2 Done Figure 10 Panel Mounting KPC-1560 User’s Manual...
-
Page 25: Chapter 3 Ami Bios Setup
This chapter provides a description of the AMI BIOS. The BIOS setup menus and available selections may vary from those of your product. For specific information on the BIOS for your product, please contact Quanmax. NOTE: The BIOS menus and selections for your product may vary from those in this chapter. -
Page 26: Main Menu
+- Change Opt. Frequency 1067 MHz (DDR3) F1: General Help System date [Mon 08/01/2011] F2: Previous Values System time [00:13:19] F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. KPC-1560 User’s Manual... -
Page 27: Advanced Menu
Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. Onboard LAN 1 Controller Options: Disabled, Enabled Onboard LAN 1 Boot Options: Disabled, Enabled Onboard LAN 2 Controller Options: Disabled, Enabled Onboard LAN 2 Boot Options: Disabled, Enabled Audio Controller Options: Disabled, Enabled KPC-1560 User’s Manual... - Page 28 Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. Fixed Graphics Memory Size Options: 128MB, 256MB IGFX – Boot Type Options: VBIOS Default, CRT, DP, HDMI LVDS Backlight Control – Voltage Options: 0.0V, 0.5V, 1.0V, 1.5V, 2.0V, 2.5V, 3.0V, 3.5V, 4.0V, 4.5V, 5.0V KPC-1560 User’s Manual...
- Page 29 Options: Power Off, Power On, Last State Resume By PCIE Device Options: Disabled, Enabled Resume By RTC Alarm Options: Disabled, Enabled EUP Power Saving Mode Options: Disabled, Enabled Watchdog Timer Configuration WDT Function ■ Options: Disabled, Enabled KPC-1560 User’s Manual...
- Page 30 F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. Hyper-Treading Options: Disabled, Enabled Execute Disable Bit Options: Disabled, Enabled Limit CPUID Maximum Options: Disabled, Enabled EIST Options: Disabled, Enabled KPC-1560 User’s Manual...
- Page 31 F4 Save & Exit ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. Legacy USB Support Options: Disabled, Enabled, Auto EHCI hand-off Options: Disabled, Enabled Mass Storage Device Options: Auto, Floppy, Forced FDD, Hard Disk, CD-ROM KPC-1560 User’s Manual...
- Page 32 IO=3F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; Serial Port Type Options: RS232, RS422, RS485 KPC-1560 User’s Manual...
- Page 33 IO=3F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12 Serial Port 2 Type Options: RS232, RS422, RS485 KPC-1560 User’s Manual...
- Page 34 : +12.144 V F3: Optimized Defaults +3.3VSB : +3.360 V F4 Save & Exit ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. CPU Warning Temperature Options: Disabled, 80 ºC, 85 ºC, 90 ºC, 95 ºC KPC-1560 User’s Manual...
-
Page 35: Boot Menu
Boot Option #1 Options: UEFI, SATA PM: Disabled Boot Option #2 Options: UEFI, SATA PM: Disabled Hard Drive BBS Priorities ■ Boot Option #1 Options: UEFI, SATA PM: Disabled ■ Boot Option #2 Options: UEFI, SATA PM: Disabled KPC-1560 User’s Manual... -
Page 36: Security Menu
↑↓ Select Item Enter: Select Save Options +- Change Opt. Save Changes F1: General Help Discard Changes F2: Previous Values F3: Optimized Defaults Restore Defaults F4 Save & Exit ESC Exit Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc. KPC-1560 User’s Manual... - Page 37 Load Optimal Default values for all the setup values. This option allows you to load failsafe default values for each of the parameters on the Setup menus, which will provide the most stable performance settings. The F8 key can be used for this operation. KPC-1560 User’s Manual...
-
Page 38: Chapter 4 D River Installation
Chapter 4 Driver Installation If your KPC-1560 does not come with an operating system pre-installed, you will need to install an operating system and the necessary drivers to operate it. After you have finished assembling your system and connected the appropriate power source, power it up using the power supply and install the desired operating system.
