M9287
M-Series ProfiNet
Network Adapter (Single Type)
M9287 Profinet Network Adapter (Single Type)
Specification
FnIO M - Series:
M9287
Date: 2020. 3. 16
Revision 1.01
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M-Series and is the answer not in the manual?

Questions and answers

Related Manuals for CREVIS M-Series

Summary of Contents for CREVIS M-Series

  • Page 1 M9287 Revision 1.01 Specification M-Series ProfiNet Page 1 Network Adapter (Single Type) FnIO M - Series: M9287 M9287 Profinet Network Adapter (Single Type) Date: 2020. 3. 16...

  • Page 2: Table Of Contents

    2.8.Mapping Data into Image Table ......................13 2.8.1.Discrete Input Module ........................13 2.8.2.Discrete Output Module ......................... 14 2.8.3.Analog Input Module ........................15 2.8.4.Analog Output Module ........................16 2.9.Example of Input Process Image (Input Register) Map ................ 17 3.FnIO M-Series Caution(Before using the unit) .................... 18...
  • Page 3 M9287 Revision 1.01 Specification M-Series ProfiNet Page 3 Network Adapter (Single Type) 3.1.How to wire communication & Power ....................18 3.1.1.Wiring of communication & System power line for Ethernet............18 3.2.Module Mounting ..........................19 4.MODBUS INTERFACE ..........................21 4.1.MODBUS Special Register Map ......................21 4.1.1.Adapter Identification Special Register (0x1000, 4096) ..............

  • Page 4: History

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 4 Network Adapter (Single Type) History REV. PAGES REMARKS DATE Editor Preliminary 2019/8/7 JY BAE Vibration, Product changed, Added ATEX certification, 1.01 2020/05/20 CW SEO M-Series caution...

  • Page 5: Environment Specification

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 5 Network Adapter (Single Type) 1. ENVIRONMENT SPECIFICATION Environmental specification Operating Temperature -25℃~60℃ UL Temperature -20℃~60℃ Storage Temperature -40℃~85℃ Relative Humidity 5% ~ 90% non-condensing Mounting DIN rail General specification Shock Operating IEC 60068-2-27...

  • Page 6: M9287 (Profinet Network Adapter)

    1 Green/Red, Expansion I/O Module Statsus (IOS) 2 LEDs (each RJ45 Connector) 1 Yellow, Link/Active 1 Green, Not used Module Location Starter module left side of M-Series system Field Power Detection About 15Vdc General specification (Supplied by M7001) UL System Power...

  • Page 7: 9287 Wiring Diagram

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 7 Network Adapter (Single Type) 2.2. 9287 Wiring Diagram * Primary Power Setting (P.S pin) - Short the P.S pin to set one of the two M7001 as the primary power. Pin No.

  • Page 8: M9287 Led Indicator

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 8 Network Adapter (Single Type) 2.3. M9287 LED Indicator 2.3.1. LED Indicator LED No. LED Function / Description LED Color Module Status Green/Red Current communication status Green ERROR Error Status (Profinet) Extension Module Status Green/Red 2.3.2.

  • Page 9: M7001 Led Indicator

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 9 Network Adapter (Single Type) 2.4. M7001 LED Indicator 2.4.1. LED Indicator LED No. LED Function / Description LED Color M-Bus Status Green Primary Status Green Active Green Field Power Field Power Enable Green 2.4.2.

  • Page 10: M9287 Electrical Interface

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 10 Network Adapter (Single Type) 2.5. M9287 Electrical Interface 2.5.1. RJ-45 Socket Signal RJ-45 Description Name Transmit + Transmit - Receive + Receive - Case Shield 2.5.2. Dip Switch * Set Node 1~99...

  • Page 11: Rs232 Port For Modbus/Rtu, Touch Panel Or Io-Guide

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 11 Network Adapter (Single Type) 2.5.3. RS232 Port for MODBUS/RTU, Touch Panel or IO-Guide Signal Pin# Description Name Reserved ---- RS232 TXD RS232 RXD RS232 GND...

  • Page 12: Hot Swap Function

    Network Adapter (Single Type) 2.6. Hot Swap Function The M-Series has hot-swap capability to protect your system. ※ Caution If you remove multiple IO modules by mistake, you must connect IO modules one by one, starting with the lower slot number.

  • Page 13: I/O Process Image Map

    An expansion module may have 3 types of data as I/O data, configuration parameter and memory register. The data exchange between network adapter and expansion modules is done via an I/O process image data by M-Series protocol. The following figure shows the data flow of process image between network adapter and expansion modules.

  • Page 14: Discrete Output Module

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 14 Network Adapter (Single Type) 32 Point Input Module • 2.8.2. Discrete Output Module 8 Point Output Module • 16 Point Output Module • 32 Point Output Module •...

  • Page 15: Analog Input Module

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 15 Network Adapter (Single Type) 2.8.3. Analog Input Module 4 Channel Analog Input Module • 8 Channel Analog Input Module •...

  • Page 16: Analog Output Module

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 16 Network Adapter (Single Type) 2.8.4. Analog Output Module 4 Channel Analog Input Module • 8 Channel Analog Input Module •...

  • Page 17: Example Of Input Process Image (Input Register) Map

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 17 Network Adapter (Single Type) 2.9. Example of Input Process Image (Input Register) Map Input image data depends on slot position and expansion slot data type. Input process image data is only ordered by expansion slot position .

  • Page 18: Fnio M-Series Caution(Before Using The Unit)

    Network Adapter (Single Type) 3. FnIO M-Series Caution(Before using the unit) ■ We appreciate you for purchasing CREVIS Products. To use the units more effectively, please read this quick guide and refer to the respective user manual for further details.

  • Page 19: Module Mounting

    Page 19 Network Adapter (Single Type) 3.2. Module Mounting 3.2.1. How to mount & dismount M-Series Modules on Din-Rail 1) Ready 2) Unlock the 'Din Rail-Locker' like Number (1). 3) Push the module to the din-rail. 4) Lock the 'Din Rail-Locker' like Number (3) to fix the module on the din rail.
  • Page 20 M9287 Revision 1.01 Specification M-Series ProfiNet Page 20 Network Adapter (Single Type) 6) To remove the module on the din-rail, first unlock the 'Din-Rail Locker' like Number (5). 7) Pull the module against the din-rail. 8) End...

  • Page 21: Modbus Interface

    (one address). 4.1.1. Adapter Identification Special Register (0x1000, 4096) Address Access Type, Size Description 0x1000(4096) Read 1word Vendor ID = 0x0140(320), Crevis. Co., Ltd. 0x1001(4097) Read 1word Device type = 0x000C, Network Adapter 0x1002(4098) Read 1word Product Code = 0xA080 0x1003(4099)

  • Page 22: Adapter Information Special Register (0X1100, 4352)

    0x80* : At Hot swap mode expansion module error 0x111D(4381) Read 1word Adapter M-Series Revision. * After the system is reset, the new “Set Value” action is applied. ** If the slot location is changed, set default value automatically (all expansion slot are live).

  • Page 23: Expansion Slot Information Special Resister (0X2000, 8192)

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 23 Network Adapter (Single Type) 4.1.5. Expansion Slot Information Special Resister (0x2000, 8192) Each expansion slot has 0x20(32) address offset and same information structure. Slot#1 0x2000(8192)~0x201F(8223) Slot#2 0x2020(8224)~0x203F(8255) Slot#3 0x2040(8256)~0x205F(8287) Slot#4 0x2060(8288)~0x207F(8319) Slot#5 0x2080(8320)~0x209F(8351)
  • Page 24 M9287 Revision 1.01 Specification M-Series ProfiNet Page 24 Network Adapter (Single Type) Type, Address Offset Access Description Size + 0x02(+2) ** Read 1word Input start register address of input image word this slot. + 0x03(+3) ** Read 1word Input word’s bit offset of input image word this slot.

  • Page 25: Supported Modbus Function Codes

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 25 Network Adapter (Single Type) 4.2. Supported MODBUS Function Codes MODBUS Reference Documents http://www.modbus.org MODBUS Tools http://www.modbustools.com, modbus poll http://www.win-tech.com, modscan32...

  • Page 26: Parameter

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 26 Network Adapter (Single Type) 5. PARAMETER 5.1. M9287 Parameter Parameter Setting Description Word data type All type Little Endian format(LSB-MSB) Clear output image to 0 * All outputs are set to 0.

  • Page 27: Sub-Slot Of M9287

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 27 Network Adapter (Single Type) Requires IOPS/IOCS Requires Engineering tool which supports at least V2.32 GSDML Version 5.2.3. Sub-slot of M9287 Item Value Sub-slot Number Sub-slot Label 32768 (0x8000) 32769 (0x8001) Sub-module Sub-...

  • Page 28: Use In Hazardous Environments

    M9287 Revision 1.01 Specification M-Series ProfiNet Page 28 Network Adapter (Single Type) 6. Use in Hazardous Environments ATEX Zone2 Information 1. Certification number : DEMKO 19 ATEX 2223X 2. Ambient range (-20℃ ≤ Tamb ≤ +60℃) 3. Certification string :...
  • Page 29 M9287 Revision 1.01 Specification M-Series ProfiNet Page 29 Network Adapter (Single Type) ATEX Zone22 Information 1. Certification number : DEMKO 20 ATEX 2373 2. Ambient range (-25℃ ≤ Tamb ≤ +60℃) 3. Certification string : * Note : a) This device can be installed with maximum one network module (MD9 or M9) and six IO modules (M1 to M7).
