5.1. Total Expansion ........................18 5.2. Plugging and Removal of the Components ..............18 5.3. Internal G-Bus/Field Power Contacts ................19 6. PROFIBUS Electrical Interface ....................20 6.1. G-Bus System ........................20 Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Page 4
9.3.3. Expansion Slot Information Special Resister(0x2000,8192) ........36 10. Trouble Shooting ........................39 10.1. How to diagnose by LED indicator ................39 A. APPENDIX A ........................... 41 A.1. Product List ........................41 A.2. Glossary ........................... 43 Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
1.1.3. Certification c-UL-us UL Listed Industrial Control Equipment, certified for U.S. and Canada See UL File E235505 FCC, Reach, RoHS- II, China RoHS CE Certificate EN 61000-6-2; Industrial Immunity EN 61000-6-4; Industrial Emissions Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Based on IEC 60068-2-6 DNVGN-CCG-0039 : Vibration Class B, 4g Industrial Emissions EN 61000-6-4/ALL : 2011 Industrial Immunity EN 61000-6-2 : 2005 Installation Position Vertical and horizontal installation is available. Product Certifications CE, UL, FCC Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Supply voltage : 24Vdc nominal Supply voltage range : 16~30Vdc System Power Protection : Output current limit (Min. 1.5A) Reverse polarity protection Power Dissipation 100mA @24Vdc Current for I/O Module 1.5A @5Vdc Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Page 9
-. -40 ~ 70 temperature range specification can be guaranteed℃ under the follwing conditions. -. Current for I/O Modules : 0.8A below. -. Otherwise, temperature specification can be guranteed with -40 ~ 60℃. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Pin No. Signal Description Signal Description Pin No. System Power, 24V System Power, Ground System Power, 24V System Power, Ground Field Power, Ground Field Power, Ground Field Power, 24V Field Power, 24V Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
- Not allocated to a master On-line, Green Device is on-line and allocated to a master Connected Connection Time-out Flashing Red One or more I/O connections are in the time-out state. Critical Communication Failure Faild communication Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
3.3.6. Field Power, System Power LED (Field Power, System Power Status LED) State To indicate Not supplied field, system power Not supplied 24Vdc field power, 5Vdc system poser. Supplied field, system power Green Supplied 24Vdc field power, 5Vdc system power. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
The data exchange between network adapter and expansion modules is done via an I/O process image data by G-Series Internal Bus protocol. The following figure shows the data flow of process image between network adapter and expansion modules. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
As above figure in order to safeguard the FnIO module from jamming, it should be fixed onto the DIN rail with locking level. To do so, fold on the upper of the locking lever. To pull out the FnIO module, unfold the locking lever as below figure. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
It is comprised of 6 data pin and 2 field power pin. Do not touch data and field power pins in order to avoid soiling and damage by ESD noise. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Network Adapter Module, e.g. for SyncNet, PROFIBUS, CANopen, DeviceNet , Ethernet/IP, CC-Link, MODBUS/Serial, MODBUS/TCP etc. • Expansion Module The Expansion Modules are supported a variety of input and output field devices. There are digital and analog input/output modules and special function modules. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Page 21
Token output port of Processor module. Serial Output Transmitter output port of Processor module. Serial Input Receiver input port of Processor module. Reserved Reserved for bypass Token. Field GND Field Ground. Field Vcc Field supply voltage (24Vdc). Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Due to the capacitive load of the station and the resulting cable reflections, bus connectors should be provided with built-in series inductors as shown below. The use of an incorrect supply voltage or frequency can cause severe damage to the component.. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
In order to minimize cable reflections and ensure a defined noise level on the data lines, the data transfer cable must be terminated at both ends with a terminating resister combination as follows. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
The above figure shows MAC ID 27(=2*10 + 7*1) of a slave node. ◆ Communication Speed Setting - See Master Module Setting about communication speed setting. MAC ID addresses have to be unique throughout the entire interconnected networks.. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Example : The repeater manufacture specifications allow nine repeaters to be connected in series. The maximum distance between two bus stations at a data transfer rate of 1500 kbit/s is then as follow: (9+1)*200m=2000 m Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
The data exchange between network adapter and expansion modules is done via an I/O process image data by FnBus protocol. The following figure shows the data flow of process image between network adapter and expansion modules. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Get diagnostic from slave, till bit is released Bit 0 Prm_ Slave must be parameterized Bit 7 Ext_Diag_Ovfl. The slave has more diagnostic data available than it can send Bit 6~0 Reserved Reserved Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
1-16 are addressed as 0-15. The discrete inputs in the response message are packed as one input per bit of the data field. Status is indicated as 1= ON; 0= OFF. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Page 32
The byte count field specifies the quantity of bytes to follow in the read data field. - Refer to MODBUS APPLICATION PROTOCOL SPECIFICATION V1.1a Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
The response data field returns the quantity of messages addressed to the remote device, or broadcast, that the remote device has processed since its last restart, clear counters operation, or power–up. Sub-function Data Field (Request) Data Field (Response) Description 0x000E(14) 0x0000 Slave Message Count Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Specialized use in conjunction with gateways, indicates hat the Gateway Path gateway was unable to allocate an internal communication path from Unavailable the input port to the output port for processing the request. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Page 37
Output word’s bit offset of output image word this slot. + 0x06(+6) ** Read 1word Input bit start address of input image bit this slot. + 0x07(+7) ** Read 1word Output bit start address of output image bit this slot. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Page 38
Read/Write 2word Firmware release date. ** After the system is reset, the new “Set Value” action is applied. *** Nothing of output, input, memory or configuration parameter corresponding slot returns Exception 02. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
- Mismatch vendor code between adapter and expansion module. Field Power LED turns off - Field power is not supplied. - Check main power Cable - Contact Sales team and send module for repair. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Page 40
- Check composition is right Configuration of communication baud rate I/O size Configuration of each nodes Ground and environment - Check ground is contacted - Check environment factor(temperature, humidity, etc) is in less than regular limit Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
Page 42
1CH, Stepper Module (TBD) 5521 Power Module GT-7408 Shield Module 7408 GT-7508 Common for 0Vdc 7508 GT-7511 Power Expansion, In 24Vdc, Out 1A/5Vdc 7511 GT-7518 Common for 24Vdc 7518 GT-7588 Common for 0Vdc, 24Vdc 7588 Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
- Sink : The method of in/output power supply if a device has no power source. - Source : The method of in/output power supply if a device has the power source. Copyright(C) CREVIS Co.,Ltd Support +82-31-273-6453 URL : www.crevis.co.kr...
