- Page 1 Home Dehumidifier Please read the manual carefully before using the unit PD220B USER MANUAL www.kesnos.com...
- Page 2 TO ACCESS CUSTOMER SUPPORT FASTER If there is any problem of the product, please contact Kesnos Customer Service at support@kesnos.com with your Purchase Order ID to help you...
- Page 3 BEFORE FIRST USE: To prevent any internal damage, it is very important to keep the unit (like this one) upright throughout its journey. Please leave it standing as the picture shown below and outside the box for 24 HOURS before plugging it in.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Safety Instructions ..................01 Parts Description ..................02 Control Interface..................03 Operation Instructions ................04 Cleaning & Maintenance ................12 Troubleshooting ..................13 Special Notes...................16 Technical Parameters ................17 Warranty & Contact Us................18 Statement The graphics and functions provided in this manual may not be the same as the actual product. -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS Safety Notes: For your safety, please read the manual carefully and keep the manual for future reference. Please use this product according to the instructions of installation and operation of this manual. ● Before cleaning the dehumidifier, turn off the power and unplug it from the power outlet. -
Page 6: Parts Description
PARTS DESCRIPTION Front Control Panel Air Outlet Water Tank Rear Handle Air Intake Continuous Drainage Port - 2 -... -
Page 7: Control Interface
CONTROL INTERFACE 1. Control Panel SLOW FAST WATER FULL TIMER LOCK LIGHTING SPEED SETTING POWER TIMER POWER LIGHTING SPEED LOCK SETTING DISPALY PANEL Timer Button Power Button Press to turn the dehumidifier Press to initiate the auto-start or auto-stop feature. on/off. -
Page 8: Operation Instructions
OPERATION INSTRUCTIONS 2.Setting Setting Humidity The humidity level can be set within a range of 30%RH to 80%RH in 5% increments. ● When it starts to work, it will first automatically detect and show the room's humidity. In dehumidification mode (other modes are invalid), press the "SETTING" button, you can change the humidity selection in 5% increments, "... - Page 9 OPERATION INSTRUCTIONS Speed Button Control the fan speed. Press to select either FAST or SLOW fan speed. FAST fan speed will result in quicker moisture removal. Set the speed FAST for maximum moisture removal. When the humidity has been reduced and quiet operation is more preferred, set the fan speed back to SLOW.
- Page 10 OPERATION INSTRUCTIONS Auto Defrost Feature When the dehumidifier is running at a lower temperature, the system will automatically determine whether there is a presence of frost. lf any frost exists, it will defrost automatically. Defrost Action The fan runs at high wind speed when the compressor stops. 3.
- Page 11 OPERATION INSTRUCTIONS 4. Instructions for Drying Clothes The dehumidifier can be used for drying clothes in rainy weather. Step 1. Hang the washed clothes in a small space such as cloakroom, bathroom, or storage room. Note: Keep away the unit from the water drip of the washed clothes. Step 2.
- Page 12 OPERATION INSTRUCTIONS 5. Fault & Processing Methods - 8 -...
- Page 13 OPERATION INSTRUCTIONS 6. Empty the Tank or Bucket Two ways are available to remove the collected water. Use the Water Tank When the water tank is already full, the Full Tank Alert indicator will light up, the dehumidifier will automatically shut down until the tank has been emptied and placed back to the unit.
- Page 14 OPERATION INSTRUCTIONS Note: Do not remove the float from the water tank. If the float in the water tank is removed, the sensor may not be able to determine the water level stored in the tank properly that may lead to water overflow leak from the water tank. If the water tank is dirty, just use cold water or warm water to clean it.
- Page 15 OPERATION INSTRUCTIONS 7. Continuous Drainage Remove the power supply, use a knife or pliers and other tools to remove the plastic cover of the continuous drainage port and insert the water hose into the port. Connect the power supply to start the operation. The outlet of the water hose should be lower than the continuous drainage port by more than 3.9 inches, and can not be bent.
-
Page 16: Cleaning & Maintenance
CLEANING AND MAINTENANCE WARNING: Turn the dehumidifier off and remove the plug from the wall outlet before cleaning. A- Cleaning the dehumidifier body Please use only a soft and a bit wet textile or cloth to clean it. B- Cleaning filter Pull out the filter. -
Page 17: Troubleshooting
If all troubleshooting steps have been exhausted and the issue is still occurring, please feel free to reach out to Kesnos Customer Service to get further assistance. - Page 18 TROUBLESHOOTING Please wait for more than 3 This is to prevent the frequent minutes. start of the machine. Does the machine stop working just now? The dehumidifier is designed to work in the humidity range Room humidity is low. of 30%-80%. Above or below this range, it will not work.
- Page 19 If the dehumidifier is still not working properly as expected and the troubleshooting steps or solutions above may not resolve the issue. Please unplug the power and shut down the dehumidifier, then contact Kesnos Customer Service at support@kesnos.com - 15 -...
-
Page 20: Special Notes
SPECIAL NOTES When using, please do not put When using, please keep the Do not insert thin rods and hard the machine at the soft and machine away from heating objects into the fuselage to uneven ground, avoid vibration furnace, electric kettle and avoid malfunction and danger. -
Page 21: Technical Parameters
TECHNICAL PARAMETERS MODEL PD220B POWER SOURCE 120V～60Hz RATED POWER (95°F, 90%RH) 400W RATED CURRENT (95°F, 90%RH) 3.6A MOISTURE REMOVAL (65°F, 60%RH) 12.3 Pints/Day (5.8L/Day) 20 Pints/Day (9.6L/Day) MOISTURE REMOVAL (80 ℉, 60%RH) 43 Pints/Day (20.4L/Day) MOISTURE REMOVAL (86 ℉, 80%RH) MOISTURE REMOVAL (95 ℉, 90%RH) -
Page 22: Warranty & Contact Us
CONTACT US Warranty Kesnos offers a 12-month warranty to all of our products together with the original proof of purchase when a defect occured, including those newly purchased and unused, from Kesnos or through an authorized reseller, wholly or substantially, or as a result of faulty manufacturing parts, or workmanship during the Warranty Period. - Page 24 We are expecting to see our products fulfill your life and hear your voice. Your satisfaction means a lot to us. Please tag us if you share a snap on your social media. www.kesnos.com...
