- Page 1 Please read the manual carefully before using the unit PD220B USER MANUAL www.kesnos.com...
- Page 2 To Access Customer Support Faster If there is any problem of the product, please contact Kesnos Customer Service at support@kesnos.com with your purchase Order ID to help us...
- Page 3 BEFORE FIRST USE: To prevent any internal damage, it is very important to keep refrigeration units (like this one) upright throughout their journey. Please leave it standing upright and outside the box for 24 HOURS before plugging it in. 需工厂替换成220B产品直立的图片...
-
Page 4: Table Of Contents
CATALOG Precaution for Use..............Parts Description ..............Control Interface..............Operation Instructions............Cleaning and Maintenance............ Troubleshooting ..............Safety Note................Technical Parameters............Warranty and Contact Us............Statement The graphics and functions provided in this manual may not be the same as the actual product. Please always refer to the actual product. The model of the machine on the manual is for reference only. -
Page 5: Precaution For Use
PRECAUTIONS FOR USE Safety notes: For your safety, please read the manual carefully and and keep the manual to serve as a reference for product usage. This product is for home use only. Please use this product according to the installation and operation of this manual. Before cleaning the dehumidifier, turn off the power and unplug it from the power outlet. -
Page 6: Parts Description
Parts Description Front Rear Control Panel Air Outlet Handle Air Intake Continous Drain Outlet Water Tank - 2 -... -
Page 7: Control Interface
CONTROL INTERFACE 1. Control Panel WiFi提示灯 风 风 水满 WiFi 低 高 定时 童锁 灯光 风速 设定 电源 童锁键 显示屏 定时键 灯光键 ⻛速键 设定键 电源键 请根据产品的实际功能和按键改成英文 Timer Button Power Button Press to turn the dehumidifier Press to initiate the auto start and auto stop feature on and off Child Lock... -
Page 8: Operation Instructions
OPERATION INSTRUCTION 2.Setting Setting Humidity The humidity level can be set within a range of 30%RH to 80%RH in 5% increments. -When it starts work, it will first automatically detect and show the room's humidity . In dehumidification mode (other modes are invalid),Press the "Dehumidify"... - Page 9 OPERATION INSTRUCTION Speed Button Controls the fan speed.Press to select either High or Low fan speed. Higher fan speed will result in quicker moisture removal. Set the fan control to High for maximum moisture removal. When the humidity has been reduced and quiet operation is preferred, set the fan control to Low.
- Page 10 OPERATION INSTRUCTION Auto Defrost Feature When the dehumidifier is running at a lower temperature, the system will automatically determine whether there is a presence of frost. If the machine determines there is a presence of a frost, it will defrost automatically. Defrost Action The fan runs at high wind speed when the compressor stops.
- Page 11 OPERATION INSTRUCTION 4. Instructions for Drying Clothes The dehumidifier can be used for drying clothes in rainy weather. Step 1. Hang the washed clothes in a small space such as cloakroom, bathroom, or storage room. Note: Keep away the unit from the water drip from the washed clothes. Step 2.
- Page 12 2. When one of the above malfunctions occurs, the buzzer will alarm for a few seconds. Press any key during the alarm to release the alarm sound. If the malfunction is still present, please don’t hesitate to contact Kesnos Customer Service email: support@kesnos.com for help.
- Page 13 OPERATION INSTRUCTION 6. Empty the Tank or Bucket There are two ways to remove collected water. Use the Bucket When the water tank is already full, the Full Tank Alert indicator will light up, the dehumidifier will automatically shut down until the tank has been emptied and placed back to the unit.
- Page 14 OPERATION INSTRUCTION Note: Do not remove the float from the water tank. If the float in the water tank is removed, the sensor may not be able to determine the water level stored in the tank properly that may lead to water overflow leak from the water tank. If the water tank is dirty, just use cold water or warm water to clean it.
- Page 15 OPERATION INSTRUCTION 备注： 请检查下排水口直径是否正确 7. Continuous Drainage Remove the power supply, take out the water tank, open the drain cover, insert the water pipe into the continuous drain port and push it back into the water tank. Connect the drain hose supply to start the operation. The water outlet of the water pipe should be lower than the continuous drainage port by more than 3.9inches(10cm), and the water pipe cannot be bent.(Note: The continuous drain port diameter is 0.63 inch(16mm).)
-
Page 16: Cleaning And Maintenance
CLEANING AND MAINTENANCE WARNING: Turn the dehumidifier off and remove the plug from the wall outlet before cleaning. A- Cleaning the dehumidifier body Please use only a soft and a bit wet textile or cloth to clean it. B- Cleaning filter Pull out the filter. -
Page 17: Troubleshooting
Listed below are not result of defective unit, crafts or materials in the unit. If all troubleshooting steps has been exhausted and issue is still occurring, feel free to get in touch with Kesnos Customer Service to get further assistance. - Page 18 TROUBLESHOOTING There is prevent frequent Please wait for more than 3 start function in the machine. minutes. Dose the machine stop working just now? The dehumidifier is designed to work in the humidity rane of Room humidity is low. 30%-80%.Above or below the work humidity range, it will not work.
- Page 19 If the dehumifier is still not working properly as expected and the troubleshooting steps or solutions above may not resolve the issue. Please unplug the power and shut down the dehumidifier then contact Kesnos customer service support@kesnos.com - 15 -...
-
Page 20: Safety Note
SAFETY NOTE When using, please do not put When using, please keep the Do not insert thin rods and hard machine away from heating the machine at the soft and objects into the fuselage to uneven ground, avoid vibration furnace, electric kettle and avoid malfunction and danger. -
Page 21: Technical Parameters
TECHNICAL PARAMETERS Model PD220B Power Source 120V~60Hz Rated Power(80°F,67°F) 300W Rated Current(80°F,67°F) 2.7A Moisture Removal(95°F,90%RH) 60 Pints/Day Input Power(65°F,60%RH) 215W 2.0A Input Current(65°F,60%RH) Noise Level(Low Fan) 43dB(A) Noise Level(High Fan) 45dB(A) IEF(65°F,60%RH) 1.30 liters/kWh Motor Fla 0.47A RLA:4.3A LRA:9.9A Motor Compressor R134a/7.05ozs(200g) -
Page 22: Warranty And Contact Us
CONTACT US Warranty Kesnos offers a 12-month warranty to all of our products, newly purchased and unused, from Kesnos Technology Co., Ltd. or through an authorized reseller, together with the original proof of purchase when a defect occurred, wholly or substantially, or as a result of faulty manufacturing, parts or workmanship during the Warranty Period. - Page 24 说明书 PD253D（KESNOS） 设计： 审核： 批准： 与02版本差异说明：整改内容 特别说明：蓝色内容按照注明的CMYK值印刷： C:65 M:0 Y:30 K:0 虚线框内内容为非印刷内容，无需印刷； support@kesnos.com Contact us on Facebook: kesnos （Scan the QR Code Get More) www.kesnos.com 30700401287-06 307-2715(03)
