Summary of Contents for Asus PN62S
- Page 1 Mini PC PN62S User Manual...
- Page 2 Copyright © 2020 ASUSTeK COMPUTER INC. All Rights Reserved. LIMITATION OF LIABILITY Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and damage to real property and tangible personal property;...
-
Page 3: Table Of Contents
Contents About this manual .........................5 Conventions used in this manual ..................6 Typography ..........................6 Package contents ........................7 Getting to know your Mini PC Features .............................10 Front view ..........................10 Left view ...........................12 Right view ..........................13 Rear view ..........................14 Using your Mini PC Getting started ........................18 Connect the AC power adapter to your Mini PC............18 Connect a display panel to your device ................20... - Page 4 Appendix Safety information .........................36 Setting up your system .......................36 Care during use ........................36 Regulatory notices ........................38 PN Series...
-
Page 5: About This Manual
About this manual This manual provides information about the hardware and software features of your Mini PC, organized through the following chapters: Chapter 1: Getting to know your Mini PC This chapter details the hardware components of your Mini PC. Chapter 2: Using your Mini PC This chapter provides you with information on using your Mini PC. -
Page 6: Conventions Used In This Manual
Conventions used in this manual To highlight key information in this manual, some text are presented as follows: IMPORTANT! This message contains vital information that must be followed to complete a task. NOTE: This message contains additional information and tips that can help complete tasks. -
Page 7: Package Contents
Package contents Your Mini PC package contains the following items: ASUS Mini PC PN Series AC power adapter* Power cord* Technical documentations PN Series... - Page 8 • If the device or its components fail or malfunction during normal and proper use within the warranty period, bring the warranty card to the ASUS Service Center for replacement of the defective components. PN Series...
-
Page 9: Getting To Know Your Mini Pc
Getting to know your Mini... -
Page 10: Features
Features Front view Power button The power button allows you to turn the Mini PC on or off. You can use the power button to put your Mini PC to sleep mode or press it for four (4) seconds to force shutdown your Mini PC. - Page 11 USB 3.2 Gen 2 Type-C® port This USB Type-C® (Universal Serial Bus) port provides a transfer rate of up to 10 Gbit/s. This port also supports the Battery Charging 1.2 technology that allows you to charge your USB devices. NOTE: Battery Charging 1.2 technology is only available on selected models, and provides a maximum of 5V / 1.5A output.
-
Page 12: Left View
Left view Air vents (intake vent) The air vents allow cooler air to enter your Mini PC chassis. IMPORTANT: For an optimum heat dissipation and air ventilation, ensure that the air vents are free from obstructions. PN Series... -
Page 13: Right View
Right view Air vents (intake vent) The air vents allow cooler air to enter your Mini PC chassis. IMPORTANT: For an optimum heat dissipation and air ventilation, ensure that the air vents are free from obstructions. Kensington security slot The Kensington security slot allows you to secure your Mini PC using Kensington®... -
Page 14: Rear View
Rear view HDMI™ port The HDMI™ (High Definition Multimedia Interface) port supports a Full-HD device such as an LCD TV or monitor to allow viewing on a larger external display. Air vents (exhaust vent) The air vents allow your Mini PC chassis to expel hot air out. - Page 15 Configurable port This port varies between models and consists of the following port options: VGA port This port allows you to connect your Mini PC to an external display. Serial (COM) connector The 9-pin serial (COM) connector allows you to connect devices that have serial ports such as mouse, modem, or printers.
- Page 16 USB 3.1 Gen 1 Type-C /DisplayPort combo port ® This USB Type-C® (Universal Serial Bus) port provides a transfer rate of up to 5 Gbit/s, and supports Display port 1.2. Use a USB Type-C® adapter to connect your Mini PC to an external display.
-
Page 17: Using Your Mini Pc
Using your Mini PC... -
Page 18: Getting Started
Getting started Connect the AC power adapter to your Mini PC To connect the AC power adapter to your Mini PC: Connect the power cord to the AC power adapter. Connect the DC power connector into your Mini PC’s power (DC) input. - Page 19 IMPORTANT! • We strongly recommend that you use only the AC power adapter and cable that came with your Mini PC. • We strongly recommend that you use a grounded wall socket while using your Mini PC. • The socket outlet must be easily accessible and near your Mini •...
-
Page 20: Connect A Display Panel To Your Device
Connect a display panel to your device You can connect a display panel or projector to your device that has the following connectors: • VGA connector • DisplayPort • HDMI™ connector • Thunderbolt 3 connector NOTE: These ports may vary per model. To connect a display panel to your Mini PC: Connect one end of a VGA, DisplayPort, HDMI™... - Page 21 Connect display via VGA port Connect display via HDMI™ port PN Series...
- Page 22 Connect display via DisplayPort Connect display via Thunderbolt 3 port PN Series...
-
Page 23: Connect The Usb Cable From Keyboard Or Mouse
Connect the USB cable from keyboard or mouse You can connect generally any USB keyboard and mouse to your Mini PC. You can also connect a USB dongle for a wireless keyboard and mouse set. To connect a keyboard and mouse to your Mini PC: Connect the USB cable from your keyboard and mouse to any of the USB ports of your Mini PC. -
Page 24: Turn On Your Mini Pc
Turn on your Mini PC Press the power button to turn on your Mini PC. PN Series... -
Page 25: Turning Your Mini Pc Off
Turning your Mini PC off If your Mini PC is unresponsive, press and hold the power button for at least four (4) seconds until your Mini PC turns off. Putting your Mini PC to sleep To set your Mini PC to enter Sleep mode by pressing the Power button once, search for Control Panel in the Windows Search Box, then navigate to Hardware and Sound >... -
Page 26: Load Default Bios Settings
Load default BIOS settings To load the default values for each of the parameters in your BIOS: • Enter the BIOS by pressing <F2> or <DEL> on the POST screen. NOTE: POST (Power-On Self Test) is a series of software controlled diagnostic tests that run when you turn on your Mini PC. -
Page 27: Upgrading Your Mini Pc
Upgrading your Mini PC... -
Page 28: Removing The Bottom Cover
It is recommended that you install or upgrade the memory modules, wireless card, and solid state drive (SSD), under professional supervision. Visit an ASUS service center for further assistance. • Ensure that your hands are dry before proceeding with the rest of the installation process. -
Page 29: Replacing The Bottom Cover
Replacing the bottom cover Push the bottom cover from the right side towards the left side of the Mini PC (A), then secure it using the four (4) screws removed previously (B). PN Series... -
Page 30: Installing Memory Modules
Align and insert the memory module into the slot (A) and press it down (B) until it is securely seated in place. Repeat the same steps to install the other memory module. IMPORTANT! Refer to http://www.asus.com for the list of compatible DIMMs. You can only install DDR4 SO-DIMMs to the Mini PC’s DIMM slots. -
Page 31: Installing 2.5" Hdd Or Ssd
Installing 2.5” HDD or SSD Prepare your 2.5” HDD or SSD, then align it with the storage bay on the bottom cover of your Mini PC. Insert your HDD or SSD into the storage bay (A), then secure it with four (4) screws (B). -
Page 32: Installing The M.2 Ssd (On Selected Models)
Installing the M.2 SSD (on selected models) Align and insert the 2280 M.2 SSD into its slot inside the Mini PC. Gently push down the 2280 M.2 SSD on top of the screw hole and fasten it using one of the bundled 3mm round screws. PN Series... -
Page 33: Installing The Wireless Card
Installing the wireless card NOTE: Your Mini PC includes a M.2 slot for 2230 wireless and Bluetooth modules. Refer to http://www.asus.com for the list of compatible wireless and Bluetooth modules. (optional) Remove the M.2 SSD if an M.2 SSD is installed. To remove the M.2 SSD, remove the screw from the screw hole, then remove the... - Page 34 PN Series...
-
Page 35: Appendix
Appendix... -
Page 36: Safety Information
Safety information Your Mini PC is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system • Read and follow all instructions in the documentation before you operate your system. - Page 37 • If you encounter the following technical problems with the product, unplug the power cord and contact a qualified service technician or your retailer. – The power cord or plug is damaged. – Liquid has been spilled into the system. –...
-
Page 38: Regulatory Notices
Regulatory notices COATING NOTICE IMPORTANT! To provide electrical insulation and maintain electrical safety, a coating is applied to insulate the device except on the areas where the I/O ports are located. Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: •... - Page 39 IMPORTANT! Outdoor operations in the 5.15~5.25 GHz band is prohibited. This device has no Ad-hoc capability for 5250~5350 and 5470~5725 MHz. CAUTION! Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment.
- Page 40 Compliance Statement of Innovation, Science and Economic Development Canada (ISED) This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 41 ASUS products sold in Vietnam, on or after September 23, 2011,meet the requirements of the Vietnam Circular 30/2011/TT-BCT. Các sản phẩm ASUS bán tại Việt Nam, vào ngày 23 tháng 9 năm2011 trở về sau, đều phải đáp ứng các yêu cầu của Thông tư 30/2011/TT-BCT của Việt Nam.
- Page 42 Turkey RoHS AEEE Yönetmeliğine Uygundur ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.
- Page 43 EPEAT (Electronic Product Environmental Assessment Tool) registered products The public disclosure of key environmental information for ASUS EPEAT registered products is available on CSR web site http://csr.asus.com/english/ article.aspx?id=41. More information about EPEAT program and purchaser guidance can be found on the EPEAT website www.epeat.net.
- Page 44 PN Series...
