3. System products
3.1. Hub Receiver
The Hub is a two-channel microphone receiver at the heart of the Plus system.
Manage your mics through the intuitive graphical UI, connect and monitor your systems
via API or utilize built-in Dante™ audio over IP
3.1.1. Hub operating elements and connections
1. Status LED
2. Display
3. System menu
4. Back button
5. Navigation buttons
6. Press to open or to con rm
1
2
7
8
9
3
4
5
10
11
7. USB-C Power, Audio In/Out
8. 3.5mm Auxiliary input
9. XLR Mic 2 Balanced audio output
10. XLR Mic 1 Balanced audio output
11. RCA Mixed Unbalanced audio output
6
5
